McIntosh MC275 Connection Diagrams

1
A
Note: Refer to the MC275 Owner's Manual page 10 for additional connection information.
Connection Legend:
Data Cable*- Digital Signal Cable -
Sensor/Keypad Cable - Network/RS232 Cable -
Power Control Cable* - Ground Wire -
Audio Signal Cable - AC Power Cords -
Video Signal Cable - Loudspeaker Cable -
RF Signal Cable -
*
2 conductor shielded with 1/8 inch stereo mini phone plug on each end.
Connect to
AC Outlet
Right Loudspeaker System
(+)8Ω
(-)
McIntosh Laboratory, Inc. 2 Chambers Street Binghamton, New York 13903-2699 Phone: 607-723-3512 www.mcintoshlabs.com Part No. 04131300
MC275 Stereo Operation Connection Diagram
(-)
(+)8Ω
(-)
(+)8Ω
Audio Preamplifier
Left Loudspeaker System
(-)
(+)8Ω
