Sonic Impact Technologies IP-P22 User Manual

Portable speaker system for ipod
Hide thumbs
Table of Contents

Advertisement

Quick Links

Ii

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP-P22 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sonic Impact Technologies IP-P22

Summary of Contents for Sonic Impact Technologies IP-P22

  • Page 2: This Class B Digital Apparatus Complies With Canadian Ices-003

    Changes or modifications not expressly approved by Sonic Impact could void the user’s authority to operate the equipment. THIS CLASS B DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003. Sonic Impact Technologies LLC ©Sonic Impact Technologies LLC iP-22 is a trademark of Sonic...
  • Page 3 Important operating and maintenance (servicing) instructions. 。 CAUTION: TO PREVENT ELECTRONIC SHOCK DO NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION CORD.RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS I-FUSION TO RAIN OR MOISTURE IMPORTANT iP-22 SAFETY INSTRUCTIONS Read instructions --All Safety and operating instructions should be read before the iP-22 is used.

  • Page 4: One-Year Limited Warranty

    ONE-YEAR LIMITED WARRANTY Sonic Impact Technologies warranties that all of its products are free from defects in material and workmanship in the course of normal and reasonable use for a term of one year from the date of purchase.

  • Page 5: Packing Content

    PACKING CONTENT Manual iP-22 System AC Power Stereo iPod® Adapter Quick Adapter Cable Sleeves Connect Instruction ·iP-22 portable speaker case ·9V 1.2A AC power adapter ·Ø3.5 stereo cable ·iPod mini、iPod 3G 10GB15GB/iPod 4G 20GB/iPod PHOTO 30GB、iPod 3G 30GB/ iPod 4G 40GB/ iPod PHOTO 40GB60GB adapter sleeves ·User manual ·Quick connect instructions...
  • Page 6 1、 Compartment Lock 2、 iPod®30 Pin Docking Station 3、 Speaker Driver Unit 4、 Port tube 5、 Battery compartment 6、 Input Jacks 7、 Rubber...
  • Page 7 8、 Belt clip 9、 iPod® Adapter sleeve 10、 iPod®30 Pin Docking Station 11、 Power On/Off and LED LOCATING YOUR iP-22 SYSTEM Best to position the iP-22 system on a stable, level surface within 1-2.5 meter from the listener. The iP-22 system may be placed near video displays, such as TV sets and computer monitors, without causing distortion to the image.

  • Page 8: Start Playing

    The iP-22 system operates using 4AA batteries, place 4AA’s into the battery compartment (see battery replacement instructions). Your iP-22 speaker system is now ready to operate. Remarks: The output of using power adapter is twice as great as the output of using battery When docked, your iPod will also recharge when using the AC adapter.
  • Page 9 to green and glitter. The LED will automatically stop glittering when an audio signal is detected and the iP-22 system will automatically power on. Power consumption will be reduced in this “standby” mode, but we suggest that you set the power switch to the “OFF” to shut down the iP-22 system completely when not in use for an extended period of time to save battery life.

  • Page 10: Specifications

    SPECIFICATIONS The excellent sound quality of the iP-22 comes from our highly professional design, which includes a customized Hi-Fi Neodymium driver, digital amp, and the latest digital equalizer circuitry...

  • Page 11: Troubleshooting

    Power Output ：1W*2 （AA battery power supply ） 2W*2 （power adapter supply） Speaker channel: 2 channel Impedance： 12Ω Frequency response ：180Hz-- 20KHz S/N ratio： 85dB±2 (0.5M & 1W) Driver unit：neodymium- magnetic drivers 1.25” × 2 TROUBLE SHOOTING SYMPTOMS POSSIBLE PROBLEM SOLUTION System is not switched on 。...
  • Page 12 Verify the power switch is at the “ON” position , and the indicator is illuminated.。 Volume is set too low。 Press the “+” button to increase the volume。 Check volume level on alternate audio source device and set it at mid-level。 iPod is not seated into the docking Remove iPod and re-seat it in the docking station。...
  • Page 13 Volume level on iP-22 system is Sound is distorted Decrease the volume set too high. Sound source is distorted. WAV and MID files are often of poor quality; therefore distortion and noise are easily noticed with high-powered speakers. Try a different audio source such as a music CD Sound is distorted Volume level in operating system...

This manual is also suitable for:

Ip-22
