G5912
Product features and decorations may vary from picture above.
WARNING
IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE.
Please read these instructions before assembly and use of this product.
Adult assembly is required.
Tool needed for battery installation: Phillips Screwdriver (not included).
Requires four LR14 alkaline batteries for operation (not included).
Weight Limit: 9 kg (20 lbs).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G5912 and is the answer not in the manual?

Questions and answers

Related Manuals for Fisher-Price G5912

Summary of Contents for Fisher-Price G5912

  • Page 1 G5912 Product features and decorations may vary from picture above. WARNING IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. Please read these instructions before assembly and use of this product. Adult assembly is required. Tool needed for battery installation: Phillips Screwdriver (not included).

  • Page 2: Warning And Caution

    Warning and Caution WARNING To prevent serious injury or death from falls and being strangled in the restraint system: - Always use the restraint system. - Not recommended for children who can sit up by themselves (6 months approximately, until 9 kg, 20 lbs).
  • Page 3 Parts Seat Back Tube Frame Lower Swing Arm Assembly (with Restraint System) 3 Link Toys Front Tube 2 Frame Tubes #6 x 1.9 cm Screws - 4 NOTE: Tighten and loosen all screws with a Phillips screwdriver. Do not over-tighten the screws. Shown Actual Size...
  • Page 4 IMPORTANT! Before assembly, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Mattel for replacement parts and instructions if needed. Never substitute parts. Upper Frame Tube •...
  • Page 5 Lower Frame Tubes • Pull the front tube to be sure it is secure to each lower frame tube. Assembly Press Button on Upper Frame Tube Pull Front Tube • While pressing the buttons on the upper frame tubes, insert them into the holes in the underside of the frame. •...
  • Page 6 Upper Frame Frame Tube • Check to be sure the upper frame tubes are secure in the frame. If you can remove the upper frame tubes from the frame, you have not properly inserted the tubes into the frame. Remove the upper frame tubes from the frame and repeat Assembly step 4.
  • Page 7 • Insert two #6 x 1.9 cm screws through the upper swing arm and into the lower swing arm. Tighten the screws. Assembly #6 x 1.9 cm Screws - 4 Shown Actual Size • Position the seat back tube so that it curves toward the back of the swing.
  • Page 8 Pad Top Pocket Pad Lower Pocket Seat Back Tube • Fit the top pocket on the pad over the seat back tube • Lift the seat bottom tube and fit the lower pocket on the pad over the seat bottom tube Assembly Slot Seat Bottom Tube...

  • Page 9: Battery Installation

    Hint: We recommend using alkaline batteries for longer battery life. 1.5V x 4 LR14 SHOWN ACTUAL SIZE Battery Compartment Door Battery Holder • Locate the battery compartment door on the frame. • Loosen the screws in the battery compartment door. •...

  • Page 10: Battery Safety Information

    Battery Safety Information Batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).

  • Page 11: Securing Your Child

    Securing Your Child Restraint Waist Belt • Place your child in the seat. Position the crotch belt between your child’s legs. • Fasten the waist belts to the crotch belt. Make sure you hear a “click” on both sides. • Check to be sure the restraint system is securely attached by pulling it away from your child.
  • Page 12 Set-Up & Use Power Dial Starting the Swing Power Dial • Turn the power dial to any of eight settings. • Give the seat a light push to start the swinging motion. Adjust the swing power dial to the desired swing motion setting. Hint: As with most battery-powered swings, a heavier child will reduce the amount of swinging motion on all settings.
  • Page 13 Hint: Your baby can enjoy lights and music with or without swinging. Baby Activated Lights and Music Switch • Slide the lights and music switch to: When baby pulls either toy on the arch, one tune plays along with twinkling lights. On this setting, six tunes (approximately 10 minutes) play along with dancing lights.
  • Page 14 Set-Up & Use 3 Link Toys • Fit the link toys to either of the hanging toys on the swing. Room-to-Room Portability WARNING • To prevent serious injury or death from falls and being strangled in the restraint system, always use the restraint system.
  • Page 15 Take Along Lift Seat Back Lift Seat Bottom Seat Back Press Tabs • Tip the swing backwards with the seat back down. • Press both tabs on the frame at the same time to release the • Lift the seat back and seat bottom together. frame base.
  • Page 16 • Place the swing on a non-elevated, flat surface. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. © 2004 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. Care •...
