1
Introduction
Congratulations on your purchase of a Durabook R13S notebook! The R13S is a
fully functional PC with built-in wireless connectivity. With the R13S notebook, you
will be able to organize and access important business and personal information. In
addition, you will be able to access the Internet and send and receive e-mail.
This manual contains all the information you need to set up and use your Durabook
R13S. It thoroughly describes all the features of the notebook in a detailed and
easy-to-read manner.

System Configurations

Processor: Intel U7500 "Merom" Processor Support
Speed at 1.06GHz
Chipset: INTEL ICH-8M + 965GM Chipset
OS Support:
Microsoft Windows XP Edition OS Support
Display Screen Interface Support:
Standard Touch Screen
Sunlight readable screen
LCD Flat Panel Support:
13.3" TFT, 1280x800 Resolution

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Durabook R13S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Twinhead Durabook R13S

Summary of Contents for Twinhead Durabook R13S

  • Page 1: System Configurations

    Introduction Congratulations on your purchase of a Durabook R13S notebook! The R13S is a fully functional PC with built-in wireless connectivity. With the R13S notebook, you will be able to organize and access important business and personal information. In addition, you will be able to access the Internet and send and receive e-mail.
  • Page 2 Storage Support: HDD Support 2.5” SATA HDD Capacity Points: 80GB 5400RPM (up to 250GB) System Memory: Single SO-DIMM Memory Slots DDR2-667MHz System Memory Upgradeable to 2GB Expansion Slot: Connecter USB 2.0 Support RS-232 Support PCMCIA & Flash Memory Slot Optical Device: DVD Super Multi Dual Layer 8X/6X/4X Communication Device Support: Wireless LAN (WLAN) Intel 802.11A/B/G/N Support:...

  • Page 3: Safety Precautions

    Safety Precautions The following safety precautions will increase the life expectancy of the Durabook R13S notebook. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use damaged power cords, accessories, and other peripherals. Do not use strong solvents such as thinners, benzene, or other chemicals on or near the surface.
  • Page 4 DO NOT expose the notebook to or use near liquids, rain, or moisture. DO NOT use the notebook’s modem during an electrical storm. DO NOT leave the notebook on your lap or any part of the body in order to prevent discomfort or injury from heat exposure.

  • Page 5: Preparing Your Notebook

    Preparing Your Notebook These are only quick instructions for powering on your Durabook R13S notebook. Read the later pages for detailed information on using your notebook. 1. Connect the AC Power Adapter 2. Install the Battery Pack 3. Turn ON the Notebook...

  • Page 6: Getting Started

    Getting Started Front View 1. Five Way Control Key – Up/Down, Left/Right, & Enter Button 2. WiFi/BT Power Button 3. Mouse Button 4. System Power Button 5. LCD Panel 6. Internal Microphone & Speaker 7. LED Status Indicator 8. Fingerprint Scanner 9.
  • Page 7 I/O Port View 1. USB Port 2. LAN Port 3. Modem Port 4. USB Port 5. RS232 Port 6. Display Output 7. Optical Drive 8. Battery Slot 9. Kensington Lock 10. Microphone-In & Audio-Out 11. PCMCIA and Flash Memory Slot 12.
  • Page 8 Making Connections Your Durabook R13S notebook is equipped with a full array of ports and connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers, keyboards, and mice. Refer to the documentation included with individual devices for details on connecting these devices to your notebook.
  • Page 9 9. Kensington® Lock Port The Kensington® lock port allows the notebook to be secured using Kensington® com- patible Notebook PC security products. These security products usually include a metal cable and lock that prevent the notebook from being removed from a fixed object. Some may also include a motion detector to sound an alarm when moved.

  • Page 10: Power Systems

    Power Systems Using AC Power The Durabook R13S notebook power system is comprised of two parts, the power adapter and the battery. The power adapter converts AC power from a wall outlet into DC power required by the R13S. Your R13S notebook comes with a universal AC/DC adapter.

  • Page 11: Using Battery Power

    NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY. Using Battery Power The Durabook R13S notebook is designed to work with a removable battery pack. The battery pack consists of a set of battery cells housed together. A fully charged pack will provide several hours of battery life, which can be further extended by using power management features through the BIOS setup.

  • Page 12: Battery Care

    Battery Care The Durabook R13S notebook’s battery pack, like all rechargeable batteries, has a limit on the number times that it can be recharged. The battery pack’s usability will depend on your environment’s temperature, humidity, and how the R13S notebook is being used.
