Summary of Contents for Tannoy Arenaccessories
- Page 1 Centre Channel Stand / Wall Bracket Accessory Manual...
- Page 3 4mm Allen key for stand to centre fixing screws stand to centre fixing screws shake proof washer for stand fixing screws Table stand 3mm Allen key for ball joint screws...
- Page 4 Cable management routing through ball joint Step one: Satellite fixing bracket Step two: Cable management – table stand application Ensure that the audio system amplifier is switched off and then feed the speaker cable up through the base and ball joint of the stand. Prepare the speaker cable by stripping 6mm ( inch) of insulation and connect to the relevant terminal on the base of the...
- Page 5 Step three: Centre channel fitting to stand Locate the unit into the cradle of the table / wall stand, ensuring that the speaker cable is carefully routed to avoid damage. Using the 4mm Allen key, insert the two chrome screws and lock washers into the underside of the unit and tighten to fully secure the unit.
- Page 6 Step four: Grille fitting If intending to use the grille you must remove the coloured trim piece using the finger recess behind the trim and locate the bottom section of the grille into the recess on the stand. Use the 4mm Allen driver to insert chrome screw to secure the grille in place.
- Page 7 Step five: Adjustment and locking of the ball joint – table stand The ball joint mechanism allows great flexibility in the positioning of the centre speaker in relation to the stand. Simply move the speaker to desired position, set in the required orientation and then use the 3mm Allen driver to tighten the four chrome screws to secure the satellite in the desired position.
- Page 8 Step six: Wall bracket application – orientation of bracket The universal design of the stand allows for wall mount use. Use the 3mm Allen key to slacken the four screws on the ball joint plate (fig. 1) slightly – rotate the assembly through and retighten (fig.
- Page 9 Step seven: Wall bracket application – wall plate Use the 4mm Allen key to remove the chrome screw retaining the wall mounting plate (figs.1 and 2). Remove the plate from the base (fig. 3) and mark the positions of the mounting screws on the wall surface. WARNING: Ensure that you utilise the correct wall fixings (screws, Rawlplug, Rawlbolt, toggle fixing, expanding insert etc) designed to provide maximum security of fastening to your wall construction.
- Page 10 Step eight: Wall bracket application – fixing to wall and adjustment Carefully dress the signal cable through the cable management and offer the bracket base to the secured wall mount plate. Using the 4mm Allen key, insert the chrome screw through the bracket and tighten to secure the assembly to the wall plate.
- Page 12 F: +44 (0) 1236 428230 E: enquiries@tannoy.com Tannoy North America T: (519) 745 1158 F: (519) 745 2364 E: inquiries@tannoyna.com Check periodically for the latest manual revision that will always available for download from www.tannoy.com The revision number of this manual is located below...
