3. Playback Section
The Playback Section is placed in the lower part of the Sound Laundry™ TerraTec Edition
window. You can load a WAV file for processing, start and stop playback, as well as jump to
the desired position in the WAV file by moving the cursor in the waveform display.
After loading a WAV file, its name and format is shown in the status window below the
Analyzer and its waveform is displayed in yellow in normalized view, i.e., properly squeezed
to the width of the waveform display.
Fig. 2: The Playback Section of Sound Laundry™ TerraTec Edition.
The processed audio material can be stored off-line by opening the file dialog with the
[STORE] button. The sampling frequency of the output file is the same as the input file (44.1
kHz). File format conversion or sampling rate conversion like 96 kHz to 44.1 kHz should be
done by the appropriate high-quality tool in your editing or soundcard software.
List of the buttons and switches in the Playback Section
opens this help file
stops the playback
starts the playback
moves the playback cursor to begin
opens the load file dialog
opens the store file dialog
CPU [ XX % ]
difference
bypass all
Algorithmix® Sound Laundry™ TerraTec Edition (English)
shows the computer load, i.e., how much computational Sound
Laundry™ TerraTec Edition is using
allows listening to only the noise being removed during processing
allows listening to the input only bypassing the Descratcher and
Denoiser
5
