Socket Cordless 56K Modem User Manual

Cordless 56k modem with bluetooth wireless technology
Hide thumbs Also See for Cordless 56K Modem:
Table of Contents

Advertisement

Quick Links

Download this manual
Cordless 56K Modem
®
with Bluetooth
Wireless Technology
Cordless modem for any Bluetooth enabled PDA, notebook
or tablet computer that supports a Dial-up Networking client
User's Guide
No software
installation
!
required

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cordless 56K Modem and is the answer not in the manual?

Questions and answers

Related Manuals for Socket Cordless 56K Modem

Summary of Contents for Socket Cordless 56K Modem

  • Page 1 Cordless 56K Modem ® with Bluetooth Wireless Technology Cordless modem for any Bluetooth enabled PDA, notebook or tablet computer that supports a Dial-up Networking client User’s Guide No software installation required...

  • Page 2: Copyright Notice

    Socket Communications, Inc. dba Socket Mobile, Inc. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc., and any use of such marks by Socket Mobile, Inc. is under license. All other brand and product names are trademarks of their respective holders.

  • Page 3: Table Of Contents

    STEP 3: Install the Software STEP 4: Complete the Connection Setup Wizard STEP 5: Connect to a Telephone Line STEP 6: Dial and Connect Socket Modem Utilities Manually Setting up a Bluetooth Connection 3 | SETUP FOR PALM OS STEP 1: Charge the Modem...
  • Page 4 6 | SETUP FOR MAC OS X STEP 1: Charge the Modem STEP 2: Prepare Dial-up Information STEP 3: Connect Modem and Notebook with Bluetooth STEP 4: Set up Your Dial-up Connection STEP 5: Dial and Connect APPENDICES A | SPECIFICATIONS B | NETWORK INFORMATION C | MANUAL DIAL-UP CONNECTION SETUP D | ADVANCED SOFTWARE INSTALLATION...

  • Page 5: Introduction

    Just connect the Cordless 56K Modem to any analog phone line, make a Bluetooth connection with your mobile computer, and enjoy up to 328 ft (100 m) of wireless freedom.

  • Page 6: System Requirements

    Quick Connect is convenient if you plan to repeatedly use the Cordless 56K Modem with the same phone line, for example the phone line in your hotel room.

  • Page 7: Package Contents

    The battery-powered version of the modem also includes a rechargeable lithium-ion battery and nylon travel pouch Product Registration Socket highly recommends that all customers register their Socket products. Registered users receive the following benefits: • Priority for technical support • Special offers for future products and product upgrades •...

  • Page 8: About The Power Switch And Leds

    About the Power Switch and LEDs Power Switch Position Status Meaning Down The battery-powered version will recharge if plugged into a power suppy. The battery-powered version will run on battery power if not plugged into a power supply. The battery-powered version will run on AC power if plugged into a power supply, and also recharge.

  • Page 9: Setup For Windows Mobile

    2 | Setup for Windows Mobile This chapter explains how to install and use the Cordless 56K Modem with a Pocket PC. Socket has developed a comprehensive suite of software (optional to install) which is designed to enhance your experience of using the Cordless 56K Modem with Pocket PCs.

  • Page 10: Step 1: Charge The Modem

    STEP 1: Charge the Modem If you have the battery-powered version of the Cordless 56K Modem and want to run it on battery power, use the AC adapter to charge the modem. It may take up to four hours to reach full charge.

  • Page 11: Step 3: Install The Software

    Connect!Agent is not compatible with Windows Mobile 5.0 devices using the Socket SD/CF card. If your Pocket PC is not compatible with Connect!Agent, or if you choose not to install it, use your Pocket PC’s Bluetooth software to manually create and manage the Bluetooth...
  • Page 12 4.0 or greater is required. Download it free from www.socketmobile.com/activesync. 2. Insert the Socket 56K Modem Installation CD into the host PC. 3. Use My Computer or Windows Explorer to access your CD-ROM drive. Click on the Setup.exe file for either Connect!Agent or the modem software.
  • Page 13 Note: If you forget to soft reset, some software icons will not appear. 6. If desired, repeat this same process to install Socket’s other software for Windows Mobile (Connect!Agent or the modem software).

  • Page 14: Step 4: Complete The Connection Setup Wizard

    STEP 4: Complete the Connection Setup Wizard If you did not install modem software, refer to Appendix C for manual setup instructions. 1. If the Pocket PC is connected to the host PC, remove it from the cable/cradle. 2. Tap Start | Settings | Connections tab. Tap on the Connection Setup icon. 3.
  • Page 15 • If your device has a built-in Bluetooth radio, ignore and tap OK. • If your Pocket PC does not have a built-in Bluetooth radio, insert the Socket SD/CF Bluetooth card or another Bluetooth adapter. Tap OK. 8. The last screen will report that you have completed the wizard. Tap on the link for Remote Networking if you would like to use the Pocket PC’s...

  • Page 16: Step 5: Connect To A Telephone Line

    Bluetooth connection using the Bluetooth software included with your Pocket PC or Bluetooth card. 2. If you just completed the Socket Connection Setup Wizard and tapped on the link for Remote Networking, the Connections screen will appear.
  • Page 17 4. Tap and hold your stylus on the connection for the Socket Cordless 56K Modem. In the pop-up menu, tap Connect. 5. If you installed Connect!Agent, a bubble will appear reporting that the modem is dialing. If desired, tap Hide to reveal a status screen reporting that Connect!Agent is searching for the Socket Cordless 56K Modem.
  • Page 18 When prompted, enter the passkey from a sticker on the back on the modem. When prompted to select the Bluetooth service, select Dialup Networking. Tap Finish. Note: After a successful connection, Socket Connect!Agent will save the device and passkey information, so future connections will be automatic.
  • Page 19 6. After the Bluetooth connection is established, the Bluetooth status LED will blink blue. Dialing will begin. The modem will make dialing sounds. 1234567 7. After the modem connects to your ISP or office network, the Modem Status LED will turn on (green), blinking during data transfer. Also, the “X”...
  • Page 20 4. If you installed Connect!Agent, a bubble will appear reporting that the modem is dialing. If desired, tap Hide to reveal a status screen reporting that Connect!Agent is searching for the Cordless 56K Modem. When prompted, enter the passkey from a sticker on the back on the modem.
  • Page 21 METHOD 3: Use your Pocket PC’s Built-in Bluetooth software The Bluetooth software built into some Pocket PCs allows you to start dialing into your ISP after establishing a Bluetooth connection to the Socket Cordless 56K Modem. Refer to your Pocket PC manual for instructions.
  • Page 22 4. A bubble should appear with the dial-up connection you just created for the Cordless 56K Modem. Tap on the phone number. Note: Multiple connections may be listed. If the Cordless 56K Modem connection is not listed, tap on the Settings link in the bubble. Tap Manage Existing Connections.
  • Page 23 6. If you did not use the Connection Setup Wizard, the Network Log On screen may appear. Enter the Password for your account and tap OK. 7. After a Bluetooth connection is established, the Bluetooth Status LED will begin blinking blue. Dialing will begin. The modem will make dialing sounds.

  • Page 24: Socket Modem Utilities

    Socket Modem Utilities 1. Make sure the modem is NOT connected to your ISP or office network. 2. Turn on the Cordless 56K Modem by pushing the power switch up. To run the modem on AC power, use the included AC adapter.
  • Page 25 This feature is helpful if you plan to use the Socket Cordless 56K Modem repeatedly from the same phone line.

  • Page 26: Manually Setting Up A Bluetooth Connection

    3. Tap on the Bluetooth icon. Tap Advanced Features | Bluetooth Devices. 4. Tap Tools | Device Discovery. 5. Follow the wizard to search for the Socket Cordless 56K Modem. Select Socket Cordless Modem from the list of found devices.
  • Page 27 These are generic instructions. Refer to the user documentation for your Bluetooth hardware/software for specific instructions. 1. Turn on the Cordless 56K Modem by pushing the power switch up. To run the modem on AC power, use the included AC adapter.

  • Page 28: Setup For Palm Os

    3 | Setup for Palm OS This chapter explains how to install and use the Cordless 56K Modem with a Bluetooth enabled Palm PDA that supports a DUN client. The modem works with PDAs running Palm OS 5.2 or greater.

  • Page 29: Step 1: Charge The Modem

    STEP 1: Charge the Modem If you have the battery-powered version of the Cordless 56K Modem and want to run it on battery power, use the included AC adapter to charge the modem. It may take up to four hours to reach full charge.

  • Page 30: Step 3: Connect Modem And Pda With Bluetooth

    • Do not plug the modem into a digital PBX line. The modem will not work and may be damaged! 1. Connect the Socket Cordless 56K Modem to an analog phone line. Use the included retractable cable. 2. Turn on the Socket Cordless 56K Modem by pushing the power switch up.
  • Page 31 7. Your PDA will search for Bluetooth enabled devices in range. In the Discovery Results, select Socket Cordless Modem. Tap OK. If the Cordless 56K Modem is not listed, make sure it is turned on and in range and tap Find More.
  • Page 32 10. Tap Done to return to the Connection Preferences screen. Your new connection should be listed. Tap Done.

  • Page 33: Step 4: Set Up Your Dial-Up Connection

    STEP 4: Set up Your Dial-up Connection 1. From the Communications Preferences list, select Network. Tungsten T2, T3,T5, Zire 72 Tungsten T 2. In the Network Preferences screen, tap New. 3. An Untitled network service profile will appear. Enter the following: •...

  • Page 34: Step 5: Dial And Connect

    STEP 5: Dial and Connect 1. In the Network Preferences screen, tap Connect. 2. Dialing will begin. Service Connection Progress messages will appear, reporting the status of the connection. The modem will make dialing sounds. 3. When the PDA reports that you have connected, tap Done. Now you are ready to use your email or Internet application.

  • Page 35: Setup For Windows 98Se/Me/2000/Xp

    4 | Setup for Windows 98SE/Me/2000/XP This chapter explains how to set up the Socket Cordless 56K Modem for use with a notebook computer running Windows 98SE/Me/2000/XP. Setup Summary STEP 1: Charge the modem. STEP 2: Prepare dial-up information. STEP 3: Connect the modem and computer with Bluetooth STEP 4: Make sure a virtual Bluetooth modem is installed.

  • Page 36: Step 1: Charge The Modem

    STEP 1: Charge the Modem If you have the battery-powered version of the modem and want to run it on batteries, use the included AC adapter to charge the modem. It may take up to four hours to reach full charge. The Battery Charging Status LED will be red when the battery is less than 90% charged, and green when at least 90% charged.

  • Page 37: Step 3: Connect Modem And Pc With Bluetooth

    1. Connect the Socket Cordless 56K Modem to an analog phone line. Use the included retractable cable. 2. Turn on the Cordless 56K Modem by pushing the power switch up. To run the modem on AC power, use the included AC adapter.

  • Page 38: Step 4: Make Sure A Virtual Bluetooth Modem Is Installed

    Is Installed Note: If your Bluetooth software automatically sets up the new modem in Windows, skip the instructions here. Socket’s add-on Bluetooth products with BlueSoleil software automatically install a virtual Bluetooth modem. Most Bluetooth software automatically install a virtual Bluetooth modem for dial-up networking.

  • Page 39: Step 5: Set Up Your Dial-Up Connection

    STEP 5: Set up Your Dial-up Connection Note: If your Bluetooth software helps you set up a dial-up connection, skip the instructions here and set up the connection using your software. Make sure you enter the correct user name, password, and phone number for your ISP account.
  • Page 40 4. In the next screen, for Windows XP, select Connect to the Internet. For Windows 2000, select Dial-up to the Internet. Click Next. 5. For Windows XP, select Set up my connection manually. For Windows 2000, select I want to set up my Internet connection manually… Click Next.
  • Page 41 6. For Windows XP, select Connect using a dial-up modem. For Windows 2000, select I connect through a phone line and a modem. Click Next. 7. Select the virtual Bluetooth modem assigned for dial-up networking. Deselect any other modems that may have been installed on your computer.
  • Page 42 Windows Me and 98SE 1. Click Start | Settings | Dial-up Networking. 2. Double-click on the Make New Connection icon. 3. The Make New Connection Wizard will begin. In the first screen, enter the following settings: • Enter a name for the dial-up connection. •...

  • Page 43: Step 6: Dial And Connect

    STEP 6: Dial and Connect Note: If your Bluetooth software helps you manage dial-up connections, skip the instructions here and use your software to dial-up to the network. 1. After setting up your dial-up connection in the Windows wizard, your new connection should be listed in the network connections screen.

  • Page 44: Advanced Networking

    Advanced Networking Follow the steps below to set up a connection for a RAS server. Advanced setup is necessary only if your network does NOT use DHCP (Dynamic Host Configuration Protocol). Note: You may want to complete the Network Information Form in Appendix B.
  • Page 45 Windows 2000 1. After you complete the New Connection Wizard, right-click on the icon for the connection you just created. In the pop-up menu, select Properties. 2. Click on the Networking tab. Check Internet Protocol and click Properties. 3. Enter any necessary settings. If needed, click Advanced to enter DNS, WNS or other settings.

  • Page 46: Setup For Windows Xp Tablet Edition

    5 | Setup for Windows XP Tablet Edition This chapter explains how to set up the Socket Cordless 56K Modem for use with a Windows XP tablet PC. The instructions differ depending on which Bluetooth software your tablet PC is running. To...

  • Page 47: Step 1: Charge The Modem

    STEP 1: Charge the Modem If you have the battery-powered version of the modem and want to run it on batteries, use the included AC adapter to charge the modem. It may take up to four hours to reach full charge. The Battery Charging Status LED will be red when the battery is less than 90% charged, and green when at least 90% charged.

  • Page 48: Step 3: Turn On The Bluetooth Radio

    STEP 3: Turn on the Bluetooth Radio 1. Tap Start | Programs | Motion Resources | Dashboard. Alternatively, tap on the Dashboard icon on your desktop, or press the Hot Button for the Dashboard. 2. In the WIRELESS section, under Bluetooth, check the box Enable Internal Bluetooth Wireless Radio.

  • Page 49: Step 4: Connect Modem And Tablet With Bluetooth

    Bluetooth software your tablet PC is running. Toshiba Bluetooth software 1. Turn on the Cordless 56K Modem by pushing the power switch up. To run the modem on AC power, use the included AC adapter. 2. Double-tap on the Bluetooth icon at the bottom of your screen.
  • Page 50 6. Enter the passkey printed on a sticker on the back of the modem. Tap Next. 7. In the list of device services, select Dial-up Networking. Tap Next. 8. In the Advanced Modem Settings screen. tap Next. 9. Enter the Telephone number, User name and Password for your Internet Service Provider account.
  • Page 51 Microsoft Bluetooth software 1. Turn on the Cordless 56K Modem by pushing the power switch up. To run the modem on AC power, use the included AC adapter. 2. Tap on the Bluetooth icon at the bottom of your screen. In the pop-up menu, tap Add a Bluetooth Device.
  • Page 52 5. In the next screen, select Use the passkey found in the documentation. Enter the passkey printed on a sticker on the back of the modem. Tap Next. 6. In the last screen, make a note of the Outgoing COM port number. Tap Finish.

  • Page 53: Step 5: Set Up Your Dial-Up Connection

    STEP 5: Set up Your Dial-up Connection Note: If your Bluetooth software helps you set up the dial-up connection (e.g., Toshiba Bluetooth software), skip this step. Go ahead and connect, as described on page 55. 1. Tap Start | Control Panel | Network Connections. Under Network Tasks on the left side, tap Create a new connection.
  • Page 54 4. Select Set up my connection manually. Tap Next. 5. Select Connect using a dial-up modem. Tap Next. 6. If the Select a Device screen appears, select the Bluetooth modem at the Outgoing COM port number you noted earlier. Deselect any other modems that may have been installed on your computer.

  • Page 55: Step 6: Dial And Connect

    Do not plug the modem into a digital PBX line. The modem will not work and may be damaged. 1. Connect the Socket Cordless 56K Modem to an analog phone line. Use the included retractable cable. 2. The procedure for dialing into a network varies depending on the Bluetooth software your tablet PC is running.
  • Page 56 Microsoft Bluetooth software: Use the Microsoft connection utility to dial in. • After you complete the New Connection Wizard, the Connect To screen will appear. Tap Dial. Note: To launch this screen any time, in the Network Connections screen, tap on the icon for your dial-up connection. •...

  • Page 57: Setup For Mac Os

    6 | Setup for Mac OS X This chapter explains how to set upthe Socket Cordless 56K Modem for use with a notebook computer running Mac OS X. The instructions are based on the iBook G4. Setup Summary STEP 1: Charge the modem.

  • Page 58: Step 3: Connect Modem And Notebook With Bluetooth

    1. Connect the Socket Cordless 56K Modem to an analog phone line. Use the included retractable cable. 2. Turn on the Cordless 56K Modem by pushing the power switch up. To run the modem on AC power, use the included AC adapter.
  • Page 59 Click Pair. 8. When asked to choose services, select Internet Access. Click OK. 9. For Socket Cordless Modem, select Dial-up Networking. Click Select. 10. In the Bluetooth Serial Utility screen. Click OK. The next screen should list the new connection.

  • Page 60: Step 4: Set Up Your Dial-Up Connection

    STEP 4: Set up Your Dial-up Connection 1. Click Applications | Internet Connect. 2. In the Bluetooth screen, for Configuration, select Edit Configurations. 3. In the next screen, enter settings for your dial-up connection: • Description: Enter a name for your dial-up connection. •...

  • Page 61: Step 5: Dial And Connect

    STEP 5: Dial and Connect 1. In the Bluetooth screen, click Connect. LEDs should begin blinking. The modem will make dialing sounds. 2. When the computer has connected, the Modem Status LED will turn on (green), blinking during data transfer. Now you are ready to use your email or Internet application.

  • Page 62: A | Specifications

    Appendix A Specifications Physical Characteristics: L x W x H: 3.1 x 1.1 x 2.9 inches (79 x 26.5 x 73 mm) Weight: 3.2 oz (91 g) Power Consumption: Active: 160 mA (Modem), 200 mA (Bluetooth transmitting) Inctive: 20 mA (Modem), 20 mA (Bluetooth) Battery capacity: 900 mA Operating Temperature: 0 to +50°...
  • Page 63 Software Included for Windows Mobile (Optional to install): - Socket Connection Setup wizard for Windows Mobile 2003/2003SE/5.0 - Socket Modem Utilities for Windows Mobile 2003/2003SE/5.0 - Socket Connect!Agent for Windows Mobile 2003/2003SE/5.0 Note: ActiveSync 4.0 or greater is required to install the software.

  • Page 64: B | Network Information

    Appendix B Network Information Network Information Form For Advanced Users Only Contact your office network administrator or Internet Service Provider (ISP) for the information below. 1. Please provide the following dial-up information: Dial-up number: ( ____ ) _______________ User name: _________________________ Password: _________________________ Domain: __________________________ 2.

  • Page 65: C | Manual Dial-Up Connection Setup

    Note: If you do not want to manually set up the connection, see Chapter 2 for instructions on the Socket Connection Setup Wizard. 1. Tap Start | Settings | Connections tab. Tap on the Connections icon. 2. Tap on the Advanced tab. Tap Select Networks.
  • Page 66 3. Make sure My ISP is selected in the top field, and My Work Network is selected in the bottom field. Tap ok. 4. Tap on the Tasks tab. In most cases, you should tap Add a new modem connection under My ISP. 66 | APPENDIX C: MANUAL DIAL-UP CONNECTION SETUP...
  • Page 67 5. In the next screen, enter the following: • Enter a name…: Enter a name for your dial-up connection. • Select a modem: The options will vary depending on your Pocket PC version, and whether you installed Connect!Agent.. Windows Mobile 5.0: −...
  • Page 68 6. In the next screen, enter the dial-up number exactly how it should be dialed. You can enter the number without any spaces or dashes. Note: If you plan to use the connection in different areas, tap use dialing rules to set up dialing locations.

  • Page 69: D | Advanced Software Installation

    Windows Mobile Advanced Users Only! If you do not want to use the application installer to install Socket’s modem software, you can install the software from a CAB (cabinet) file. The CAB file contains all the necessary software and drivers for your product to be installed on a specific Pocket PC platform.

  • Page 70: E | Faxing

    3. If using Socket’s Connection Kit for Windows Mobile, assign the Cordless 56K Modem as your favorite fax. In the Bluetooth Devices folder, tap Tools | My Favorites. Tap on the FAX tab. Select the Cordless 56K Modem and tap ok.

  • Page 71: F | Technical Support

    Appendix F Technical Support If you have trouble installing or using the Cordless 56K Modem, Socket has two resources to help you: Socket Online Support Socket Online Support is an interactive technical support program that provides immediate service and is the best place to start for technical support.

  • Page 72: Limited Warranty

    Socket will, at its option, repair or replace the defective product at no charge when furnished with proof of retail purchase, provided that you deliver the product to Socket or to an authorized Socket Service Center. The returned product must be accompanied by a return material authorization (RMA) number issued by Socket or by Socket's Authorized Service Center.
  • Page 73 90 days from the date of delivery of the SOFTWARE. CUSTOMER REMEDIES. SOCKET’S entire liability and your exclusive remedy shall be, at SOCKET’S option, either (a) return of the price paid or (b) replacement of the SOFTWARE which does not meet SOCKET’S Limited Warranty and which is returned to SOCKET with a copy of your receipt.

  • Page 74: Regulatory Compliance

    Telecom Regulatory Compliance 1. This equipment complies with Part 68 of the FCC Rules. On the inside of the Socket Cordless 56K Modem (behind the battery) is a label that contains, among other information, the FCC registration number. If requested, provide this information to your telephone company.
  • Page 75 9. For any other repairs to the device, also contact Socket’s technical support department by the method mentioned above. 10. Connection to party line service is subject to state tariffs. Contact the state public utility commission, public service commission or corporation commission for information.
  • Page 76 Radio Frequency Interference Requirements This device complies with part 15 of the FCC rules and Industry Canada. Operation is subject to the following conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 77 The user may find the following booklet helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Canada Certification The marking of “IC:252929A-BM56S” on the device means: “252929A- BM56S”...
  • Page 78 • EN 60 950 + Amd 1 + Amd 2 – Safety of Information Technology Equipment Including Business Equipment. Battery Warning: • Your device contains a rechargeable lithium ion battery. Never throw the battery into a fire, as that could cause the battery to explode. •...
  • Page 79 5/2007 Printed in U.S.A.
