- Page 1 ’ ’...
-
Page 2: Table Of Contents
Table Of Contents CHAPTER 1 GETTING STARTED Getting Started ................... 2 Inventory ..................... 3 Safety and Maintenance ..............4 Checklists ................... 5 Features ....................6 Where to Look For Information............7 Quick Start ..................8 Loading Windows ................9 Adjusting the Volume ..............10 Adjusting the Brightness .............. - Page 3 Memory....................27 The Graphics System ..............28 Communication Components ............32 Information about the Wireless LAN button........33 CHAPTER 3 MAKING CONNECTIONS Making Connections ................ 36 Left Side Connectors ............... 36 Right Side Connectors ..............37 Front Side Connectors ..............38 CHAPTER 4 SYSTEM SOFTWARE System Software ................
- Page 4 FREQUENTLY ASKED QUESTIONS Frequently Asked Questions ............64 APPENDIX B STATEMENTS Statements ..................68 European Notice................71 UL CAUTION ..................71 Canadian Department of Communications ........72 Battery Disposal................73 CAUTION FOR ADAPTER..............73 BATTERY CAUTION................. 73 CLASS 1 LASER PRODUCT ............73 Macrovision DVD License Agreement ...........
-
Page 6: Getting Started
Chapter 1 — Introduction Getting Started Congratulations on your purchase of the Notebook computer! Your new notebook features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with sophisticated architecture to provide you with a personal computer that is compact, powerful, and easy to use. -
Page 7: Inventory
Introduction — Inventory Inventory This computer system is designed for years of productive and pleasurable computing. Use this section to keep details of your purchase. This information will be required should you need to make repairs to your notebook during the warranty period. Update this section when you add new options. -
Page 8: Safety And Maintenance
Chapter 1 — Introduction Safety and Maintenance You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: • Follow all warnings and instructions noted in this documentation and in the Windows Help program. -
Page 9: Checklists
Introduction — Checklists • Set the computer on a flat, stable surface. To prevent damage to the computer’s hard disk drive, avoid using the computer where it will be exposed to strong vibration. Checklists After opening the package, carefully inspect the contents. If any of the items is missing or appear damaged, contact your dealer. -
Page 10: Features
Chapter 1 — Introduction Caution: When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electro-magnetic radiation in... -
Page 11: Where To Look For Information
Introduction — Where to Look For Information Where to Look For Information About Your Computer This User’s Manual describes the key elements of your computer. New users can find a simple step-by-step orientation in the Quick Start section of this chapter. About Windows The Windows Manual provides an overview of the Windows operating System. -
Page 12: Quick Start
Chapter 1 — Introduction Quick Start Turning on the Computer for the First Time 1. Connect the AC adapter power cord to the AC adapter. 2. Connect the AC adapter to the DC power port on the left side of your computer. -
Page 13: Loading Windows
Introduction — Loading Windows Loading Windows The following section is for installing the Windows operating system only. If you are installing a different operating system, please check with your vendor for installation details. Your computer will begin loading Windows once you turn on the power. -
Page 14: Adjusting The Volume
Chapter 1 — Introduction Adjusting the Volume You can adjust the volume with the volume control knob located below the touchpad. Volume Control Knob Alternatively, you can adjust the volume with the Windows volume control applet located on the taskbar. Adjusting the Brightness Use the following hot key combinations to adjust the LCD panel brightness:... -
Page 15: Turning Off Your Computer
Introduction — Turning off Your Computer Turning off Your Computer Turning off the computer properly is important to maintaining your computer. 1. On the Start menu, click Turn 2. Click the Turn Off button. Off Computer. If you are going to be away from the computer for a short period, there are ways of conserving power without shutting down the system. - Page 16 Chapter 1 — Introduction Don't leave passwords anywhere on your notebook or carrying case Be careful when placing your notebook on an airport security conveyor belt In most airports, security conveyor belts are safe for computers. If you are not sure, ask the security staff. You should keep a close eye on your computer.
-
Page 18: Getting Started
Chapter 2 — Getting Started Hardware and Software This chapter introduces the different components and controls of your notebook computer, including the hardware components, the software, and the audio and video systems. Getting Started Before you begin using your computer, read this chapter to familiarize yourself with the main components installed in the system. -
Page 19: Front View
Getting Started — Left View Front View 1. LCD panel 10. Audio-out jack for external speakers or headphones 2. Battery 11. SPDIF jack 3. Keyboard 12. IEEE1394 port 4. Speakers 13. Power indicators 5. Touchpad 14. Microphone 6. Touchpad buttons 15. -
Page 20: Left View
Chapter 2 — Getting Started Left View 1. Shoulder strap hole 2. Kensington lock hole 3. Ventilation slots 4. DC-adapter port 5. VGA port external video display 6. LAN RJ-45 jack 7. RJ-11 jack 8. USB port 9. PCMCIA card slot 10. -
Page 21: Right View
Getting Started — Bottom View Right View USB ports S-Video port CD-ROM/DVD-ROM/Combo/DVD±RW drive CD-ROM/DVD-ROM/Combo/DVD±RW drive lock CD-ROM/ DVD-ROM/Combo/DVD±RW drive eject button Shoulder strap hole... -
Page 22: Bottom View
Chapter 2 — Getting Started Bottom View Ventilation slots WLAN Module Battery release button Battery SO-DIMM DDR RAM Module... -
Page 23: Led Status Indicators
Getting Started — LED Status Indicators LED Status Indicators The status indicators in the upper left corner of the keyboard light up when a particular function of the computer is active. Each indicator is marked with a symbol. The computer is reading information CD ROM Drive from the CD-ROM, CD-RW or the DVD ROM drive. -
Page 24: Power Indicators
Chapter 2 — Getting Started Power Indicators The power indicators show which power source the system is using. They also show battery status and low battery power alerts. The power indicators remain active and viewable even when the LCD panel is closed. Icon Light Description... -
Page 25: Numeric Keypad
Getting Started — Touchpad Numeric Keypad The embedded numeric keypad consists of ten keys that make number intensive input more convenient. Press <NumLock> to enable or disable the numeric keypad. Touchpad The touchpad is a pressure sensitive pointing device that provides all the features of a two-button mouse. - Page 26 Chapter 2 — Getting Started makes selections, drags objects, or performs a variety of other functions depending on the software. To select an object, first move the pointer over the object you want to select, and then press the left button one time. The functions of these buttons are software specific.
-
Page 27: Connecting The Floppy Disk Drive
Getting Started — Disk Drives Connecting the Floppy Disk Drive Your notebook computer comes with a USB port 1.44 MB floppy disk drive (FDD is optional). The FDD is “hot pluggable,” so you do not have to power down the notebook to connect it. -
Page 28: The Cd-Rom, Dvd-Rom, Combo Drive, Or Dvd±Rw
Chapter 2 — Getting Started The CD-ROM, DVD-ROM, Combo Drive, or DVD±RW Your computer comes with a pre-installed CD-ROM, DVD-ROM, Combo drive or DVD±RW. The CD-ROM drive is a read-only drive. It cannot be used to write data to a recordable CD. The CD-ROM drive can read data from CDs, including audio or video CDs. - Page 29 Getting Started — The CD-ROM, DVD-ROM, Combo Drive, or DVD±RW Precautions for Handling CD-ROM Discs Keep these precautions in mind when handling CD-ROM discs. • Always hold the disc by the edges; avoid touching the surface of the disc. • Use a clean, dry, cloth to remove dust, smudges, or fingerprints.
-
Page 30: Connecting The Printer
Chapter 2 — Getting Started Connecting the Printer To connect a printer to your notebook via the USB port, use the optional USB to printer adapter cable. Note: Before use, you must install the driver for the adapter cable. The PCMCIA Card Slot The PC card slot can be used as an interface between your computer and a variety of communications devices, such as network adapters, SCSI adapters, fax/modems, or provide additional data storage capacity. -
Page 31: Memory
Getting Started — Memory Memory Adding memory allows the computer to operate faster, handle more tasks simultaneously, and work more smoothly with large files. Users who increase memory demands - by adding additional programs, for example - may notice a slowdown in operating speed, and wish to increase memory. The notebook includes a memory card slot for adding additional memory. - Page 32 Chapter 2 — Getting Started Inserting a Memory Card Hold the memory card by its edges with the edge-connector side towards the slot. Hold the card at a shallow angle (about 25 degrees) and insert the edge connector into the connector slot (3). The “gold teeth” of the edge connector should no longer be visible when the card is fully inserted.
-
Page 33: The Graphics System
Getting Started — The Graphics System The Graphics System Your computer has a high-performance graphics system, which can easily handle the demands of today's multimedia computing. Screen Controls Brightness Function keys can increase or decrease the brightness of the monitor. •... - Page 34 Chapter 2 — Getting Started Windows desktop to open the desktop menu. Click Properties to open the Display Properties window. 4. In the Display Properties window, click Advanced in the Settings tab. Click the Display Modes tab. 5. Under Driver mode, you can select the appropriate options to change the display to an external monitor.
- Page 35 Getting Started — Dual Displays These options are described below In Display Combination, there are two options Standard available: VGA1 or LCD2. You can choose which device to apply as the Primary display. VGA1 is the default value for Primary if an external CRT is available.
-
Page 36: Communication Components
Chapter 2 — Getting Started Communication Components This system provides powerful communication functions, including built-in MiniPCI 802.11g and PCMCIA card slot. Fax/Modem A phone jack on the left side of the computer allows you to connect to the Internet to send and receive data. When used with fax software, it can be used as a fax. -
Page 37: Information About The Wireless Lan Button
Getting Started — Information about the Wireless LAN button Information about the Wireless LAN button Wireless LAN button Even when a Wireless LAN module has not been built-in to your computer, the Wireless LAN indicator lights and remains active when you turn on the Wireless LAN button near the power button of your computer. - Page 38 Chapter 2 — Getting Started DGT Warning Article 14 Without permission, any company, firm or user shall not alter the frequency, increase the power, or change the characteristics and functions of the original design of the certified lower power frequency electric machinery.
-
Page 40: Making Connections
Chapter 3 — Making Connections Making Connections Your computer is equipped with a full array of ports and connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers, keyboards, and mice. Refer to documentation included with individual devices for details on connecting these devices to your computer. -
Page 41: Right Side Connectors
Making Connections — Right Side Connectors 4. LAN RJ-45 Jack With the built-in Ethernet LAN combo, you can make LAN connections without installing PC cards. Connection speed is 10/100 Mbps. When using the LAN function, wrap your LAN cable around the EMI ferrite suppression box to inhibit electromagnetic interference. -
Page 42: Front Side Connectors
Chapter 3 — Making Connections Warning: Plug your modem into an analog telephone jack only. Most homes use analog lines. Do not use digital lines, such as the PBX and ISDN systems found in many offices. Digital lines may damage your modem. Front Side Connectors 1. - Page 44 Chapter 4 — System Software System Software Software List Operating System Your hard drive already contains all the software you need to operate the computer. Audio and Video Drivers These utility programs and drivers are included for the PC Card drive, the sound system, and the graphics sub-system.
-
Page 45: System Recovery
System Software — System Recovery System Recovery Before you start Your system includes two Recovery CD-ROMs. Follow the steps in the appropriate section below to reinstall the operating system, the system software, or add a new hard disk. • The factory has pre-partitioned your system's hard disk, so you may directly install the system software;... - Page 46 Chapter 4 — System Software Recovering Windows and Original Software If your Windows operating system is lost or damaged, use the Recovery CD (Windows). Enter BIOS setup. Set first boot device to “CD-ROM.” (See Chapter 6: BIOS Settings.) Put the Windows Recovery CD into the CD- ROM drive and reboot the computer.
- Page 47 System Software — System Recovery Partitioning the Hard Drive Hard drive is not partitioned. When the Microsoft Windows startup menu appears, select (2) Go to MS-DOS PROMPT. Press Enter to repartition your hard disk. At the A:\ prompt, type fdisk and press Enter. Note: If your computer is set to boot from the CD- ROM drive, “A”...
- Page 48 Chapter 4 — System Software Windows XP Reinstallation Enter BIOS setup. Set first boot device to “CD-ROM.” (See Chapter 6: BIOS Settings.) Put the Recovery CD for Windows XP Disc#1 into the CD-ROM drive and reboot the computer. When the Microsoft Windows XP Menu appears, choose option 1: Recovery CD for Windows XP.
-
Page 50: Power Management Power Management
Chapter 5 — Power Management Power Management Battery Calibration The first time you use a battery, you should calibrate it. The calibration process empties and charges the battery one time. This allows the Windows battery gauge to accurately monitor battery status. To calibrate a battery, follow these steps: 1. - Page 51 Power Management — Power Management Monitoring Battery Power There are two ways to monitor how much power the battery has left. 1. Click Start / Settings / Control Panel / Power Options ; then click Power Meter. 2. Moving the cursor to the battery icon on the taskbar is the simplest way to check on battery...
-
Page 52: Power Saving Modes
Chapter 5 — Power Management • Turn off or suspend the computer and replace the discharged battery with a charged battery (See Battery Charging below). Do not restart the computer until you have connected to an AC adapter, or replaced the discharged battery with a charged battery. Battery Charging When you use the AC adapter to connect your Notebook to a power outlet, the internal battery will automatically begin to recharge. - Page 53 Power Management — Power Saving Modes notebook standby, hibernate, or you can power off the computer altogether. Standby All devices are powered up and in suspend mode . Suspend to Disk is similar to turning off the computer, Hibernate except that the current state of the computer is copied to the hard disk as a special file.
-
Page 54: Power Saving Tips
Chapter 5 — Power Management Using the BIOS Utility for Power Management With Windows running in ACPI mode, power can be controlled through the Power Management dialog box only. With operating systems that use ACPI power management, BIOS power settings have no effect. -
Page 55: Heat Considerations
Power Management — Heat Considerations Changing the Battery Change the main battery pack as follows: 1. Turn off the computer. 2. Close the screen cover and turn the computer over. 3. Slide the side battery latch (1) away from the battery. Continue to hold it until the battery is removed. - Page 56 Chapter 5 — Power Management...
-
Page 58: Using The Bios Setup Utility
Chapter 6 — Using the BIOS Setup Utility Using the BIOS Setup Utility Your notebook has a BIOS setup utility which allows you to configure important system settings, including settings for various optional functions of the computer. This chapter explains how to use the BIOS setup utility. -
Page 59: Navigating And Entering Information In Bios
Using the BIOS Setup Utility — Navigating and Entering Information in BIOS Navigating and Entering Information in BIOS Use the following keys to move between fields and to enter information: Function Press Del to start the BIOS utility after turning on the computer. Press Esc to exit any section. -
Page 60: The Main Menu
Chapter 6 — Using the BIOS Setup Utility The Main Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit System Overview Use [ENTER] , [TAB] Or [SHIFT-TAB] to select a field. AMIBIOS Version : RC.0 Use [+] or [-] to Configure system Time Processor... -
Page 61: Advanced Menu
Using the BIOS Setup Utility — UAdvanced Menu Advanced Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Advanced Setting Enables support for Legacy USB. AUTO option disables legacy support if no Auto DIM function USB devices are [Enable] connected. System can boot from LAN [Enable] Legacy USB Support [Enable]... -
Page 62: Boot Menu
Chapter 6 — Using the BIOS Setup Utility Boot Menu BIOS SETUP UTILITY Main Advanced Security Exit Boot Boot Device [Removable Dev.] Specifies the boot sequence from the Boot Device [CD/DVD] available devices. Boot Device [HDD] Boot Device [Network] A device enclosed in parenthesis has been disabled in the corresponding type... -
Page 63: Security Menu
Using the BIOS Setup Utility — USecurity Menu Security Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Security Settings Install or Change the password . Supervisor Password : Not Installed User Password : Not Installed Change Supervisor Password Change User Password ←... -
Page 64: Change Supervisor Password
Chapter 6 — Using the BIOS Setup Utility Change Supervisor Password: Enter new password: Supervisor Password Indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays. Change Supervisor Password Select Change Supervisor Password from the Security Setup menu and press <Enter>. - Page 65 Using the BIOS Setup Utility — U Exit Menu Enter New Password: appears. Type the password and press <Enter>. The screen does not display the characters entered. Retype the password as prompted and press <Enter>. If the password confirmation is incorrect, an error message appears.
-
Page 66: Exit Menu
Chapter 6 — Using the BIOS Setup Utility Exit Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Exit Options Exit system setup After saving the changes. Save Changes and Exit Discard changes and Exit F10 key can be used Discard Changes for this operation. -
Page 68: Frequently Asked Questions
Appendix A — Frequently Asked Questions Frequently Asked Questions Q: My screen seems to time out too quickly. I have to constantly hit a key or move the mouse in order to bring it back. How can I adjust the screen time-out? This is part of Windows Power Management. - Page 69 Appendix A — Frequently Asked Questions Q: There is feedback noise coming from my speakers. What can I Double click on the Speaker icon on the task bar. Then, under Microphone Balance, check the Mute box. Q: Because of a software problem, I was unable to shut down power normally.
- Page 70 Appendix A — Frequently Asked Questions 3. Select “Save Settings and Exit”. When you see the following prompt, choose <Y> and then press <Enter> to restart your computer. Save current settings and exit (y/n)? Y 4. When you see the following sentence “FAN never Learned. Do it in BIOS Setup.
-
Page 72: Appendix Bstatements
Appendix B — Statements Statements Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 73 Appendix B — Statements About The Modem This equipment complies with Part 68 of FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment.
- Page 74 Appendix B — Statements The Telephone Consumer Protection Act of 1991 marks it unlawful for any person to use a computer or other electronic device, including fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending...
-
Page 75: European Notice
Appendix B — Statements • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference this device must accept any interference received, including... -
Page 76: Ul Caution
Appendix B — Statements UL CAUTION To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord. IMPORTANT SAFETY INSTRUCTIONS When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury to persons, including the following: Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a... -
Page 77: Battery Disposal
Appendix B — Statements certified connector assembly (telephone extension cord). The customer should be aware that compliance with the above conditions may not prevent degradation of service in some situations. Repairs to certified equipment should be made by an authorized Canadian maintenance facility designated by the supplier. -
Page 78: Class 1 Laser Product
Appendix B — Statements CLASS 1 LASER PRODUCT LASERSCHUTZKLASSE 1 PRODUKT TO EN60825 CAUTION: THIS APPLIANCE CONTAINS A LASER SYSTEM AND IS CLASSIFIED AS A "CLASS 1 LASER PRODUCT.” TO USE THIS MODEL PROPERLY, READ INSTRUCTION MANUAL CAREFULLY KEEP THIS MANUAL FUTURE REFERENCE.
