- Page 1 SIRIUS Home Signal Distribution Kit for Satellite Radio For Use With One or Two SIRIUS Receivers Installation Manual...
-
Page 2: Box Contents
SIRIUS satellites and terrestrial (ground) transmitters when mounted outdoors on a home or other building. The antenna has been approved by Sirius Satellite Radio to receive the SIRIUS signal under a variety of conditions within the SIRIUS North American coverage area. -
Page 3: Tools Required
Tools Required A phillips-type screwdriver and a 3/8 in. wrench is needed for installation. De- pending upon the type of installation, a power drill with a 3/32 in. drill bit may also be required. Caution and Warnings WARNING: Be sure not to cut, damage, or puncture the external jacket of the antenna cables during the installation procedure. - Page 4 Materials Required and Installation Considerations In order to install the antenna you will need to purchase several lengths of RG-6 antenna cables to complete your installation. The following illustration shows a typical home installation. SATELLITE SATELLITE RADIO OUTDOOR ANTENNA Adapter Cable SATELLITE RADIO Adapter...
- Page 5 RG-6 cable is typically sold in lengths of 25, 50, or 100 ft., all with “F” type con- nectors on each end. These cables may be purchased at your local hardware store, home center, or electronics retailer. The combined length of the RG-6 cables from the outdoor antenna to each SIRIUS receiver should not exceed 150 ft., as shown in the preceding illustra- tions.
-
Page 6: Antenna Installation
Antenna Installation A successful antenna installation consists of three steps: First, determining a location for the antenna; Second, choosing a mounting option; and Third, ad- justing and aiming the antenna. Please read the following three sections before beginning the antenna installation so that you understand the entire installation process. - Page 7 NORTH WEST EAST HORIZON SOUTH Use the above map and find the area you are located in (1 to 5). Then find the direction in which you need to have a clear view of the sky: Area 1: You will need a location with a clear view of the sky facing EAST or NORTHEAST or SOUTHEAST Area : You will need a location with a clear view of the sky facing NORTH or NORTHEAST...
-
Page 8: Adapter Cable
No obstructions to the sky within the area facing North to Northeast NORTH Once you have determined a possible mounting location for your area, it is recommended that you put the antenna in place temporarily and connect the antenna to your SIRIUS receiver as shown in the following illustration. Using the Antenna Aiming or Signal Indicator feature of your receiver, verify that your an- tenna is receiving a good SIRIUS signal. - Page 9 Wall Mount The antenna mounting bracket should be oriented in a vertical position (as shown) and mounted directly to the wall of the building or home using the pro- vided #10 screws. MOUNTING HOLES Remember to avoid blocking the antenna’s view of the sky as described in the previous section by locating the antenna too high under the eaves or soffit of the home or building.
- Page 10 Once you have determined a suitable mounting location, use the mounting bracket as a template and mark the roof with the location of the four screw holes in the mounting bracket. Then, using a 3/32 in. drill bit, drill pilot holes in the roof for the screws.
- Page 11 Next, screw the hex nuts on each leg until they are snug. Do not yet tighten the hex nuts beyond finger tight. Repeat this procedure with the other U-bolt. When all the hex nuts are snug, verify that the antenna is facing the correct direction and begin tightening each hex nut with a 3/8”...
-
Page 12: Cable Installation
Cable Installation Once the antenna is mounted according to the previous instructions, you can continue with the cable and Splitter portion of the installation: Take the RG-6 cable which you purchased to connect to the antenna and thread one end of the cable through the opening in the end of the rubber boot. - Page 13 second receiver, connect the provided terminator to the unused OUT con- nector on the splitter. (Refer to page 3 for the Splitter port identification.) Use terminator if no second receiver The installation of the Home Distribution Kit is now completed. The completed installation for two SIRIUS receivers should be as illustrated below: If you are connecting one SIRIUS receiver, the completed installation should be as illustrated below:...
-
Page 14: Troubleshooting
Troubleshooting SIRIUS receiver displays “Antenna Error” or “Check Antenna” message. Check the antenna cable connections to be sure they are connected tightly. SIRIUS receiver displays “No Signal” or “Acquiring Signal” message. The receiver is not receiving a good SIRIUS signal. Check that the antenna has a clear view of the sky, and that the antenna is pointed in the direction of the SIRIUS satellites. - Page 15 Notes: Home Distribution Kit Installation Manual...
-
Page 16: Sirius Satellite Radio
11 Avenue of the Americas New York, NY 1000 () 5- www.sirius.com © 2006 SIRIUS Satellite Radio Inc. SIRIUS Home Signal Distribution Kit for Satellite Radio 082306a) ® “SIRIUS” and the SIRIUS dog logo are registered trademarks of Sirius Satellite Radio Inc.
