iXtreamer Dock Guide
Ver.2.6.0 Firmware

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iXtreamer and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Xtreamer iXtreamer

Summary of Contents for Xtreamer iXtreamer

  • Page 1 Dock Guide Ver.2.6.0 Firmware...

  • Page 2: Dock Menu Section

    Major Function DOCK menu section Currently only iPod Touch and iPhone running iOS 4.0 or above are supported. For more information please refer to the list of compatible devices.

  • Page 3: Compatibility List

    Major Function Compatibility list In further firmware upgrades we will improve the Docking function. Control with Control Apple Product Rechargeable without TV iPad iPhone 4 iPhone 3GS iPhone 3G iPhone iPod Touch 4th Generation iPod Touch 3th Generation iPod Touch 2th Generation iPod Touch 1th Generation iPod Classic 120GB 160GB (2009) iPod Classic 160GB (2007)
  • Page 4 Nano 4th Generation(video) iPod Nano 3rd Generation (video) - Control on TV You can view iPad/iPhone/iPod media files on TV and control them by the iXtreamer remote control - Control without TV The iPad/iPhone/iPod can be controlled by the remote control but without the TV output.
  • Page 5 Controlling iXtreamer Dock Remote control functions for DOCK...
  • Page 6 Remote Control button for iPod POWER To turn on/ off power mode DOCK Changes to iPod (iPad) control mode, one more click leads to iXtreamer control mode. iPod Shifts iPod mode (Currently, this function is supported for iPod touch and iPhone running MODE over iOS 4.0)

  • Page 7: Docking The Iphone (Ipad/Ipod)

    Docking Docking the iPhone (iPad/iPod) Slide the top cover If docking iPad take out the back support panel. Put in the top hole of iXtreamer top side Docking the iPhone/iPod/iPad...
  • Page 8 Docking Docking the iPhone (iPad/iPod) The Docking Guide is used for iPhones 3GS only and should be removed when using iPhone 4 or iPad. Please remove a protective cover from your iPad before docking it.
  • Page 9 Docking After docking your iPhone (iPad/iPod) pay attention to the LED status. Normal : Green LED Normal: Green LED blinking If a problem occurs take the device out and reconnect. When the device is recognized the following screen will appear on TV. If the player starts with an iPhone already docked press the DOCK button.
  • Page 10 Using Dock Return to the Media Library To exit Dock menu Press DOCK button Return to the Main Menu Press the button any time to access Dock menu.

  • Page 11: Return To The Dock Mode

    Using Dock Return to the DOCK mode To go to the main DOCK menu. Press HOME button. Home button will always return you to main screen of the Dock menu.

  • Page 12: Outdated Ipod Version (Not Ios)

    Outdated iPod version (Not iOS) The following screen will appear if the device is not fully supported by the iXtreamer. If your iPod is not running iOS then the files can only be browsed on its screen and not on a TV.
  • Page 13 Using Dock iOS 4.x and the latest Apple devices. The following screen appears when an Apple device is docked. Use video menu Open the video list of iTunes or Podcast on iPod. If the required file is not listed on iTunes it can't be opened this way. Please return to the Dock Main Menu.
  • Page 14 Using Dock (Info) button during playback to see the movie file name. Press Home or Home button on the to return to the Dock main menu screen. Dock accepts resolution up to 480i Out put screen ratio: 4:3 ratio play 16:9 ratio play Note: While playing 4:3 ratio movie files on a 16:9 TV please change the ratio to avoid "black borders"...

  • Page 15: How To Watch A Video Recorded By Iphone

    Using Dock How to watch a video recorded by iPhone To watch a video file recorded by iPhone, access the Photos on your iPhone screen to find it. 1 . Dock the iPhone. 2. Select the photos menu in Dock. The following screen will appear.

  • Page 16: Watching Video

    Watching Video How to watch a video recorded by iPhone Run the Photos application on your iPhone Access the Photos icon in iPhone Touch the Camera Roll menu Choose a recorded video Touch the paly button to start playback...

  • Page 17: Listening To Audio Files

    Listening to Audio Files DOCK Audio Section Enter DOCK menu audio section Select a category in the iPod audio screen Enter the category...
  • Page 18 Listening to Audio Files Audio Menu in DOCK Use up/down keys to navigate Select an album. Or an audio file. Play the file.

  • Page 19: Audio Menu In Dock

    Listening to Audio Files Audio Menu in DOCK Continuous play Button Icon Play mode Description Sequential Sequential play Random Random play SHUFFLE Button Icon Repeat mode Description All Repeat Repeat all files. 1 Repeat One files only. Loop Repeat Repeat files continuously. REPEAT...

  • Page 20: Accepting A Call While Playing An Audio File On Ixtreamer

    Accepting a Call Accepting a call while playing an audio file on iXtreamer When someone calls your iPhone while it is used for audio playback you will be alerted on the TV screen. Audio playback screen Call alert and caller information is displayed on the TV screen.

  • Page 21: Dock Photos Menu

    Watching Photos DOCK Photos Menu You can access the images stored in iTunes and photos taken by your iPod\iPad\iPhone. Select photos menu in Dock. The above message will appear on the TV screen.
  • Page 22 Watching Photos DOCK Photos Menu Navigate to a required folder . Press the Photo icon on your iPhone. Touch the ▶ button and start the slideshow. Select a photo.
  • Page 23 Watching Photos DOCK Photos Menu Once the slideshow is started and is seen on your TV, press (ENTER) button to close the information window. buttons to navigate. buttons stop and resume the slide show. The Slideshow function uses the settings of your iPhone\iPod.
  • Page 24 Background Music for Slideshows Using Audio and Photos simultaneously. Enjoy a Slideshow with background music. 1. First, choose and play an audio file. 2. Press Home button to return to the DOCK main screen. 3. Select Photos menu and use your iPhone to start a Slideshow.

  • Page 25: Dock Firmware Upgrade

    Dock Firmware Upgrade DOCK firmware upgrade 3. Select DOC firmware. 4. Read the guidance of R screen and press OK to upgrade...
  • Page 26 Dock Firmware Upgrade DOCK firmware upgrade 5. Upgrade is in progress. DOCK upgrading lasts 30seconds~1minute. System reboots and upgrading will be completed.
  • Page 27 Links Xtreamer4Dummies Dock video guide iXtreamer Forum Section – you will need to register on the forum iXtreamer in the Xtreamer Knowledge Base...
