P.O. Box 791 • Traveler s Rest, SC 29690 • Phone: (864) 834-7212 • Fax: (864) 834-5127
Ser vice/Replacement Par ts: (800) 845-4141 • www.titanindustrial.net
Commercial Dual Tank Compressor
The Emission Control System for this generator is warranted for standards set by the Environment Protection Agency.
It is extremely important to read and understand the entire contents of this
Owner's Manual for the Titan Industrial Commercial Model TAC-2T before at-
tempting to operate the compressor. This is a gasoline engine powered, com-
mercial strength, dual tank air compressor. The gasoline engine and the com-
pressor are both potentially hazardous and could cause physical injury or even
death if improperly used.
WARNING!
TAC2T Titan Motor Manual
OWNER'S MANUAL
MODEL TAC-2T
IMPORTANT!
Do Not Operate Equipment until reading and
understanding Owner's Manual!
1
®
Revision # 030428A
Advertisement
Table of Contents
Related Manuals for Titan TAC-2T
Summary of Contents for Titan TAC-2T
- Page 1 IMPORTANT! It is extremely important to read and understand the entire contents of this Owner’s Manual for the Titan Industrial Commercial Model TAC-2T before at- tempting to operate the compressor. This is a gasoline engine powered, com- mercial strength, dual tank air compressor. The gasoline engine and the com- pressor are both potentially hazardous and could cause physical injury or even death if improperly used.
-
Page 2: Saftey Guidelines
SAFTEY GUIDELINES The information in this manual is provided for your saftey and to protect your equipment. It is very important to read and understand the contents of this manual before attempting to operate this equipment. Please observe the following symbols to help recognize this information. DANGER This symbol indicates extremely hazardous situations that could cause serious injury or death! WARNING... -
Page 3: General Safety
GENERAL SAFETY The following safety precautions must be observed at all times because the compressor and compo- nents make up a high pressure system. A. Follow all codes for the safe operation of this equipment, both local and federal (United States Occu- pational Safety and Health - OSHA). -
Page 4: Maintenance Schedule
SAFTEY GUIDELINES (continued) UNPACKING WARNING WARNING Your compressor comes equipped with a guard Inspect your air compressor carefully for any dam- over the drive wheel and belt assembly. Never age that may have occurred during transit. Be sure attempt to operator this unit if the guard is dam- to inspect and tighten all bolts, screws, and fittings aged or removed. -
Page 5: Assembly And Operation
DISCLAIMER STARTING THE ENGINE (see page 9) TITAN INDUSTRIAL, HEREBY DISCLAIMS ANY RESPONSIBILITY OF ANY LIABILITY WHATSO- EVER FOR ANY LOSS, PERSONAL INJURY, OR Maintenance Shedule (see page4) DAMAGE RESULTING FROM BREATHING AIR FROM THE COMPRESSOR. -
Page 6: Maintenance
MAINTENANCE DRIVE BELT WARNING Belts tend to stretch as a result of normal use. The Release all pressure from the system before belt will deflect about 1/2 inch with five pounds of attempting to perform any maintenance! pressure applied midway between the engine pulley and the pump (see below). -
Page 7: Troubleshooting
TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Low Discharge Pressure 1. Air leaks 1. Listen for escaping air. Apply soap solution to fittings if bubbles appear. 2. Leaking Valves 2. Remove defective parts and reassemble. Be sure to replace the head gasket each time head is removed. 3. -
Page 16: Engine Specifications
Titan Industrial Industrial Air Compressor TAC-2T Engine Engine Type Titan Horse Power 6.0HP Fuel Low Octane Gas Fuel Capacity 2.3 Gallons Ignition System Pull Start Dimensions (inches) L-44" W-19 1/2" H-25" Net W eight 160 LBS W arranty 1 Year...
