Owner's Manual
Owner's Manual
Owner's Manual
with Assembly Instructions
with Assembly Instructions
with Assembly Instructions
For Model H4433
For Model H4433
For Model
H4433
Please read this manual and save it
with your original sales receipt.
Tools needed for assembly: Phillips Screwdriver,
Adjustable Wrench (or Pliers), Hammer and
Safety Scissors (all not included). Use only with
a Power Wheels
®
12 Volt Lead Acid
Requires three "AA" (LR6) alkaline
batteries for sound box operation.
®
12 Volt
Advertisement
Table of Contents
Related Manuals for Fisher-Price BARBIE H4433
Summary of Contents for Fisher-Price BARBIE H4433
- Page 1 Please read this manual and save it with your original sales receipt. Tools needed for assembly: Phillips Screwdriver, Adjustable Wrench (or Pliers), Hammer and Safety Scissors (all not included). Use only with a Power Wheels Rechargeable Battery and Power Wheels Charger with Type 12V Connector (both included).
-
Page 2: Table Of Contents
• Use this vehicle ONLY outdoors. Most interior flooring can be damaged by riding this vehicle indoors. Fisher-Price responsible for damage to the floor if the vehicle is used indoors. • To prevent damaging the motors and gears, teach your child to stop the vehicle before switching direction. -
Page 3: B Warnings And Cautions
WARNINGS AND CAUTIONS ELECTRICAL HAZARD • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 4: C Parts
• If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded. •... - Page 5 TABLE OF CONTENTS PARTS #10 x " Screw - 16 12 Volt Battery 12 Volt Charger Taillight Lens Set #8 x 1" Screw - 6 Taillight Housing Set #8 Acorn Lock Nut - 2 Lens Guard - 2 Headlight Lens - 2 .354"...
- Page 6 Note: Some parts shown are assembled on both sides of the vehicle. Vehicle Steering Column Hood Latch 12 Volt Battery 12 Volt Charger Key Assembly Taillight Lens Taillight Housing Hood with Flying Disc TABLE OF CONTENTS PARTS PICTURE Dash Sport Bar Headlight Lens Sport Bar Support - 2 Lens Guard...
-
Page 7: Battery Charging
ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery retainer. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. -
Page 8: Ebattery Charging
BATTERY CHARGING 12V Battery • Plug the charger connector into the battery • Plug the charger into a standard wall outlet Notes: - If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. - Use the charger only in a wall outlet. - Page 9 1.5V x 3 "AA" (LR6) Battery Safety Information In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or ruin your product. To avoid battery leakage: • Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).
- Page 10 Dash • Insert and “snap” the key assembly into the opening in the dash, as shown. Steering Column Bottom View • Wipe the steering column with a paper towel to remove any excess lubricant. • Turn the vehicle on its side. •...
- Page 11 • Fit the steering wheel cap into the center of the steering wheel. • Insert two #8 x 1" screws and tighten. Steering Wheel • Position the steering wheel cover so the fastener tabs are towards the bottom of the steering wheel. •...
- Page 12 Hood Latch Slot • Insert a hood latch into one of the slots in the vehicle, near the hood area. • Twist the base of the hood latch • Repeat this procedure on the other side of the hood area to attach the other hood latch to the vehicle.
- Page 13 Brush Guard Side View • Fit and hold the brush guard against the front end of the vehicle. Hint: Using the end of a Phillips screwdriver, poke a hole in the thin, plastic covering over the lower holes in the brush guard. •...
- Page 14 Seat Back Tabs Slot Side View • With the seat at an angle, insert the tabs on the front edge of the seat into the slots in the foot-well wall • Push down firmly on the edge of the seat above each tab to snap the tabs into the slots •...
- Page 15 • Using safety scissors, cut the plastic ties holding the water bottles to the drink holders. Dispose of the plastic ties properly. Note to Retailer: Do not remove the plastic ties. Sport Bar • Fit a support to one side of the sport bar. •...
- Page 16 Rear of Vehicle Bottom View • Turn the vehicle on its side. • Insert two #10 x " screws into the holes (behind the rear wheels) in the underside of each rear wheel well, through the vehicle body and into the ends of the sport bar. Tighten the screws. •...
- Page 17 TABLE OF CONTENTS DECORATION Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •...
-
Page 18: Gdecoration
DECORATION FRONT LEFT SIDE FRONT RIGHT SIDE H4433pr-0921... -
Page 19: Battery Installation
IMPORTANT! Use only a Power Wheels ® 12 volt lead-acid rechargeable battery. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels operating your vehicle for the first time. Charge the battery for at least 14 hours after each use of the vehicle. -
Page 20: Battery Care And Disposal
BATTERY CARE AND DISPOSAL Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician. -
Page 21: Safe Driving Rules
RIDING HAZARD WARNING • Prevent Injuries and Deaths • Direct Adult Supervision Required • Never Ride at Night. • Keep Children Within Safe Riding Areas. These areas must be: - away from swimming pools and other bodies of water to prevent drownings - generally level to prevent tipovers - away from steps, steep inclines, cars, roads and alleys. -
Page 22: Vehicle Operation
IMPORTANT! Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price will not be responsible for damage to the floor if the vehicle is used indoors. Beginner Use - Low Speed Drive As assembled, your vehicle is ready to roll in low speed mph, maximum). -
Page 23: Lsound Box Operation
SOUND BOX OPERATION • Press any of the buttons on the sound box to hear three styles of beach party music. STEERING WHEEL COVER, SEAT COVER & HAIR TIE CARE IMPORTANT! Color will fade on the fabric covers if left in sunlight. We recommend placing and storing the vehicle in a shaded area when not in use. -
Page 24: Nvehicle Care
VEHICLE CARE • Check all screws, cap nuts and their protective coverings regularly and tighten as required. Check plastic parts on a regular basis for cracks or broken pieces. • During snowy or rainy weather, the vehicle should be stored inside or under a protective cover. - Page 25 PROBLEMS AND SOLUTIONS GUIDE IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels ® Consumer Relations, toll-free at 1-800-348-0751 between 9 AM and 7 PM (EST) Monday through Friday or 11 AM and 5 PM (EST) Saturday.
-
Page 26: Qproblems And Solutions Guide
PROBLEMS AND SOLUTIONS GUIDE PROBLEM Vehicle was running but suddenly stopped Short run time (Less than 1 - 3 hours per charge) Vehicle runs in low speed, but does not run in high speed Please Note: The vehicle is designed to operate in low speed only in reverse When the foot pedal is pressed only one rear wheel spins... - Page 27 PROBLEMS AND SOLUTIONS GUIDE PROBLEM POSSIBLE CAUSE Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Sometimes the vehicle doesn’t Loose wire or connector run, but other times it does Motor or electrical switch damage When the foot pedal is pressed,...
- Page 28 ® and its trade dress are used under license. ©DaimlerChrysler Corporation 2005. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2007 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
