Product features may
vary from the picture above.
Please read this manual and save it with your original sales receipt.
Tools needed for assembly: Phillips Screwdriver, Hammer and Pliers (all not included);
Use only with a Power Wheels
and a Power Wheels
Kawasaki
®
and Ninja
®
are U.S. trademarks owned by and used under license from Kawasaki Motors Corp., U.S.A.Kawasaki Motors Corp., U.S.A. All Rights Reserved.
This product is neither manufactured nor distributed by Kawasaki Motors Corp., U.S.A. Consumer inquiries should be directed to: Power Wheels by Fisher Price
Fisher-Price, Power Wheels, Power Wheels by Fisher-Price and Power Lock are U.S. trademarks of Mattel, Inc.
®
Cap Nut Assembly Tool (included).
®
12 Volt Battery with Built-in Thermal Fuse
®
12 Volt Charger (both included).
www.powerwheels.com
Owner's Manual
with Assembly Instructions
For Model 73690
®
®
.

Advertisement

Table of Contents
loading

Related Manuals for Fisher-Price 73690

Summary of Contents for Fisher-Price 73690

  • Page 1 This product is neither manufactured nor distributed by Kawasaki Motors Corp., U.S.A. Consumer inquiries should be directed to: Power Wheels by Fisher Price Fisher-Price, Power Wheels, Power Wheels by Fisher-Price and Power Lock are U.S. trademarks of Mattel, Inc. www.powerwheels.com ®...

  • Page 2: Table Of Contents

    3 - 7 years of age. • Use this vehicle ONLY outdoors. Most interior floor- ing can be damaged by riding this vehicle indoors. Fisher-Price ® will not be responsible for damage to floors if this vehicle is used indoors.

  • Page 3: Warnings And Caution

    ELECTRICAL HAZARD • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system. - Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury.

  • Page 4: Parts

    • If you experience a problem with this product, or are missing a part, please call us at 1-800-348-0751, rather than return this product to the store. • Please identify all parts before assembly and save all packaging material until assembly is complete to ensure that no parts are discarded.
  • Page 5 Parts Fairing Top Handlebar Cover Bottom Handlebar Cover 12 Volt Charger 12 Volt Battery Key Assembly Round Bushing - 2 Radio Knob - 2 Handlebar Cap Nut Microphone Assembly Tool Part Not Shown: Label Sheet #8 x " Screw – 17* #10 - 32 Lock Nut - 2 .437 Cap Nut –...

  • Page 6: Parts Diagram

    Note: Some parts shown are assembled on both sides of vehicle. Vehicle Body Cowling Seat Wheel - 4 Hubcap - 4 Cap Nut - 6 Steering Column Right Mudflap 12 Volt Battery Key Assembly Parts Diagram Microphone Radio Knob - 2 Grip - 2 Top Handlebar Cover Bottom Handlebar Cover...

  • Page 7: Battery Charging

    ELECTRICAL HAZARD WARNING • Battery can fall out and injure a child if vehicle tips over. Always use battery clamp. • PREVENT FIRE - Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.
  • Page 8 Important Notes • Your new battery must be charged for at least 18 hours before you use it in your vehicle for the first time. • We recommend that you start charging your battery before beginning assembly of your new vehicle. •...

  • Page 9: Assembly

    WARNING Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s unassembled state, or by electrical items. Care should be taken in unpacking and assembly of the vehicle. Children should not handle parts, including the battery, or help in assembly of the vehicle.
  • Page 10 • Slide a hubcap, indented side down, onto the rear axle. • Slide a wheel onto the rear axle. Make sure the ribs on the wheel face up. • Slide a rear wheel driver, ring side down, onto the rear axle.
  • Page 11 Wheel Hubcap Cap Nut Assembly Tool Cap Nut Ring • Face the front end of the vehicle body. • Slide a washer onto one of the Round Bushing front axles. • Slide a round bushing, ring end first, onto the front axle. •...
  • Page 12 PRESS HERE To Snap Side Tabs • Press firmly on each side of the cowling to snap the four side tabs into the slots in the vehicle body. Make sure the rear tab stays aligned with the slot. Note: You may need to flex the shifter to the side to fit the cowling over the high speed lock-out screw.
  • Page 13 Hole Lock Nut Neck • Position the handlebar so that the side with the three holes and circular indent face up. • Fit the neck against the bottom of the handlebar. Align the holes in the handlebar and neck. • Insert a #10-32 x 1 "...
  • Page 14 • Fit the top handlebar cover to the bottom handle- bar cover. • Insert three #8 x " screws through the holes in the top handlebar cover. Tighten the screws with a Phillips screwdriver. Do not over-tighten. Screw Tab • While pushing the top handlebar cover and the fairing together, insert four #8 x "...

  • Page 15: Label Decoration

    Proper label application will help to keep the labels looking their best! When applying labels, keep the following guidelines in mind: • Wash your hands before applying the labels. • Before applying the labels, wipe the surface of the vehicle with a clean, dry cloth to remove any dust or oils. •...
  • Page 16 Label Decoration Right Side Left Side...

  • Page 17: Battery Installation

    IMPORTANT! Use only a Power Wheels with built-in thermal fuse. Use of any other battery will damage your vehicle. Make sure that you charge the battery for at least 18 hours using the enclosed Power Wheels 12 volt charger before operating your vehicle for the first time.

  • Page 18: Battery Care And Disposal

    Battery Care and Disposal Care If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal. If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.

  • Page 19: Rules For Safe Driving

    RIDING HAZARD WARNING Prevent Injuries and Deaths • Direct Adult Supervision Required • Keep Children Within Safe Riding Areas These areas must be: - away from swimming pools and other bodies of water to prevent drownings - generally level to prevent tipovers - away from steps, driveways, cars, roads and alleys.

  • Page 20: How To Operate Your Vehicle

    How to Operate Your Vehicle As assembled, your vehicle is ready to roll in low speed (2 child is ready to drive the vehicle in high speed (5 mph, maximum), follow the instructions (step 3) to disconnect the high speed lock-out. Beginner - Low Speed Drive Shifter REMOVE LOCK-OUT...

  • Page 21: Fcc Statement (United States Only)

    IMPORTANT! Use the vehicle ONLY outdoors. Most interior flooring can be damaged by riding the vehicle indoors. Fisher-Price ® will not be responsible for damage to floors if vehicle is used indoors.

  • Page 22: Problems And Solutions Guide

    Problems and Solutions Guide IMPORTANT! If you experience a problem with your vehicle, first check the Problems and Solutions Guide below. If you still experience a problem, please contact Power Wheels toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through Friday. Or, contact your local Power Wheels Authorized Service Center list beginning on page 24.
  • Page 23 Problems and Solutions Guide Problem Short run time Undercharged battery Overcharged battery Battery is old and will not accept full charge Tripped thermal fuse Vehicle runs sluggishly Undercharged battery Battery needs charging Battery is old and will not accept full charge Vehicle is overloaded Driving conditions are too stressful Vehicle runs in low speed, but...

  • Page 24: Authorized Service Centers

    Problems and Solutions Guide Problem When the foot pedal is pressed only one rear wheel spins Sometimes the vehicle doesn’t run, but other times it does When the foot pedal is pressed, the vehicle won’t run without a push Loud clacking or grinding noise from a motor-gearbox Charger gets warm during use Battery makes a sizzling or...
  • Page 25 YUCAIPA - Aire-Rite Heating & A/C, 34724 Yucaipa Blvd., 92399, (909) 797-2788 COLORADO COLORADO SPRINGS - Nelson Appliance Repair, Inc., 1220 E. Fillmore, 80907, (719) 635-1928, (800) 291-8010 DENVER - Appliance Service, 4272 Lowell Blvd., 80211, (303) 458-1109, GRAND JUNCTION - V & L Appliance Service, 591 25 Road Suite A6, 81505, (970) 243-3360 PUEBLO - Direct Maytag Home Appliance, 1407 Santa Fe Drive, 81006, (719) 543-0777...
  • Page 26 BERLIN - Myers Auto-Power Tool Rental Co., Inc., 10714 Ocean Gateway, 21811, (410) 641-3497 GAITHERSBURG - Waters Appliance Service, 216 E. Diamond Avenue, 20877, (301) 258-7500, (800) 225-5009 GLEN BURNIE - Taylor Rental, 7389 Baltimore Annapolis Blvd., 21061, (410) 768-1933, (800) 836-8464 LOVEVILLE - Hancock Refrigeration Co Inc., 28650 Point Lookout Rd, 20656, (301) 475-8298 MASSACHUSETTS...
  • Page 27 YOUNGSTOWN - O’Connor’s, 3224 Market Street, 44507, (330) 782-4705 ZANESVILLE - Batteries Unlimited, 2350 Adamsville Road, 43701, (740) 453-3311 OKLAHOMA OKLAHOMA CITY - Appliance Services by CK, 101 East Madison, 73105, (405) 525-8862 OKLAHOMA CITY - Oaklahoma Service Center, 1940 North May Street, 73107, (405) 946-9841 TULSA - H.L.
  • Page 28 Service Centers Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052 U.S.A. ©2002 Mattel, Inc. All Rights Reserved. Fisher-Price and Power Wheels by Fisher-Price are U.S. trademarks of Mattel, Inc. Printed in Mexico. If you are missing parts or need assistance,...
