Local Setup

entry ―Local Setup‖ interface, setup local configuration, including: language, stream type, transmit
Click
protocol, circular channel quantity, local save route etc.
1. Language selection: provide local IE web language switch and display function.
2. Stream type: select the transmit model, including main stream, sub stream (net transmit code type). The main
stream setup in the ―Advance Setup-Transfer‖.
3. Transmit protocol: provide TCP, UDP transmit setup.
4. Circular monitor setup: Setup circular monitor display. Including: image number display at once, image stay
time in circular monitor.
5. Local storage path setup: choose local image snap, local record save route.
6. Local surveillance and playback support P/N, adjust the video compression according to the video
headstream itself.

Advance Setup

entry ―Advance Setup‖ interface. These configurations are corresponding to the ―Advance Setup‖
Click
in the menu in DVRs.
1. System configuration: take reference at ―Basic Parameter Setup‖ Section6 ChapterⅣ.
2. Channel configuration: take reference at ―Display Setup‖ Section13 ChapterⅣ.
3. Network Parameters: including startup DHCP, IP address, Subnet mask, Gateway, Net card speed, ports, host
MAC sits get, PPPoE setup, http port setup and DDNS setup. Take reference at ―Network Setup‖ Section10
ChapterⅣ.
Http port： when use the IE view browser, input the port behind the IP address, such as : IP is192.168.2.3， http
port is 998，input the IE addresshttp://192.168.2.3:998;
4. Net transmit setup: setup Sub stream (Net transmit stream) configuration. Take reference at ―Net Transfer
Parameter Setup‖ Section11 ChapterⅣ.
5. PTZ configuration: Take reference at ―PTZ Setup‖ Section14 ChapterⅣ.
6. User info.: provide remote add or change host name, password, and display all current user name. Take
reference at ―User Management‖ Section12 ChapterⅣ.
73
