- Page 1 RJP-201M Remote Jack Pack Installation & Setup Guide Warranty © Copyright 2010, LG Electronics U.S.A., Inc.
-
Page 2: Safety Warnings
• CAUTION: Do not attempt to modify this product in any way (except as noted herein) without written authoriza- tion from LG Electronics U.S.A., Inc. Unauthorized modification could void the user’s authority to operate this product. COMPLIANCE: The responsible party for this product’s compliance is: LG Electronics U.S.A., Inc., 2000 Millbrook Drive... -
Page 3: Table Of Contents
Troubleshooting Flow Chart ........18 RJP-201M Scaler RJP Supported Timing List ......19 Quick Setup Guide . -
Page 4: Overview
Overview The Remote Jack Pack (RJP) contains circuitry to determine the pres- ence of a signal at each input jack. (Note: Audio In, Audio In L-R and Video In inputs detect the pres- ence of the inserted plug, regardless if a signal is present or not.) When a source is detected, its priority is compared to the priority of other sources which may be present. - Page 5 Introduction Conveniently installed right in the room where guests will stay, the LG Remote Jack Pack, (RJP) multi-media interface is available to end-users to connect audio, video and computer devices to hear and view on the in-room TV display panel.
-
Page 6: Accessories
Accessories Supplied Accessories Ensure that the following accessories are included with your product. Network Cable (8-Pin RJ-45) Mixed Signal Cable Assembly Installation & Setup Guide w/Black Protective Sleeve (approx.6.0 feet) 6-Pin RJ-11 Phone Cable 5-Retainer Clips, L-Shaped 5-Machine Screws w/Serrated (approx.6.0 feet) Washers... - Page 7 Mixed Signal Breakout Cable Mixed Signal In Mixed Signal Breakout Cable Item Description Audio Cable (Left/Right) Gender Cable Digital Video Cable Assembly Control Cable (8-pin RJ-45) approx. 12.9 Feet Length Control Audio Cable Digital Video Cable (L - R) Cable Note: The actual appearance of the cable, cabinet, mounting hardware etc., may be different than shown in these drawings.
-
Page 8: Installation In Cabinet Backsplash
Installation in Cabinet Backsplash The RJP-201M can only be installed in a vertical position into the backsplash of the cabinet. Vertical mounting in the backsplash is required so that if liquid is spilled on the desk top, it will not be able to flow into the RJP. The RJP must only be installed in the backsplash panel cutout opening. -
Page 9: Installer Connections
Installer Connections The RJP-201M and the cables listed below are to be connected to both the TV display panel and any entertainment resources available in the room. CAUTION: Be sure power is turned off before attempting to connect the RJP-201M to the TV display panel and in-room resources. -
Page 10: Installation Mixed Signal Breakout Cable
Installation Mixed Signal Breakout Cable CAUTION: Be sure power is turned off before attempting to connect the RJP to the TV display panel. 1. Take off the two-sided tape that is 2. Attach the Mixed Signal Breakout cable attached to the Mixed Signal Breakout to TV display panel on the back. -
Page 11: Connections To Tv Display Panel
Connections to TV Display Panel After completing connections between the RJP and the TV display panel, be sure the installer menu items have been updated to enable the RJP. Installer Menu item 040 Auto Camport needs to be set to 000 and 093 RJP Available needs to be set to 005 or 006. -
Page 12: End-User Operation
End-User Connections Overview The end-user simply plugs a device such as a laptop computer with the appropriate cables, as shown in the example, into the RJP connection panel. The Remote Jack Pack senses the new source connection and switches the TV to the newly-connected source. The device’s sound and image are then presented on the in- room TV display panel. -
Page 13: End-User Multi-Media Interface Connections
End-User Multi-Media Interface Connections USB Charging Port Reset Switch Connection for USB Circuit breaker for device charging. AC power outlets. USB Sync Port Connection for playing multi-media file. DIGITAL VIDEO IN CHARGE SYNC 10 AMP MAXIMUM CURRENT PC VIDEO IN 3.5 mm Stereo Audio Input Jack AC Power Outlets... -
Page 14: End-User Connectable External Source Devices
End-User Connectable External Source Devices Examples of devices a guest/end-user can connect are shown to the right. There are four AC power outlets available on the jack pack for added convenience. The End-User Can Connect: PC Laptop/Notebook Computers • Portable Video Game Players •... -
Page 15: Specifications
Specifications Application Makes available to the hotel’s guests, a multi-media interface to the in-room TV display panel and media resources. Input jacks are provided for external portable devices such as DVD/CD Players, Laptop Computers, Camcorders, etc. Dimensions Height 4.08 Inches (103.6 mm) Width 16.49 Inches... - Page 16 Specifications Regulatory UL, FCC Class B, Digital Video Device Environmental Parameters Operating Temperature 0° to 40° Degrees Celsius (32° to 104° Degrees Fahrenheit) Storage Temperature -20° to 85° Degrees Celsius (-4° to 185° Degrees Fahrenheit) Cooling Free Air Convection Humidity 10% to 90% Non-condensing Supplied Accessories List (Cable Assembly)
-
Page 17: Troubleshooting
Make sure all connectors and connections are tight and secure on user device, RJP-201M and TV. • Check to assure user device, RJP-201M and TV are all powered up and working properly and that the TV • Installer menu items are set correctly. -
Page 18: Troubleshooting Flow Chart
Troubleshooting Flow Charts No Audio (or No Audio (or not desired Power not desired Audio) Audio) Power Restore Has Circuit Remove AC Failure? Has Circuit Remove AC Power Breaker load, press Breaker load, press Tripped RESET Tripped RESET Connect Is power cord Power connected Connect... -
Page 19: Rjp-201M Scaler Rjp Supported Timing List
RJP-201M Scaler RJP Supported Timing List 1. Input 2. Output Format Format Video Input Comments Video Output Comments (Pixels x Lines) (Pixels x Lines) 640x350@70 RGB/HDMI(DVI) 800x600@60 HDMI(DVI) Installer Menu only 640x400@70.085 RGB/HDMI(DVI) 1360x768@60 HDMI(DVI) Shipping Default 640x400@85 RGB/HDMI(DVI) 1680x1050@60... -
Page 20: Quick Setup Guide
Quick Setup Guide Installer RJP-201M Quick Setup Reference Guide Following are the tasks associated 4. Adjust TV installer menu items 040 6. Provide user information in with installing and setting up an and 093 to enable RJP capability. room. (As applicable to your enter- RJP-201M System. - Page 21 Memo...
- Page 22 Memo...
- Page 23 Memo...
-
Page 24: Warranty
LG RJP-201M Warranty Remote Jack Pack Welcome to the LG family! We believe that you will be pleased with your new LG product. Please read this warranty carefully, it is a “LIMITED WARRANTY” as defined under Federal Law. This warranty gives you specific legal rights, and you may also have other rights that vary from state-to-state within the U.S.A.
