Viewing the DoS sensor list

Viewing the DoS sensor list

Configuring DoS sensors

46
To view the anomaly list, go to Intrusion Protection > DoS Sensor.
Figure 12: The DoS sensor list
Create New Add a new DoS sensor to the bottom of the list.
ID A unique identifier for each DoS sensor. The ID does not indicate the
sequence in which the sensors examine network traffic.
Status Select to enable the DoS sensor.
Name The DoS sensor name.
Comments An optional description of the DoS sensor.
Delete Delete the DoS sensor.
Edit icon Edit the following information: Action, Severity, and Threshold.
Insert DoS Create a new DoS sensor before the current sensor.
Sensor before
icon
Move To icon Move the current DoS sensor to another position in the list. After
selecting this icon, enter the destination position in the window that
appears, and select OK.
Because an improperly configured DoS sensor can interfere with network traffic,
no DoS sensors are present on a factory default FortiGate unit. You must create
your own and then enable them before they will take effect. Thresholds for newly
created sensors are preset with recommended values that you can adjust to meet
the needs of your network.
Note: It is important to know normal and expected network traffic before changing the
default anomaly thresholds. Setting the thresholds too low could cause false positives, and
setting the thresholds too high could allow otherwise avoidable attacks.
To configure DoS sensors, go to Intrusion Protection > DoS Sensor. Select the
Edit icon of an existing DoS sensor, or select Create New to create a new DoS
sensor.
FortiGate IPS User Guide Version 3.0 MR7
01-30007-0080-20080916
DoS sensors
