MF DIGITAL NeoLogica DICOMBurner User Manual

Version 3
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DICOMBurner, version 3
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NeoLogica DICOMBurner and is the answer not in the manual?

Questions and answers

Related Manuals for MF DIGITAL NeoLogica DICOMBurner

Summary of Contents for MF DIGITAL NeoLogica DICOMBurner

  • Page 1 DICOMBurner, version 3 User Manual...

  • Page 2: Table Of Contents

    DICOMBurner: User Manual [DB-UM-3 – Rev B] Table of Contents ABBREVIATIONS..............................5 INDICATIONS FOR USE ............................6 INTRODUCTION ..............................7 INTERFACE ARCHITECTURE AND MAIN DIALOG..................8 CREATING A CD/DVD OF DICOM FILES ...................... 12 ............................13 URN LAST PATIENT – O CD/DVD ..................

  • Page 3: Dicomburner: User Manual [Db-Um-3 – Rev B

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.2.2 Series-level search ............................ 34 7.2.3 Instance-level search ..........................35 DELETING DICOM FILES..........................36 ............................36 TUDY LEVEL SEARCH ............................37 ERIES LEVEL SEARCH ..........................38 NSTANCE LEVEL SEARCH ............................39 ELETE FILES STEP BACKUP DICOM FILES AND DATABASE......................
  • Page 4 DICOMBurner: User Manual [DB-UM-3 – Rev B]...

  • Page 5: Abbreviations

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 1 Abbreviations Abbreviation Description Application Entity Bitmap DICOM Digital Imaging and COmmunications in Medicine DIMSE DICOM Message Service Element Dynamic Link Library Dots Per Inch Graphical User Interface Integrated Color Management Identifier JPEG Joint Picture Experts Group Local Area Network Personal Computer...

  • Page 6: Indications For Use

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 2 Indications for use The DICOMBurner software allows receiving and storing DICOM files on a database residing on a networked PC. In addition DICOMBurner allows burning DICOM files on one or more CDs or DVDs, with an embedded autorunning viewer.

  • Page 7: Introduction

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 3 Introduction NeoLogica DICOMBurner is a mini-PACS system that allows a complete interaction with a DICOM Network. It’s able to import/export DICOM files coming from digital modalities or local disks. It has advanced CD/DVD production capabilities.

  • Page 8: Interface Architecture And Main Dialog

    DICOMBurner: User Manual [DB-UM-3 – Rev B] This document will explain the meaning of the available configuration parameters and all the functionalities available from the DICOMBurner GUI. 4 Interface architecture and main dialog The DICOMBurner application runs in background, with an icon in the system tray area of Windows. When you start the application, a balloon tooltip for the system tray icon is displayed for some seconds.
  • Page 9 DICOMBurner: User Manual [DB-UM-3 – Rev B] DICOMBurner’s main dialog box In DICOMBurner’s main dialog box, the following information is provided: Store SCP Server: • Current server status: tells if the connection server is started or stopped. The connection server must be started if client connections and associations from Storage SCU have to be accepted.
  • Page 10 DICOMBurner: User Manual [DB-UM-3 – Rev B] General Statistics: • Max concurrent associations: the maximum number of concurrent DICOM associations accepted by DICOMBurner. This value may be changed in the “Settings… DICOM Configuration” section. Active: the number of DICOM associations currently active. This value gives an indication of the current workload.
  • Page 11 DICOMBurner: User Manual [DB-UM-3 – Rev B] • Start: starts DICOMBurner’s connection server. This allows accepting connections and DICOM association requests from DICOM Storage SCU’s. Once the server is started, the “Settings” button is disabled. • Stop: stops DICOMBurner’s connection server. Once the server is stopped, it is no longer possible to accept connections and association requests from DICOM Storage SCUs.

  • Page 12: Creating A Cd/Dvd Of Dicom Files

    DICOMBurner: User Manual [DB-UM-3 – Rev B] The DICOMBurner tray menu 5 Creating a CD/DVD of DICOM files DICOMBurner allows creating DICOM-compliant CDs or DVDs containing DICOM files. The DICOM files to be stored on CD or DVD can be selected by the user through intuitive wizard-based procedures. The produced media also contains an autorunning DICOM Viewer which allows viewing the medical images on a PC.

  • Page 13: Burn Last Patient

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.1 Burn last patient By selecting the “Burn last patient” option, you are able to burn all the DICOM files related to the patient the last received and stored image belongs to (i.e. the “last patient”). DICOMBurner displays a dialog showing the data related to the last patient.

  • Page 14: Burn Last Study

    DICOMBurner: User Manual [DB-UM-3 – Rev B] DICOMBurner since last burn operation. Then you can choose the patients you want to burn and in addition you can change the CD/DVD options with respect to the default one set by the “CD/DVD Burner Configuration”...

  • Page 15: Burn Non-Burnt

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.4 Burn non-burnt By selecting the “Burn non-burnt” option, you are able to burn all the DICOM files which have been received and stored by DICOMBurner, but which haven’t been burnt onto CD or DVD yet. DICOMBurner displays a dialog box showing the list of non-burnt instances.

  • Page 16: Burn Custom From Local Storage

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.5 Burn custom from local storage If you select the “Burn custom from local storage” option, DICOMBurner shows a GUI wizard guiding you through a hierarchical (Study – Series – Instance) selection of the DICOM files to burn onto CD or DVD. The DICOM files will be selected by query the local storage.

  • Page 17: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] deleting procedure of the selected studies without reaching the last wizard step by pressing the “Burn Studies” button or “Delete Studies” button respectively. DICOMBurner will execute the burning operation using the default burning options. 5.5.2 Series-level search The series-level step of the wizard procedure allows you to select the series containing the DICOM files you want to burn onto CD or DVD.

  • Page 18: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] reaching the last wizard step by pressing the “Burn Series” button or “Delete Series” button respectively. DICOMBurner will execute the burning operation using the default burning options. 5.5.3 Instance-level search The instance-level step of the wizard procedure allows you to select the DICOM files/instances you want to burn onto CD or DVD.

  • Page 19: Burn Files Step

    DICOMBurner: User Manual [DB-UM-3 – Rev B] the “Burn Instances” button or “Delete Instances” button respectively. DICOMBurner will execute the burning operation using the default burning options. 5.5.4 Burn files step The burn file step is the last one in the wizard procedure: a list of the files that will be burnt on the CD/DVD is displayed.

  • Page 20: Burn Custom From Dicom Device

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.6 Burn custom from DICOM device If you select the “Burn custom from DICOM device” option, DICOMBurner shows a GUI wizard guiding you through a hierarchical (Study – Series – Instance) selection of the DICOM files to burn onto CD or DVD.

  • Page 21: Study-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.6.2 Study-level search The study-level step of the wizard procedure allows you to query, select and retrieve the studies containing the DICOM files you want to burn onto CD or DVD. This step includes both the filtering options related to patient and study levels.

  • Page 22: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.6.3 Series-level search The series-level step of the wizard procedure allows you to query, select and retrieve the series containing the DICOM files you want to burn onto CD or DVD. The list of series can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of series dates and the producing modalities.

  • Page 23: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 5.6.4 Instance-level search The instance-level step of the wizard procedure allows you to query, select and retrieve the DICOM files/instances you want to burn onto CD or DVD. The list of instances can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of acquisition dates and the acceptable range of store dates.

  • Page 24: Importing Dicom Files

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 6 Importing DICOM files By pressing the “Import” button on the main toolbar or on the correspondent menu item from the DICOMBurner tray pop-up menu, you can enter the importing feature. There exist two kinds of importing procedures: 1.

  • Page 25: Import From Disk

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 6.1 Import from disk In addition to being able to receive DICOM files from DICOM peers through the DICOM protocol, DICOMBurner allows populating its internal database by importing DICOM files from local folders or disks. The “Browse for folder”...

  • Page 26: Study-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 6.2.2 Study-level search The study-level step of the wizard procedure allows you to query, select and retrieve the studies containing the DICOM files you want to import. This step includes both the filtering options related to patient and study levels.

  • Page 27: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 6.2.3 Series-level search The series-level step of the wizard procedure allows you to query, select and retrieve the series containing the DICOM files you want to import. The list of series can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of series dates and the producing modalities.

  • Page 28: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 6.2.4 Instance-level search The instance-level step of the wizard procedure allows you to query, select and retrieve the DICOM files/instances you want to import. The list of instances can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of acquisition dates and the acceptable range of store dates.

  • Page 29: Exporting Dicom Files

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7 Exporting DICOM files By pressing the “Export” button on the main toolbar or on the correspondent menu item from the DICOMBurner tray pop-up menu, you can enter the exporting feature. There exist two kinds of exporting procedures: 1.

  • Page 30: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.1.2 Series-level search The series-level step of the wizard procedure allows you to select the series containing the images you want to export to a local folder. The list of series can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of series dates and the producing modalities.

  • Page 31: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.1.3 Instance-level search The instance-level step of the wizard procedure allows you to select the images/instances you want to export to a local folder. The list of instances can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of acquisition dates and the acceptable range of store dates.

  • Page 32: Export Images Step

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.1.4 Export images step The export images step is the last one in the wizard procedure: a dialog shows all the output image formats that you can select. For the DICOM format you can check the DICOMDIR generation and select the Transfer Syntax of the output DICOM files.

  • Page 33: Export To Dicom Device

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.2 Export to DICOM device DICOMBurner acts as a DICOM Store SCU allowing you to send DICOM files to a pre-selected DICOM device. Note that the sending procedure preserves the original DICOM files remain on the local storage.

  • Page 34: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.2.2 Series-level search The series-level step of the wizard procedure allows you to select the series containing the DICOM files you want to send to a DICOM device. The list of series can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of series dates and the producing modalities.

  • Page 35: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 7.2.3 Instance-level search The instance-level step of the wizard procedure allows you to select the DICOM files/instances you want to send to a DICOM device. The list of instances can be filtered by specifying some filtering options (or search criteria): in particular, you can set the acceptable range of acquisition dates and the acceptable range of store dates.

  • Page 36: Deleting Dicom Files

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 8 Deleting DICOM files In addition to the automatic purging procedure, DICOMBurner allows deleting a portion of the database content by using a quick and easy process to select the DICOM files to remove. When you press the “Delete”...

  • Page 37: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] acceptable range of study dates. By pressing the “Filter” button you obtain the list of studies satisfying the set conditions. Then you can select all studies you are interested in by using the mouse and multiple file selection technique.

  • Page 38: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] can select all series you are interested in by using the mouse and multiple file selection technique. The “Deselect All/Select All” button can simplify this task. The number of series, series size and number of instances are provided for the selected series.

  • Page 39: Delete Files Step

    DICOMBurner: User Manual [DB-UM-3 – Rev B] image of the DICOM file. Then you can select all instances you are interested in by using the mouse and multiple file selection technique. The “Deselect All/Select All” button can simplify this task. Finally, you can proceed to the next step by pressing the “Next>”...

  • Page 40: Backup Dicom Files And Database

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 9 Backup DICOM files and database DICOMBurner allows backing-up the database or creating backup CDs or DVDs containing DICOM files. The DICOM files to be archived on CD or DVD can be selected by the user. There exist four kinds of backup procedures: 1.

  • Page 41: Backup Database

    DICOMBurner: User Manual [DB-UM-3 – Rev B] These four options are accessible by clicking the small down arrow located next to the “Backup” button on the main toolbar. Once you select one of the available backup options from the pop-up menu, it will become the default option associated with the “Backup”...

  • Page 42: Backup A Week

    DICOMBurner: User Manual [DB-UM-3 – Rev B] obtain a preview image of the DICOM file. Then you can select all instances you are interested in by using the mouse and multiple file selection technique. The “Deselect All/Select All” button can simplify this task. Also in this case in you can change the CD/DVD options with respect to the default one set by the “CD/DVD Burner Configuration”...

  • Page 43: Backup A Period

    DICOMBurner: User Manual [DB-UM-3 – Rev B] “CD/DVD Burner Configuration” tab. You can start the backup procedure of the selected instances by pressing the “Backup” button. 9.4 Backup a period If you select the “Backup a week” popup menu option, it will appear a dialog similar to the following one.

  • Page 44: Restore Dicom Files And Database

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 10 Restore DICOM files and database In case of accidental loss of data DICOMBurner allows restoring DICOM files and database contents, by using the database backup files and backup CDs or DVDs containing DICOM files. There exist two kinds of restore procedures: 1.

  • Page 45: Restore Database

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 10.1 Restore database In case of system crashes the entire content of the database can be lost. In this case after you have reinstalled the system, you can recover the database content by using most recent database backup file (having the DBK extension).

  • Page 46: Series-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] acceptable range of study dates. By pressing the “Filter” button you obtain the list of studies satisfying the set conditions. Then you can select all studies you are interested in by using the mouse and multiple file selection technique.

  • Page 47: Instance-Level Search

    DICOMBurner: User Manual [DB-UM-3 – Rev B] the “Next>” button. As a shortcut you can start the restoring procedure of the selected series without reaching the last wizard step by pressing the “Restore Series” button. 10.2.3 Instance-level search The instance-level step of the wizard procedure allows you to select the DICOM files/instances you want to restore in the local database.

  • Page 48: Restore Files Step

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 10.2.4 Restore files step The restore files step is the last one in the wizard procedure and a list of alternative restore solutions is displayed. By clicking a listed restore solution the list of media code identifying the CDs or DVDs that will be need is displayed.

  • Page 49: Viewing Information

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 11 Viewing information 11.1 View Log dialog box The “View Log” dialog box allows viewing a detailed log of the events occurring inside DICOMBurner and of the actions performed. A List control is displayed on the dialog: each row of the list represents a logged event. Each event is defined by the following information: •...

  • Page 50: Dicomburner Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] • Event source: describes the source that originated the logged event or action. Currently defined sources are: DICOM UL: events coming from the DICOM Upper Layer software layer. DIMSE: events coming from the DIMSE software layer. Database: events or action coming from the database manager.
  • Page 51 DICOMBurner: User Manual [DB-UM-3 – Rev B] Maximum number of associations: the maximum number of concurrent DICOM associations accepted by DICOMBurner. ARTIM Timer value: the timeout value (in milliseconds) of the ARTIM Timer, used in the DICOM Upper Layer (see DICOM PS 3.8). Maximum received PDU size: the maximum PDU length (in bytes) accepted by DICOMBurner.

  • Page 52: Dicom Devices Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 12.2 DICOM Devices Configuration The “DICOM Devices Configuration” tab allows setting some parameters to configure the remote DICOM devices that DICOMBurner will interact with. The buttons on the dialog allows you to add a new device configuration, modify or remove an exiting one, verify the connection between DICOMBurner and the remote device or set a remote device as default for the available DICOM device operations.

  • Page 53: Log Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] 12.3 Log Configuration The “Log Configuration” tab allows setting some parameters related to the production of log by DICOMBurner. A description of each configuration parameter available in this dialog box is now provided: •...

  • Page 54: File Storage Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] The Log Configuration tab 12.4 File Storage Configuration The “File Storage Configuration” tab allows setting some preferences related to the policies used by DICOMBurner to manage the database where the received DICOM files are stored in. A description of each configuration parameter available in this dialog box is now provided: •...
  • Page 55 DICOMBurner: User Manual [DB-UM-3 – Rev B] files contained in the database (according to the actual storage date) will be deleted until the free disk space rises above the second specified threshold (Free Disk Space After Purge): Minimum Free Disk Space Threshold: a value representing the minimum number of megabytes always granted as free disk space.

  • Page 56: Cd/Dvd Burner Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] The File Storage Configuration tab 12.5 CD/DVD Burner Configuration The “CD/DVD Burner Configuration” tab allows setting up the burner units that you need to use to produce CD or DVD containing DICOM files. For any configured unit you can set the default parameters used during the burning process (for production or backup).

  • Page 57: Local Burner Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] The CD/DVD Burner Configuration tab By pressing the “Add” or “Modify” button, DICOMBurner shows a GUI wizard allowing you to set all the unit parameters. DICOMBurner is able to manage local CD/DVD burners and CD/DVD robot producer such as Rimage, MFDigital and Primera.
  • Page 58 DICOMBurner: User Manual [DB-UM-3 – Rev B] o Name: a not-null and unique name that identifies the unit o Description: an optional description of the unit o Usage: the destination use (Production or Backup) assigned to the unit (for a local burner only Production is suitable) By clicking “Next>”...
  • Page 59 DICOMBurner: User Manual [DB-UM-3 – Rev B] Media Type: specifies if the burner has to produce CDs or DVDs. By clicking “Next>” button you reach the third step of the GUI wizard where you can specify the following options: • CD/DVD Image Viewer: DICOMBurner allows putting a DICOM image viewer on every burnt CD/DVD, so you can specify the location of the executable application file: Add an autorunning DICOM viewer on the CD/DVD: a flag specifying if a DICOM Viewer has to be included into CD/DVD during the burning process.

  • Page 60: Rimage Unit Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Finish” button you save the configuration. 12.7 Rimage Unit Configuration If you have a Rimage CD/DVD Production Unit and a DICOMBurner license including the Rimage option then you can configure it for production or backup purposes. At the first step of the GUI wizard you have to select “Rimage”.
  • Page 61 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the second step of the GUI wizard where you can specify the following options: • Networking: specifies the networking parameters used to connect DICOMBurner to the Rimage Unit.
  • Page 62 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the third step of the GUI wizard where you can specify the following options: • Default CD/DVD Options: Number of copies: specifies the number of CD/DVD copies for any burn process. Interchange Profile: specifies a Media Storage Application Profile as defined by DICOM PS 3.11.
  • Page 63 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the fourth step of the GUI wizard where you can specify the following options: • CD/DVD Image Viewer: DICOMBurner allows putting a DICOM image viewer on every burnt CD/DVD, so you can specify the location of the executable application file: Add an autorunning DICOM viewer on the CD/DVD: a flag specifying if a DICOM Viewer has to be included into CD/DVD during the burning process.
  • Page 64 DICOMBurner: User Manual [DB-UM-3 – Rev B] Note: if at the first step of the wizard you set Rimage for Backup usage then this step isn’t shown because the image viewer is useless on a backup CD/DVD. By clicking “Next>” button you reach the fifth step of the GUI wizard where you can specify the following options: Label Selection: the Rimage Unit allows you to print the CD/DVD surface, so you have to specify the file pathnames containing the label project.
  • Page 65 DICOMBurner: User Manual [DB-UM-3 – Rev B] The Custom DICOM Field Search dialog Note: if at the first step of the wizard you set Rimage for Backup usage then the label selection step allows you to select a backup label instead of a production one and the dynamic fields aren’t of DICOM type:...

  • Page 66: Primera Unit Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Finish” button you save the configuration. 12.8 Primera Unit Configuration If you have a Primera CD/DVD Production Unit and a DICOMBurner license including the Primera option then you can configure it for production or backup purposes. At the first step of the GUI wizard you have to select “Primera”.
  • Page 67 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the third step of the GUI wizard where you can specify the following options: • Default CD/DVD Options: Number of copies: specifies the number of CD/DVD copies for any burn process. Interchange Profile: specifies a Media Storage Application Profile as defined by DICOM PS 3.11.
  • Page 68 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the fourth step of the GUI wizard where you can specify the following options: • CD/DVD Image Viewer: DICOMBurner allows putting a DICOM image viewer on every burnt CD/DVD, so you can specify the location of the executable application file: Add an autorunning DICOM viewer on the CD/DVD: a flag specifying if a DICOM Viewer has to be included into CD/DVD during the burning process.
  • Page 69 DICOMBurner: User Manual [DB-UM-3 – Rev B] Note: if at the first step of the wizard you set Primera for Backup usage then this step isn’t shown because the image viewer is useless on a backup CD/DVD. By clicking “Next>” button you reach the fifth step of the GUI wizard where you can specify the following options: Label Selection: the Primera Unit allows you to print the CD/DVD surface, so you have to specify the file pathnames containing the label project.
  • Page 70 DICOMBurner: User Manual [DB-UM-3 – Rev B] The Custom DICOM Field Search dialog Note: if at the first step of the wizard you set Primera for Backup usage then the label selection step allows you to select a backup label instead of a production one and the dynamic fields aren’t of DICOM type:...

  • Page 71: Mfdigital Unit Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Finish” button you save the configuration. 12.9 MFDigital Unit Configuration If you have a MFDigital CD/DVD Production Unit and a DICOMBurner license including the MFDigital option then you can configure it for production or backup purposes. At the first step of the GUI wizard you have to select “MFDigital”.
  • Page 72 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the second step of the GUI wizard where you can specify the following options: • Networking: specifies the networking parameters used to connect DICOMBurner to the MFDigital Unit.
  • Page 73 DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Next>” button you reach the third step of the GUI wizard where you can specify the following options: • Default CD/DVD Options: Number of copies: specifies the number of CD/DVD copies for any burn process. Interchange Profile: specifies a Media Storage Application Profile as defined by DICOM PS 3.11.
  • Page 74 DICOMBurner: User Manual [DB-UM-3 – Rev B] • CD/DVD Image Viewer: DICOMBurner allows putting a DICOM image viewer on every burnt CD/DVD, so you can specify the location of the executable application file: Add an autorunning DICOM viewer on the CD/DVD: a flag specifying if a DICOM Viewer has to be included into CD/DVD during the burning process.
  • Page 75 DICOMBurner: User Manual [DB-UM-3 – Rev B] Note: if the label project contains images, they have to be put in the same folder of the LBL file. Dynamic Field Associations: allows setting the associations between a label field and a dynamic field. The “Associate>” and “<Clear” buttons respectively create or delete an association between a listed and selected “CD Label Field”...

  • Page 76: Automatic Cd/Dvd Production Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] By clicking “Finish” button you save the configuration. 12.10 Automatic CD/DVD Production Configuration The “Automatic CD/DVD Production Configuration” tab allows setting up the parameters to manage the automatic burning processes. A description of each configuration parameter available in this dialog box is now provided: •...
  • Page 77 DICOMBurner: User Manual [DB-UM-3 – Rev B] Each Unit Selection Rule is composed of the following parameters: Calling AE Title: the Calling AE Title of the association. The user may either specify a specific Calling AE Title, a Calling AE Title present in the DICOMBurner database or select the “Any”...

  • Page 78: Automatic Backup Configuration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] The Automatic CD/DVD Production Configuration tab 12.11 Automatic Backup Configuration The “Automatic Backup Configuration” tab allows setting up the parameters to manage the automatic backup processes (for DICOM files storage and database content). A description of each configuration parameter available in this dialog box is now provided: •...
  • Page 79 DICOMBurner: User Manual [DB-UM-3 – Rev B] Frequency: specifies the frequency of the backup operation selected between “Week by week” or “Day by day”. Day: specifies the day of the week in which the backup is launched (available only for “Week by week” backup) Time: specifies the time of the day in which the backup is launched Backup …: specifies which DICOM files has to be backed-up All files...

  • Page 80: Registration And Administration

    DICOMBurner: User Manual [DB-UM-3 – Rev B] The Automatic Backup Configuration tab 13 Registration and Administration 13.1 Registration & Administration dialog box The “Registration & Administration” dialog box appears when the DICOMBurner user selects the “Registration & Administration” menu item from the DICOMBurner tray pop-up menu. It shows the kind of license activated for the current copy of DICOMBurner.
  • Page 81 DICOMBurner: User Manual [DB-UM-3 – Rev B] The Registration & Administration dialog box Through the “Enter/change registration keys…” button, the user may enter new registration keys for the current copy of DICOMBurner, or change the current registration keys. This operation is protected by an administration password.
  • Page 82 DICOMBurner: User Manual [DB-UM-3 – Rev B] The DICOMBurner administrator (i.e., a person who knows the DICOMBurner administration password) may also choose to protect the DICOMBurner configuration section with the administration password: if the “Request admin password for configuration” option is enabled, then the user will be asked for the administration password when the “Settings”...
