AC supply. Should this not be the case, do not proceed – but contact your dealer. As a general rule, you should not make any connections to the 519, or to any other component in your system, whilst the AC power supply is con- nected and switched on.
Installation Connections There are five types of connection that may be made to the 519: power Laser Disc RF electrical digital audio optical digital audio communications. Digital audio and RF connections need to be made to other components in your system. Communication connections have to be made to most of the other Meridian components in your system in order for them to act as one system.
Checking Before turning on the power, check once again that you have made all the connections correctly. The 519 is designed to be left connected to AC power at all times and can be run continuously. Switching on The power switch is located directly next to the power inlet on the rear of the 519.
5 Volt signal fit jumper 1. Jumper 2 In normal use the 519 will switch to regular digital audio if it is unable to demodulate AC-3. This allows both AC-3 encoded and non AC-3 encoded discs to be replayed with no change of settings by the user.
2. The power switch on the rear panel of the 519 is turned on. If the yellow light will still not illuminate, check any fuses in your power supply and the fuse in the inlet of the 519. If these are all intact, contact your dealer.
In the unlikely event that your 519 fails to function correctly, it should be returned, in its original packing, to your Meridian dealer. In case of diffi- culty within the UK or USA please contact our sales and service offices shown on page 2.
Contents, 2 Help!, 7 Installation, 3 Introduction, 3 Jumpers, 6 Opening the case, 6 Power switch, 5 Radio interference, 8 Repacking 519. see Unpacking Service where to get, 8 Specifications, 9 Switching on, 5 Unpacking 519, 3 519 User Guide...
