TC Electronic DARK MATTER DISTORTION User Manual page 9

(EN) Technical Specifications
Sounds
Unique distortion circuit with classic tube-amp characteristics: high headroom, low compression
and amazing bottom-end
Touch sensitive – control tone and distortion level by pick attack and your guitars volume knob
Two-band active EQ with separate bass and treble controls
Voice switch for vintage or modern voicing
Size & Weight
72 mm x 122 mm x 50 mm - 300 g (excl. battery)
Battery
16mA current draw
Non-stop playing Carbon: 6.5 hours, Alkaline: 25 hours.
These figures will vary depending on the actual conditions of use.
Design
Custom 'hammerhead' rugged, die-cast aluminum casing built for a life on the road
Gloss powder coating
Unique one-screw battery access for lightning fast battery changes
All metal design – this pedal was meant to be stepped on!
Connectors & Connectors and input/outputs
Inputs/Outputs
Metal Jack Connectors - road ready
Knobs etc.
Knobs, Switches and Controls
Gain, Level, Bass and Treble knobs with high-quality, metal-shaft potentiometers
Heavy duty tactile footswitch with true bypass for zero tone coloration
In the box
Owner's Manual, TC Electronic Guitar Pamphlet, TC Electronic Sticker.
