Summary of Contents for Sonifex Redbox RB-DA6R
- Page 1 RB-DA6R 6 Way Stereo Distribution Amplifier With RJ45 Connectors RB-DA6RG 6 Way Stereo Distribution Amplifier With RJ45 Connectors & Output Gain Control User Handbook...
- Page 2 Information in this document is subject to change without notice and does not represent a commitment on the part of the vendor. Sonifex Ltd shall not be liable for any loss or damage whatsoever arising from the use of information or any error contained in this manual.
-
Page 3: Table Of Contents
Ordering the Correct Mains Lead Installation Information Atmosphere Electromagnetic Radiation Fitting Redboxes WEEE & RoHS Directives - Sonifex Statement RB-DA6R & RB-DA6RG 6 Way Stereo Distribution Amplifier With RJ-45 Outputs 1 Introduction System Block Diagram Connections and Operation Balanced Inputs... - Page 4 Fig 1-5: RB-DA6R & RB-DA6RG Rear Panel. Fig 1-6: RB-DA6R & RB-DA6RG Input Selector Switch. Fig 1-7: RB-DA6R Front Panel Input Gain Controls and Stereo/Mono Switch. Fig 1-8: RB-DA6RG Front Panel Output Gain Controls and Stereo/Mono Switch . Redbox RB-DA6R & RB-DA6RG User Handbook...
-
Page 5: Warranty
Company. In respect of computer software supplied by the Company the Company does not warrant that the use of the software will be uninterrupted or error free. Redbox RB-DA6R & RB-DA6RG User Handbook... - Page 6 Where the Goods are sold under a consumer transaction (as defined by the Consumer Transactions (Restrictions on Statements) Order 1976) the statutory rights of the Purchaser are not affected by these Conditions of Sale. Redbox RB-DA6R & RB-DA6RG User Handbook...
-
Page 7: Unpacking The Rb-Da6R & Rb-Da6Rg
Sonifex Ltd in the UK. For your own records you should write down the serial number (which can be found on the rear of the RB-DA6R &... -
Page 8: Safety Information
Connect the equipment in accordance with the connection details and before applying power to the unit, check that the machine has the correct operating voltage for your mains power supply. Important Note : The terminal marked on the rear panel must be earthed. Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 9: Ordering The Correct Mains Lead
SAFETY INFORMATION Ordering the Correct Mains Lead When ordering a Redbox from Sonifex, it is helpful if you can specify your required operating voltage and mains lead. After the product code add: UK, for 230V, UK 3 pin to IEC lead... -
Page 10: Installation Information
Note: When fitting the rear-mounting rack-kits, a notch has been left on the inside of the right-hand rack-piece for the mains cable to pass through. Make sure that the mains cable has been put through the notch before attaching the right hand rack-piece. Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 11: Weee & Rohs Directives - Sonifex Statement
“end of use”. Sonifex Ltd will be happy to give you information about local organisations that can reprocess the products, or alternatively all products that have reached “end of use” can be returned to Sonifex and will be reprocessed correctly free of charge. - Page 12 WEEE & ROHS INFORMATION Sonifex Ltd defines “Lead Free” as pertaining to any product, which has been manufactured by Sonifex Ltd using components which have been declared by the manufacturers as “Lead Free”. All statements by Sonifex Ltd of RoHS compliance are based on component manufacturer documentation.
-
Page 13: Rb-Da6R & Rb-Da6Rg 6 Way Stereo Distribution Amplifier With Rj-45 Outputs
The 1-12 mono, 1-6 stereo switch is recessed on the front panel to prevent accidental knocking. An LED power indicator on the front panel shows the unit is powered. Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 14: System Block Diagram
Gain Gain Gain Gain Gain Gain Gain Gain Gain Gain Gain Input Balanced Inputs Select Left XLR-3 Right Stereo/Mono RJ-45 Left & Right Unbalanced Inputs Left RCA Phono Right Fig 1-4: RB-DA6RG Block Diagram. Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 15: Connections And Operation
The RCA Phono input connectors provide an unbalanced input with an additional gain of +10dB to compensate for consumer level signals. Input Selector Switch This switch controls which input is routed to the outputs; either balanced (XLR-3 or RJ-45) or unbalanced (RCA Phono). Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 16: Stereo Outputs 1-6 (Mono Outputs 1-12)
12 mono channels, by the push button on the front panel, which is recessed to prevent accidental switching. In mono mode the left input channel is distributed to all outputs. Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 17: Technical Specification For Rb-Da6R & Rb-Da6Rg
Anti-surge fuse 100mA 20 x 5mm (230VAC) Anti-surge fuse 200mA 20 x 5mm (115VAC) Equipment Type RB-DA6R: 6 way stereo distribution amplifier with RJ-45 outputs RB-DA6RG: 6 way stereo distribution amplifier with RJ-45 outputs and output gain Redbox RB-DA6R & RB-DA6RG User Handbook... -
Page 18: Technical Specification
19” (W) x 4.3” (D) x 1.7” (H) (1U) Dimensions (Boxed): 53cm (W) x 20.5cm (D) x 6cm (H) 21” (W) x 8” (D) x 2.4” (H) Weight: Nett: 1.3kg Gross: 1.9kg Nett: 2.9lbs Gross: 4.2lbs Redbox RB-DA6R & RB-DA6RG User Handbook... - Page 19 NOTES Redbox RB-DA6R & RB-DA6RG User Handbook...
- Page 20 w w w . s o n i f e x . c o . u k t:+44 (0)1933 650 700 f:+44 (0)1933 650 726 s a l e s @ s o n i fe x . co. u k...
