3. Implementation for the MIDI Remote Mode
PHASE 88 Rack FW
MIC 2/8 FW 96 kHz
PHASE 88 Rack FW
MIC 2/8 FW 96kHz
MIC 2/8 FW ADAT
Examples
1. MIDI input channel is 1, Line In 1/2 Fader controller no. is set to 10(dez):
Set Line In 1/2 Fader to 0dB (max)
=> send MIDI control: B0(hex) – 0A(hex) – 7F(hex)
2. MIDI input channel is 16, Line In 1/2 Fader controller no. is 1:
Set Line In 1/2 Fader to -127dB (MUTE)
=> send MIDI control: BF(hex) – 01(hex) – 00(hex)
3. MIDI input channel is 5, Line Out 5/6 controller is 20(dez):
Route Line Out 5/6 to Digital Mixer Out
=> send MIDI control: B4(hex) – 14(hex) – 00(hex)
4. MIDI input channel is 12, Digital Out controller is 40(dez):
Route Digital Out to Line Input 7/8
=> send MIDI control: BB(hex) – 28(hex) – 04(hex)
Advanced Standalone Mode for EWS MIC 2/8 (96kHz or ADAT Firmware) and PHASE 88 Rack FW
Controls
Line In 1/2 Fader
Line In 3/4 Fader
Line In 5/6 Fader
Line In 7/8 Fader
Digital In 1/2 Fader
Digital In 3/4 Fader*
Digital In 5/6 Fader*
Digital In 7/8 Fader*
Master Fader
*MIC with ADAT
Line Out 1/2 Source
Line Out 3/4 Source
Line Out 5/6 Source
Line Out 7/8 Source
Digital Out Source
Line Out 1/2 Source
Line Out 3/4 Source
Line Out 5/6 Source
Line Out 7/8 Source
Digital Out 1/2 Source
Digital Out 3/4 Source
Digita Out 5/6 Source
Digital Out 7/8 Source
Controller Number
00, 01 = -127dB (MUTE)
02 –> 3F(hex) = -40.0dB -> -18dB
Set by user in 40(hex) –> 7F(hex) = -17.7dB -> 0.0dB
Control Panel
(0-127dez) 00, 01 = -127dB (MUTE)
02 –> 63(dez) = -40.0dB -> -18dB
64(dez) -> 127(dez) = -17.7dB -> 0.0dB
0 = Digital Mixer
1 = Line In 1/2
Set by user in 2 = Line In 3/4
Control Panel 3 = Line In 5/6
(0-127dez) 4 = Line In 7/8
5 = Digital In
6 = No Signal
0 = Digital Mixer
1 = Line In 1/2
2 = Line In 3/4
3 = Line In 5/6
Set by user in
4 = Line In 7/8
Control Panel
5 = Digital In 1/2
(0-127dez)
6 = Digital In 3/4
7 = Digital In 5/6
8 = Digital In 7/8
9 = No Signal
Controller Value
(0-127dez / 00-7Fhex)
