- Page 1 Model T4444 Model M7596 www.fi sher-price.com...
-
Page 2: Consumer Information
WARNING To avoid serious injury: • Adult supervision required. • Never use near cars and other motor vehicles, near streets, steps, slopeddriveways, hills, roadways, alleys, swimming pools or other bodies of water. • Always wear shoes. • Never allow more than one rider. CAUTION This product contains small parts in its unassembled state. - Page 3 Assembled Parts Assembled Parts Note: Label sheet not shown. Rear Axle 2 Front Axles Roof 2 Axle Mounts 4 Wheels 4 Hubcaps Sounds and Lights Box Retainer Cup Holder 4 Roof Posts 2 Rear Bushings 4 Wheel Covers Steering Wheel 2 Front Bushings 2 Cap Nut Covers ”...
-
Page 4: Battery Installation
Battery Installation Battery Installation 1,5V x 3 “AAA” (LR03) • Locate the battery compartment on the bottom of the sounds and lights box. • Loosen the screw in the battery compartment door. Remove the battery compartment door. • Insert three “AAA” (LR03) alkaline batteries. Hint: We recommend using alkaline batteries for longer battery life. -
Page 5: Bottom View
Sounds Sounds and Lights Box Lights Retainer Frame BOTTOM VIEW • Turn the frame on its side. • Fit the sounds and lights box onto the dash on the topside of the vehicle. • Then, fit the retainer over the battery compartment door on the underside of the frame. -
Page 6: Front View
Front Axle FRONT VIEW • First, slide a ” washer onto the front axle. 16 16 • Then, insert the front axle labeled 2 up through the hole in the front end of the frame also labeled 2. Rear Bushing Hubcap Rear Axle •... - Page 7 • Fit a cap nut cover over each cap nut on the front end of the frame. Push to “snap” in place. Rear Bu Rear Bushing Wheel Hubcap • Slide a rear bushing, long end first, onto the rear axle. •...
- Page 8 Cap Nut Cover • Fit a cap nut cover onto each rear wheel and push to “snap” in place. • Fit the roof assembly onto the frame. Push near each post to “snap” in place. Hint: The roof assembly is designed to only fit one way. If it does not seem to fit turn it around and try again.
- Page 9 • Fit the key into the hole in the dash. Push to “snap” in place. Assembly Assembly • Turn the roof upside down on a flat surface. • Fit the four posts into the roof and push to “snap” in place. Hint: Each post is labeled (1, 2, 3 or 4).
-
Page 10: Back View
(T4444 only) (M7596 Only) FRONT VIEW Decoration Decoration • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. • Place the labels exactly as shown in the illustrations. For best results, avoid repositioning a label once it has been applied to the vehicle. - Page 11 Press the horn on the steering wheel for fun car songs and lights! Real working door! 11 11...
-
Page 12: Consumer Assistance
Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2010 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. PRINTED IN MEXICO PRINTED IN MEXICO CONSUMER ASSISTANCE 1-800-432-5437 (US & Canada) 1300 135 312 (Australia) Fisher-Price, Inc., 636 Girard Avenue, East Aurora, NY 14052.
