- Page 1 AdderLink X-Series Dual Video Transmitter ...
-
Page 2: Table Of Contents
Contents Special configuration Welcome Password override ...............8 ‘One-in, two-out’ mode ............2 Flash upgrade ................8 ‘Two-in, two-out’ mode ............2 Supplied items .................2 Stage A - Download the upgrade files ........8 Stage B - Create a startup diskette ........9 Installation and operation Stage C –... -
Page 3: One-In, Two-Out' Mode
Welcome Supplied items Thank you for choosing the AdderLink X-Series Dual Video Transmitter. Used in Connection from the primary video conjunction with two remote receivers, this compact unit allows you to control Connection from controller within the secondary video the computer (or monitor) one computer from two separate locations. -
Page 4: Installation And Operation
ON: Set transparent mode. Use this setting if the Dual Video Transmitter is to be used with KVM switches that are not manufactured by Adder Technology. OFF: Normal operation Cascaded KVM switches often use special signals to set or identify ON: Transparent mode conditions. -
Page 5: Stage B - Mounting The Module - Desk Or Rack
Stage B - Mounting the module – desk or rack Stage C – Connections The Dual Video Transmitter can be situated on a desk (or floor) or alternatively, Most connections to the Dual Video Transmitter are common to both of the for larger installations, mounted within an optional rack mount chassis. - Page 6 Insert the connectors from computer has a 5-pin DIN (AT) keyboard the two twisted pair cables connection, use an optional ‘PS/2 to AT’ into the connectors front converter (Adder Technology part code: end of the module. VSA2). Note: In the ‘Two-in, Connection to secondary two-out’...
-
Page 7: Connections At The Remote Receivers
The instructions given here relate specifically to the AdderLink X- Series receivers, although the following Adder Technology receivers could also 2 Attach the other end of the secondary be used in conjunction with the Dual Video Transmitter:... -
Page 8: Operation
Operation ‘Two-in, two-out’ mode connections Secondary Power and activity indicator reciever with video monitor On the front panel of the Dual Video only attached Transmitter a small recessed indicator provides confirmation of power and activity, as follows: • Constant red - power applied, no Primary receiver Primary and communication activity. -
Page 9: Special Configuration
As part of the continual development and improvement process across the range (such as passwords, hotkey controls, etc.) are made at the receiver units, where of Adder products, software upgrades are occasionally made available. The Dual the keyboards, video monitors and mice are connected. There are, however, two Video Transmitter’s internal flash memory and Adder’s unique keyboard-link... -
Page 10: Stage B - Create A Startup Diskette
Stage B - Create a startup diskette Stage C – Reconfigure the connections and begin For this stage you will need a floppy diskette that is either blank or has 1 On the computer from which you will run the upgrade, ensure that its BIOS 3½... -
Page 11: Stage D - Return The Connections To Their Usual State
Stage D - Return the connections to their usual state Once the upgrade process has been completed, perform the following to return the system to its previous state. 1 Switch off the computer and Dual Video Transmitter (if a power supply is connected). -
Page 12: Further Information
(each of which is fed along separate twisted pair sets) to overcome most screen image problems. • Adder Technology website – www.adder.com In ‘two-in, two-out’ mode no video image is received on the second Check the Support section of our website for the latest solutions and driver screen. -
Page 13: Other Products In The X-Series Range
If the product should fail to operate correctly in normal use during the warranty period, Adder will replace or repair it free of charge. No liability can be accepted for damage due to misuse or circumstances outside Adder’s control. -
Page 14: Radio Frequency Energy
Radio Frequency Energy A Category 5 (or better) twisted pair cable must be used to connect the AdderLink units in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. All other interface cables used with this equipment must be shielded in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. - Page 15 © 2007 Adder Technology Limited All trademarks are acknowledged. Release 1.0d July 2007 Part No. ADD0048/1 Adder Technology Limited, Adder Corporation, Technology House, 29 Water Street, Trafalgar Way, Newburyport, Cambridge, CB3 8SQ, MA 01950, United Kingdom United States of America...
