9V Power Jack
Plug the output of the Ring Thing's supplied AC Adapter into the 9V power jack located at
the top of the Ring Thing. The Ring Thing requires 9 - 9.6VDC at 200mA with a center
negative plug. The Ring Thing accepts Boss style AC Adapters. The actual current draw of
the Ring Thing is 190 mA.

Technical Specifications

Sample Rate = 46.93 kHz
A/D and D/A Conversion Bit Resolution = 24 bits
Processed Audio Bit Resolution = 32 bits
PRESETS
The Ring Thing has nine fully programmable presets. Any of the four available modes can
be saved in a preset. Once a preset is saved, the Ring Thing will remember the preset
after power has been disconnected.
Saving a preset will save the setting of all 5 of black knobs and the selected mode. It will
also save a tuned-in ring modulator frequency whether tuned using the PRESET/TUNE
footswitch or an expression pedal. The expression pedal setting at the time of saving the
preset will be saved. If you save a preset without an expression pedal connected, and then
recall the preset with an expression pedal present, the Ring Thing ignores the expression
pedal.
PRESET SAVE PROCEDURE:
1. Once you have created a sound you want to save, turn the MODE knob to the
preset number you want to save the setting to.
2. Press and hold down the MODE knob for 3 seconds. Nothing will occur for 2
seconds, then all the preset LEDs will blink rapidly for 1 second.
3. After the LEDs stop blinking, release the MODE knob. The Preset LED will light
up solid.
4. Your preset has been saved.
PRESET LOAD PROCEDURE:
There are two options for loading presets:
1. Press and release the PRESET/TUNE FSW repeatedly until the preset you want to
load is selected. Make sure the PRESET LED is lit to indicate your preset is
- Presets -
15
