LG M3704C Owner's Manual

Monitor signage
Hide thumbs Also See for M3704C:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
OWNER'S MANUAL
MONITOR SIGNAGE
Please read this manual carefully before operating
your set and retain it for future reference.
MONITOR SIGNAGE MODELS
M3704C
M4225C
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG M3704C

Summary of Contents for LG M3704C

  • Page 1 OWNER’S MANUAL MONITOR SIGNAGE Please read this manual carefully before operating your set and retain it for future reference. MONITOR SIGNAGE MODELS M3704C M4225C www.lg.com...

  • Page 2: Table Of Contents

    Table of Contents Licenses Accessories Connecting the Speakers Portrait Mode Using the Remote Control Part Names and Functions Connecting to External Devices Connecting to Your PC .......................10 Using the LAN ........................12 Daisy Chaining Set ......................13 VESA FDMI Wall Mounting ....................14 Video Input ...........................15 Component Input (480i/480p/576i/576p/720p/1080i/1080p) ..........16 HDMI Input (480p/576p/720p/1080i/1080p) ..............17...

  • Page 3: Licenses

    Licenses Supported licenses may differ by model. For more information of the licenses, visit www.lg.com. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified® device that plays DivX video.

  • Page 4: Accessories

    Accessories Included Accessories Thank you for your purchase. Check to make sure that the accessories shown immediately below have been included with your set. ❖ Note that the accessories may look different from those shown here. D-Sub Signal Power Cable Remote Control CD-ROM / Cards Cable...

  • Page 5: Connecting The Speakers

    Connecting the Speakers - Only on some models. Attach the speakers to the set using screws as shown below. Then, connect the speaker cable. After installing your speakers, use holders and cable ties to organize the speaker cables. Cable holder Remove the paper.

  • Page 6: Portrait Mode

    Portrait Mode - Only on some models. < Only M4225C > "When installing in portrait mode, rotate the set clockwise."...

  • Page 7: Using The Remote Control

    Using the Remote Control Remote Control Buttons On / Off Button - Switches the set on from standby or off to POWER standby. MONITOR On / Off Button ENERGY INPUT MONITOR - Turns off the monitor and then turn it back on. SAVING Number and Letter Buttons .

  • Page 8: Inserting Batteries Into The Remote Control

    Using the Remote Control ENERGY SAVING Button POWER - Adjusts the Energy Saving mode of the set. INPUT Select Button ENERGY INPUT MONITOR Accesses the Input Signal Window. Selects the signal type you want using < >. SAVING . , ! Input List Component HDMI/DVI...

  • Page 9: Part Names And Functions

    Part Names and Functions * The set image in the user's guide may be different from the actual image. Rear View Power Connector Connect the power cord. RS-232C Serial Ports RGB, HDMI/DVI Ports HDMI supports high definition input and HDCP (High-bandwidth Digital Content Protection).

  • Page 10: Connecting To External Devices

    Connecting to External Devices Connecting to Your PC Check that the computer, monitor and the peripherals are turned off. Then, connect the signal input cable. Connecting with a D-Sub Signal Input Cable. Connecting with an HDMI-DVI Signal Input Cable (not included) * When HDMI PC is used, a compatibility problem may occur.
  • Page 11 Connecting to External Devices Press Power. < M3704C > < M4225C > On/Off button On/Off button Turn on the PC. Select an input signal. Press INPUT on the remote control to select the input signal. INPUT → < > → OK Or, press INPUT on the bottom of the set.

  • Page 12: Using The Lan

    Connecting to External Devices Using the LAN Connect the LAN cable as shown below. Using a Router (Switch). Connect PC to Monitor. Switch Using the Internet. Network Network Network Connect the LAN cable and install the eZ-Net Manager program on the CD-ROM. For more information about the program, please refer to the eZ-Net Guide on the included CD-ROM.

  • Page 13: Daisy Chaining Set

    Connecting to External Devices Daisy Chaining Set Using RGB Input To use different set connected to each other, connect one end of the signal input cable (15-pin D-Sub signal cable) to the RGB OUT connector of set 1 and connect the other end to the RGB IN connector of other set.

  • Page 14: Vesa Fdmi Wall Mounting

    • To prevent injury, this apparatus must be securely attached to the wall in accordance with the installation instructions. Optional Installer Remote Control for model No. Series M4225C/M3704C There is an optional Installer remote control available for the M4225C/M3704C Models. The installer remote control is NOT included with the apparatus. Option Extras...

  • Page 15: Video Input

    Connecting to External Devices Video Input Connect the video cable as shown below and then connect the power cord (see page 10). Connecting with a BNC Cable • Connect the input terminal with a proper color match. Audio Cable BNC Cable (not included) (not included) VCR/DVD Receiver...

  • Page 16: Component Input (480I/480P/576I/576P/720P/1080I/1080P)

    Connecting to External Devices Component Input (480i/480p/576i/576p/720p/1080i/1080p) Connect the AV cable as shown in the below figure, then connect the power cord (see page 10). • Connect the input terminal with the matching color. BNC Cable Audio Cable (not included) (not included) HDTV Receiver Note:...

  • Page 17: Hdmi Input (480P/576P/720P/1080I/1080P)

    Connecting to External Devices HDMI Input (480p/576p/720p/1080i/1080p) HDMI supports high definition input and HDCP (High-bandwidth Digital Content Protection). Some devices require HDCP in order to display HD signals. Connect the AV cable as shown below and connect the power cord (see page 10). RCA-PC HDMI-DVI Signal Cable...

  • Page 18: User Menus

    User Menus Screen Adjustment Options < M3704C > < M4225C > Turns the set on/off. On/Off Button This Indicator lights up green when the set is operating Power Indicator normally (on mode). If the set is in sleep mode (Energy Saving), the indicator color changes to amber.
  • Page 19 User Menus Screen Adjustment Options AUTO/SET Button [For PC Analog signal] Auto in progress For optimal display change resolution to 1920 x 1080 [When XGA Mode is active and 1920 x 1080 is selected] Auto in progress INPUT Button INPUT → ◄ ► → AUTO/SET - Toggles between inputs Composite Video Component...

  • Page 20: Osd Menu

    User Menus OSD Menu Icon Function Description Adjusts screen brightness, contrast and color to your preference. Picture Adjusts the audio. Audio Adjusts the timer. Time Adjusts the screen status according to conditions. Option Adjusts tile options. Tile Adjusts USB options. Note OSD (On-Screen Display) •...

  • Page 21: Adjusting The Osd (On-Screen Display)

    User Menus Adjusting the OSD (On-Screen Display) ➩ ➩ ➩ ➩ ➩ ➩ ➩ MENU Save Select a Pops up Move where Move where Exit from the Select a Adjust the status adjustment menu list the menu you want to you want to menu screen.

  • Page 22: Adjusting Screen Color

    User Menus Adjusting Screen Color Aspect Ratio PICTURE Move Aspect Ratio : 16:9 Aspect Ratio : 16:9 Energy Saving : Off Picture Mode : Standard 16:9 16:9 • Backlight Just scan Original • Contrast • Brightness 14:9 • Sharpness Zoom Cinena Zoom 1 •...

  • Page 23: Energy Saving

    User Menus Adjusting Screen Color Energy Saving PICTURE Move Aspect Ratio : 16:9 ꕫ Energy Saving : Off Energy Saving : Off Level 1 Picture Mode : Standard Level 2 • Backlight Level 3 • Contrast • Brightness • Sharpness •...
  • Page 24 User Menus Adjusting Screen Color Picture Mode PICTURE Move Aspect Ratio : 16:9 Energy Saving : Off Vivid Picture Mode : Standard Picture Mode : Standard Standard Standard • Backlight Cinema • Contrast Sport • Brightness Game • Sharpness Expert 1 •...
  • Page 25 User Menus Adjusting Screen Color Picture Mode PICTURE Move Aspect Ratio : 16:9 Energy Saving : Off Picture Mode : Standard (User) • Backlight • Backlight 70 • Contrast • Brightness 50 • Sharpness 70 • Color ▼ Backlight: Adjusts the brightness of LCD panel. Contrast: Adjusts the difference between light and dark levels.
  • Page 26 User Menus Adjusting Screen Color Advanced Control PICTURE Move ▲ • Contrast Color Temperature ◄ Medium ► • Brightness Dynamic Contrast High • Sharpness Dynamic Color • Color High • Tint Noise Reduction Medium • Advanced Control • Advanced Control Gamma Medium •...

  • Page 27: Picture Reset

    User Menus Adjusting Screen Color Picture Reset Returns Picture Mode to the default factory PICTURE settings. Move ▲ • Contrast • Brightness • Sharpness • Color • Tint • Advanced Control • Picture Reset • Picture Reset Screen Screen PICTURE Move ▲...

  • Page 28: Adjusting Audio

    User Menus Adjusting Audio AUDIO AUDIO Move Move ▲ Auto Volume : Off Auto Volume : Off Clear Voice II : Off Clear Voice II : Off • Level • Level Balance Balance Sound Mode : Standard Sound Mode : Standard •...

  • Page 29: Adjusting The Timer

    User Menus Adjusting the Timer TIME Move Clock Clock : −− : −− −−−− Off Time : Off On Time : Off Sleep Timer : Off Auto Off : On Power On Delay : Off Clock If the current time is incorrect, reset the clock manually. 1) Press the MENU button and then use ∧∨<...

  • Page 30: Selecting Options

    User Menus Selecting Options OPTION Move Language : English Language : English Input Label Key Lock : Off Set ID : Off ISM Method : Normal DPM Select : On Power Indicator : ON Interface Select : RS232C Language Chooses the language in which the control names are displayed. Input Label Selects a label for each input source.
  • Page 31 User Menus Selecting Options OPTION Move ▲ ISM Method : Normal DPM Select : On DPM Select : On Power Indicator : ON Interface Select : RS232C Network Setup Information Factory Reset DPM Select Turns power saving on/off. Power Indicator Sets the power indicator on the front side of the set to On or Off.

  • Page 32: Screen Tiling Options

    User Menus Screen Tiling Options Tile Mode TILE Move - Must be displayed with various other set. Tile Mode : 2x2 Tile Mode : Off - Must be in a function that can be connected Tile ID to RS-232C or RGB Out. Natural Mode : Off H Size...
  • Page 33 User Menus Screen Tiling Options - Tile Mode (set 1 to 9): c(3) x r(3) Column ID 3 ID 1 ID 2 ID 4 ID 5 ID 6 ID 9 ID 7 ID 8 - Tile Mode (set 1 to 2): c(2) x r(1) Column - Tile Mode (set 1 to 16): c(4) x r(4) Column...

  • Page 34: Usb Options

    User Menus USB Options Connecting USB Devices When you connect a USB device, this pop-up menu is displayed, automatically. The pop-up menu will not be displayed while the OSD, EPG or Schedule list is displayed. When the pop-up menu appears, you can select Music List, Photo List or Movie List in the MY MEDIA menu.
  • Page 35 User Menus USB Options Precautions when using the USB device • Only a USB storage device is recognizable. • If the USB storage device is connected through a USB hub, the device is not recognizable. • A USB storage device using an automatic recognition program may not be recognized. •...

  • Page 36: Photo List

    User Menus USB Options Photo List You can view photo files on USB storage devices. The On-Screen Display may be different from your set. Images are an example to assist with set operation. Supported JPG Photo File Types Baseline: 15360 x 8640 Progressive: 1024 x 768 •...
  • Page 37 User Menus USB Options Photo Selection and Pop-Up Menu USB Device Photo List Page 2/3 No Marked Free Space 150 MB Drive1 Up Folder KY103 02/12/2010 JMJ001 KY101 02/12/2010 KY104 02/12/2010 KY102 02/12/2010 KY105 02/12/2010 JMJ001 02/12/2010 JMJ005 02/12/2010 JMJ002 02/12/2010 JMJ006 02/12/2010...

  • Page 38: Viewing Photos

    User Menus USB Options Viewing Photos Detailed operations are available on the full-sized photo view screen. The aspect ratio of a photo may change the size of the photo displayed on the screen in full-size. Press EXIT to move to the previous menu.

  • Page 39: Music List

    User Menus USB Options Music List You can play music files stored on USB storage devices. Purchased music files (*.MP3) may have copyright restrictions. Playback of these files may not be supported by this set. The On-Screen Display may be different from your set. Images are an example to assist with set operation.
  • Page 40 User Menus USB Options Music Selection and Pop-Up Menu Up to 6 music files are listed per page. Play (During stop): Plays the selected USB Device Music List Page 2/3 No Marked Free Space 150 MB music files. When playback of a file stops, Music Title Duration...
  • Page 41 User Menus USB Options If you don't press any button for a while during playback, the play information box (as shown below) will display as a screen saver. What is the ‘Screen Saver’? The screen saver prevents screen pixel damage due to a fixed image remaining on the screen for an extended period of time.

  • Page 42: Movie List

    User Menus USB Options Movie List The movie list is activated once a USB device is detected. It is used when playing movie files on the set. Movies in the USB folder can be played. Video editing is not supported but files can be deleted.

  • Page 43: Screen Components

    User Menus USB Options Screen Components USB Device Movie List Page 2/3 No Marked Free Space 150 MB Movie Title Duration M002 Up Folder Favorite Music M001 01:34:15 M002 640x480, 720KB 01:35:30 M001 01:30:20 Up Folder M001 Navigation Option Page Change Mark Exit MARK...
  • Page 44 User Menus USB Options Movie Selection and Pop-Up Menu USB Device Movie List Page 2/3 No Marked Free Space 150 MB Movie Title Duration M002 Up Folder Favorite Music M001 M002 01:34:15 640x480, 720KB M001 01:35:30 01:30:20 Up Folder M001 Navigation Option Page Change...

  • Page 45: Adjusts The Usb Options

    User Menus Adjusts the USB options. When you select the Movie Option, Picture Size Full Screen Subtitle Language Audio Language Subtitle File ● Language Latin 1 ● Sync +0.5 ● Position Option Picture Size : Sets to [Full Screen] or [Original Size]. Subtitle Language : Allows to select the language you want for the file with multiple subtitle tracks.
  • Page 46 User Menus USB Options DivX Registration Code Move Photo List Music List Movie List DivX(R) Video On Demand DivXReg. Code DivX Reg. Code ꔉ Your registration Code is: xxxxxxxxxx Deactivation To learn more visit www.divx.com/vod. Close Close Confirm the DivX registration code of the set. Using the registration code, movies can be rented or purchased at www.divx.com/vod.
  • Page 47 User Menus USB Options Deactivation Move Photo List Music List Movie List DivX Reg. Code Deactivation DivX(R) Video On Demand Deactivation ꔉ Do you want to deactivate your device? DivX(R) Video On Demand This device is deactivated. Your deactivation code is: xxxxxxxx To learn more visit www.divx.com/vod.

  • Page 48: Troubleshooting

    'Unknown Set' Message Appears When the Television is Connected ● Did you install the driver? • Install the television driver provided with the television, or download it from http://www.lg.com. • See if the plug & play function is supported by referring to your video card user manual.
  • Page 49 Troubleshooting The Screen Image Looks Abnormal ● Is the screen position wrong? • D-Sub analog signal - Press AUTO on the remote control to automatically select the optimal screen status that fits the current mode. If adjustment is not satisfactory, use the OSD Position menu.
  • Page 50 Troubleshooting The Audio Does Not Work ● No sound? • See if the audio cable is connected properly. • Adjust the volume. • See if the sound is set properly. ● Sound is too dull. • Select the appropriate equalizer setting. ●...

  • Page 51: Specifications

    Specifications < M3704C > 94.0 cm ( 37 inch) TFT (Thin Film Transistor) LCD Panel LCD (Liquid Crystal Display) Panel Visible diagonal size : 94.0 cm 0.4845 mm x 0.4845 mm X RGB (Pixel Pitch) Power Rated Voltage AC 100-240 V~ 50 / 60 Hz 1.9 A...
  • Page 52 Specifications < M4225C > 106.73 cm ( 42.02 inch) TFT (Thin Film Transistor) LCD Panel LCD (Liquid Crystal Display) Panel Visible diagonal size : 106.73 cm 0.4845 mm x 0.4845 mm X RGB (Pixel Pitch) Rated Voltage AC 100-240 V~ 50 / 60 Hz 2.3 A Power Power Consumption On Mode...
  • Page 53 Specifications Video Signal Max. Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type. Recommended Resolution RGB : 1920 x 1080 @ 60 Hz HDMI/DVI : 1920 x 1080 @ 60 Hz - It may not be supported depending on the OS or video card type.

  • Page 54: Dtv Mode

    1 to 17: RGB mode *: HDMI/DVI mode DTV Mode HDMI/DVI (DTV) Component 480i 576i 480p 576p 720p 1080i 1080p Power Indicator < M3704C > < M4225C > Mode Mode On Mode Green On Mode Blue Sleep Mode Amber Sleep Mode Amber Off Mode...

  • Page 55: Connecting The Cable

    Controlling Multiple Set RS-232C Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. If the [Set ID] menu in [Option] is set to OFF, the monitor ID value should be set between 1 and 99. Connecting the cable Connect the RS-232C cable as shown in the picture.

  • Page 56: Command Reference List

    Controlling Multiple Set RS-232C Command Reference List COMMAND 1 COMMAND 2 DATA1 DATA2 DATA3 01. Power 00H to 01H 02. Input Select 02H to 09H 03. Aspect Ratio 01H to 1FH 04. Screen Mute 00H to 01H 05. Volume Mute 00H to 01H 06.
  • Page 57 Controlling Multiple Set RS-232C COMMAND 1 COMMAND 2 DATA1 DATA2 DATA3 02H to 09H 38. Scheduling input select F1H to F4H 39. Sleep Time 00H to 08H 40. Auto Sleep 00H to 01H 41. Power On Delay 00H to 64H 42.
  • Page 58 Controlling Multiple Set RS-232C Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command 1]: First command. (k, j, m, d, f, x) * [Command 2]: Second command.(a to u) * [Set ID]: Set up the Set ID number of product. range : 01H to 63H.
  • Page 59 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 01. Power(Command : a) ► To control Power On / Off of the Set. Transmission [k][a][ ][Set ID][ ][Data][Cr] Data 0 : Power Off 1 : Power On Acknowledgement [a][ ][Set ID][ ][OK][Data][x] ►...
  • Page 60 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 03. Aspect Ratio(Command : c) (Main picture format) ► To adjust the screen format. You can also adjust the screen format using the ARC (Aspect Ratio Control) button on remote control or in the Screen menu.
  • Page 61 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 05. Volume Mute(Command : e) ► To control On/Off of the Volume Mute. Transmission [k][e][ ][Set ID][ ][Data][Cr] Data 0 : Volume Mute On (Volume Off) 1 : Volume Mute Off (Volume On) Acknowledgement [e][ ][Set ID][ ][OK][Data][x] Data 0 : Volume Mute On (Volume Off)
  • Page 62 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 07. Contrast(Command : g) ► To adjust screen contrast. You can also adjust the contrast in the Picture menu. Transmission [k][g][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H Acknowledgement [g][ ][Set ID][ ][OK][Data][x] Refer to 'Real data mapping' page A7.
  • Page 63 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 09. Color(Command : i) (Video Timing only) ► To adjust the screen color. You can also adjust the color in the Picture menu. Transmission [k][i][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H (Hexadecimal code) Refer to 'Real data mapping' page A7.
  • Page 64 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 11. Sharpness(Command : k) (Video Timing only) ► To adjust the screen Sharpness. You can also adjust the sharpness in the Picture menu. Transmission [k][k][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H (Hexadecimal code) Refer to 'Real data mapping' page A7.
  • Page 65 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 14 Balance(Command : t) ► To adjust the sound balance. Transmission [k][t][ ][Set ID][ ][Data][Cr] Data Min : 00H to Max : 64H (Hexadecimal code) 00H : Step L50 64H : Step R50 Acknowledgement [t][ ][Set ID][ ][OK][Data][x] Data...
  • Page 66 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 16. Abnormal state (Command : z) ► Abnormal State : Used to Read the power off status when Stand-by mode. Transmission [k][z][ ][Set ID][ ][Data][Cr] Data FF : Read Acknowledgement [z][ ][Set ID][ ][OK][Data][x] 0 : Normal (Power on and signal exist) 1 : No signal (Power on) 2 : Turn the monitor off by remote control...
  • Page 67 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 18. Auto Configure(Command: j u) ► To adjust picture position and minimize image shaking automatically. it works only in RGB(PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 1 : To set Acknowledgement [u][ ][Set ID][ ][OK][Data][x] 19.
  • Page 68 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 20. Tile Mode(Command : d d) ► Change a Tile Mode. Transmission [d][d][ ][Set ID][ ][Data][x] Data Description 00 or 11 Tile mode is off. 1 x 2 mode(column x row) 1 x 3 mode 1 x 4 mode 5 x 5 mode * The data can not be set to 0X or X0 except 00.
  • Page 69 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 21. Tile H Position(Command : d e) ► To set the Horizontal position. Transmission [d][e][ ][Set ID][ ][Data][x] Data Min : 00H to Max : 14H 00H : Step -10(Left) 14H : Step 10(Right) Acknowledgement [e][ ][Set ID][ ][OK/NG][Data][x] 22.
  • Page 70 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 23. Tile H Size(Command : d g) ► To set the Horizontal size. Transmission [d][g][ ][Set ID][ ][Data][x] Data Min : 00H to Max : 64H Refer to 'Real data mapping' page A7. Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x] 24.
  • Page 71 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 25. Tile ID Set(Command : d i) ► To assign the Tile ID for Tiling function . Transmission [d][i][ ][Set ID][ ][Data][x] Data Min : 00H to Max : 19H (Hexadecimal code) Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x] 26 Natural Mode (In Tile mode) (Command : d j)
  • Page 72 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 28. Sound Mode (Command : d y ) ► To adjust the Sound mode. Transmission [d][y][][Set ID][][Data][X] Data Structure Mode Data(Hex) Standard Music Cinema sport Game Acknowledgement [y][][Set ID][][OK/NG][Data][x] 29. Fan Fault check (Command : d w ) ►...
  • Page 73 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 30. Elapsed time return(Command : d l) ► To read the elapsed time. Transmission [d][l][ ][Set ID][ ][Data][x] * The data is always FF(in Hex). Acknowledgement [l][ ][Set ID][ ][OK/NG][Data][x] * The data means used hours. (Hexadecimal code) 31.
  • Page 74 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 33. Auto volume (Command : d u) ► Automatically adjust the volume level. Transmission [d][u][][Set ID][][Data][x] Data 0 : Off 1 : On Acknowledgement [u][][Set ID][][OK/NG][Data][x] 34. Speaker (Command : d v) ►...
  • Page 75 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 35. Time (Command : f a) ► Set the current time. Transmission [f][a][][Set ID][][Data1][][Data2][][Data3][Cr] [Data1] 0 : Monday 1 : Tuesday 2 : Wednesday 3 : Thursday 4 : Friday 5 : Saturday 6 : Sunday [Data2] 0H to 17H (Hours)

  • Page 76: Transmission / Receiving Protocol

    Controlling Multiple Set RS-232C Transmission / Receiving Protocol 36. On Timer (On/Off Timer) Time (Command : f d) ► Set On Timer. Transmission [f][d][][Set ID][][Data1][][Data2][][Data3][Cr] [Data1] 1. f1h to f4h(read one index) f1: read 1st index of On Time List, f2: read 2nd index of On Time List f3: read 3rd index of On Time List f4: read 4th index of On Time List...
  • Page 77 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 37. Off Timer (On/Off Timer) Time (Command : f e) ► Set Off Timer. Transmission [f][e][][Set ID][][Data1][][Data2][][Data3][Cr] [Data 1] 1. f1h to f4h(read one index) f1: read 1st index of Off Time List, f2: read 2nd index of Off Time List f3: read 3rd index of Off Time List f4: read 4th index of Off Time List...
  • Page 78 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 38. Scheduling Input select (Command : f u) (Main Picture Input) ► To select input source for SET depending on day. Transmission [f][u][][Set ID][][Data1][][Data2][Cr] [Data 1] 1. f1h to f4h(write/read one index) f1: read 1st index of On Time Input f2: read 2nd index of On Time Input f3: read 3rd index of On Time Input...
  • Page 79 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 39. Sleep Time (Command : f f) ► Set Sleep Time. Transmission [f][f][][Set ID][][Data][Cr] Data 0 : Off 1 : 10 2 : 20 3 : 30 4 : 60 5 : 90 6 : 120 7 : 180 8 : 240...
  • Page 80 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 41. Power On Delay (Command : f h) ► Set the schedule delay when the power is turned on (Unit: second). Transmission [f][h][][Set ID][][Data][Cr] Data : 00H to 64H (Data value) Refer to 'Real data mapping' page A7 Acknowledgement [h][][Set ID][][OK/NG][Data][x] 42.
  • Page 81 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 43. DPM Select (Command : f j) ► Set the DPM (Display Power Management) function. Transmission [f][j][][Set ID][][Data][Cr] Data 0 : Off 1: On Acknowledgement [j][][Set ID][][OK/NG][Data][x] 44. Reset (Command : f k) ►...
  • Page 82 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 45. Power saving(Command : f I) ► To set the Power saving mode. Transmission [f][I][][Set ID][][Data][Cr] Data 0 : Off 1: (static level 1) 2: (static level 2) 3: (static level 3) Acknowledgement [I][][Set ID][][OK/NG][Data][x] 46.
  • Page 83 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 47. Serial no.Check (Command : f y) ► To read the serial numbers Transmission [f][y][][Set ID][][Data][Cr] Data FF (to read the serial numbers) Acknowledgement [y][][Set ID][][OK/NG][Data1] ~ [Data13] [x] * The data format is ASCII Code. 48.
  • Page 84 Controlling Multiple Set RS-232C Transmission / Receiving Protocol 49. Input Select (Command : x b) ► To select input source for the Set. Transmission [x][b][][Set ID][][Data][Cr] Data 20H : AV 40H : Component 60H : RGB (PC) 90H : HDMI/DVI (DTV) A0H : HDMI/DVI (PC) Acknowledgement [b][ ][Set ID][ ][OK][Data][x]...
  • Page 85 Controlling Multiple Set IR Codes RS-232C RS-232C Remote Control IR Code Output waveform single pulse, modulated with 37.917kHz signal at 455kHz Carrier frequency FCAR = 1 / Tc = fosc / 12 Duty ratio = T1 / Tc = 1 / 3 ►...
  • Page 86 Controlling Multiple Set IR Codes RS-232C RS-232C Code(Hex) Function Note R/C Button UP(∧) R/C Button DOWN(∨) R/C Button RIGHT( > ) R/C Button LEFT(< ) R/C Button POWER ON/OFF R/C Button MONITOR ON (Discrete IR Code) R/C Button MONITOR OFF (Discrete IR Code) R/C Button MUTE...
  • Page 87 Controlling Multiple Set IR Codes RS-232C RS-232C Code(Hex) Function Note R/C Button Bright∧(Page UP) R/C Button Bright∨(Page Down) R/C Button BACK AUTO CONFIC R/C Button (Discrete IR Code) R/C Button ID ON(Red Color) R/C Button ID OFF(Green Color) (Yellow Color) R/C Button R/C Button (Blue Color )
