- Page 1 READ ME FIRST Windows® NT ® *DSL Equipment Installation Guide: Alcatel Speed Touch PC® *Digital Subscriber Line Part Number: AlcatelPCNT02 Version 1.2 ©2001 SBC Advanced Solutions, Inc. All rights reserved.
-
Page 2: Table Of Contents
Table of Contents Follow Steps 1 through 7 to complete the DSL Equipment Installation Step 1: Verify Your System Requirements and Documents Step 2: Verify the Contents of Your DSL Equipment Kit Step 3: Install a Telephone Filter on Every Telephone Line Step 4: Select Modem and Minimum Requirements Check Step 5: Installing the Alcatel Speed Touch PC®... -
Page 3: Step 1: Verify Your System Requirements And Documents
Step 1 : Verify Your System Requirements and Documents This Installation Guide is for Windows® NT users only. The SBC Express software will ensure that you meet the following minimum requirements. You will not be able to complete the installation without meeting these requirements. PC with a Pentium-class processor, CD-ROM Drive, 166 MHz, 25 Mb free disk space, •... -
Page 4: Step 2: Verify The Contents Of Your Dsl Equipment Kit
Step 2 : Verify the Contents of Your DSL Equipment Kit Your DSL Equipment Kit Contains: A: This Installation Guide and the SBC Express CD. B: 1 Alcatel Speed Touch PC Internal Modem ® C: 1 Filter Pack containing: 5 in-line filters, 1 wall-mount filter, 1 two-way adapter, and 1 data cable. Note: Internet Software and/or instructions may be provided in this box or separately by your Internet Service Provider. -
Page 5: Step 3: Install A Telephone Filter On Every Telephone Line
Step 3 Install a Telephone Filter on Every Telephone Line Determine how many telephone jacks in your home share the same telephone number with the activated DSL. 1) Locate the phone jack where you want to connect your DSL 2) Insert the 2-way adapter in the phone jack 3) Connect a filter to... - Page 6 4) If you have a phone, fax machine, analog modem or other phone device at this location, connect it to the filter 5) Connect the data cable that will go to your DSL modem to the unfiltered side of the 2-way adapter To the DSL modem Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 5...
- Page 7 Install a filter on all other phones and phone devices Why do I need a filter on all my other phones and phone devices? Converting your regular phone line into a high-speed Digital Subscriber Line (DSL) can cause audible noise (high pitched tones and static) when you talk on the phone. You need to install a filter on every telephone or device that shares the same phone number as your DSL line to eliminate this noise.
- Page 8 Other filters you may encounter in your DSL Equipment Kit. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 7 ©2001 SBC Advanced Solutions, Inc. All rights reserved...
-
Page 9: Step 4: Select Modem And Minimum Requirements Check
Step 4 Select Modem and Minimum Requirements Check Insert the SBC Express CD into your CD-ROM drive. SBC Express should start automatically. If not, select Run from the Windows Start menu. Type “D:\Launch.exe”. (Substitute the appropriate letter of your CD-ROM drive for “D”.) Select Alcatel Speed Touch PC and click Next. - Page 10 SBC Express displays the Welcome screen. Click Next to proceed. SBC Express displays the license agreement. If you agree to the terms, click Accept. If you do not accept, installation cannot continue. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 9 ©2001 SBC Advanced Solutions, Inc.
- Page 11 SBC Express now prompts you for your first and last name. Please type your first and last name and then click Next to proceed. Do not enter Technician Name. Enter your 10-digit DSL phone number in the next screen. Click Next to proceed. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 10 ©2001 SBC Advanced Solutions, Inc.
- Page 12 SBC Express quickly checks your computer system to ensure that it meets the minimum requirements for DSL service. SBC Express has determined that you need to install the Alcatel Speed Touch PC. Click Shutdown and proceed to step 5 to install the Alcatel Speed Touch PC. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 11 ©2001 SBC Advanced Solutions, Inc.
-
Page 13: Step 5: Installing The Alcatel Speed Touch Pc
Step 5 ® Installing the Alcatel Speed Touch PC If you shutdown your computer, leave the CD in the the CDROM drive, and SBC Express will continue after you restart. You should be at the following screen in the SBC Express Software: Click Shutdown in SBC Express and then turn off all peripheral devices. - Page 14 Remove the metal PCI slot cover from the unused PCI slot, and retain the screw. PCI Slot Remove PCI slot cover Carefully insert the Alcatel Speed Touch PC adpter into any empty PCI slot. Make sure the card is completely seated by pressing firmly. Verify that the end bracket is flush against the chassis.
- Page 15 Installing the Alcatel Speed Touch PC® Software 5-11 Turn on your computer. • NOTE: Windows NT will NOT automatically detect your Alcatel Speed Touch PC ® adapter. SBC Express will display the screen below. Please IGNORE this screen and proceed to step 5-12. Do NOT Cancel SBC Express. 5-12 Right click on the Network Neighborhood icon and select Properties.
- Page 16 5-13 Click on the Adapters tab. 5-14 Click on the Add button. 5-15 Click on the Have Disk button. 5-16 The SBC Express has copied all the necessary files to “C:\Temp”. At this prompt please type in C:\Temp and click OK. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 15 ©2001 SBC Advanced Solutions, Inc.
- Page 17 5-17 Windows NT will presents the following select OEM option screen, select ITeX ADSL PCI NIC and click OK. ( Note: The IteX ADSL PCI NIC is the Alcatel Speed Touch PC adapter. This is the formal adapter name used for NT ) 5-18 After you install the driver software, the ITeX ADSL PCI NIC will appear under Network Adapters.
- Page 18 You will be prompted to bind a TCIP/IP address to the Adapter. Select the ITeX ADSL 5-19 PCI NIC in the drop down box in the Microsoft TCP/IP Properties window shown below. Next, click “Specify an IP address.” Fill in the IP address with the dummy IP of 10.0.0.1 and Subnet Mask of 255.0.0.0.
- Page 19 5-21 SBC Express will re-run the Minimum Requirements test and detect the newly installed Alcatel Speed Touch PC adapter and complete, stopping at the following screen. If problems are detected follow the instructions on the screen or look at the troubleshooting section of this manual for further information.
-
Page 20: Step 6: Finish Configuring Your System
Step 6 Finish Configuring Your System If the Alcatel Speed Touch PC card is installed properly, you will see the following screen. You must now connect the Alcatel Speed Touch PC to the phone jack prepared in Step 3. Connect the Alcatel Speed Touch ADSL modem, see diagram below. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 19 ©2001 SBC Advanced Solutions, Inc. - Page 21 To determine if your DSL modem has made a good connection look at the icon in the system tray. If both lights are black then you have a good connection. If either light is red or there is a red circle with a slash through it then check the diagnostic guide in appendix E for help.
- Page 22 Congratulations! You have finished setting up your DSL hardware. Click Finished in SBC Express and then proceed to Step 7. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 21 ©2001 SBC Advanced Solutions, Inc. All rights reserved...
-
Page 23: Step 7: Follow The Instructions Provided Separately By Your Internet Service Provider
Step 7 Follow the Instructions Supplied by your Internet Service Provider Your Internet Service Provider may have provided you additional instructions in this box or separately. These instructions may contain information about account setup, additional software installation, and/or Internet usage. Please follow those instructions to complete your Internet connection setup. -
Page 24: Appendices
Appendices Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 23 ©2001 SBC Advanced Solutions, Inc. All rights reserved... -
Page 25: Having Trouble
APPENDIX A Having Trouble? If the suggestions below don’t resolve your problem, technical support is available from your Internet Service Provider. Please refer to the Internet Service Provider's information on how to contact them for technical assistance. I can’t open my computer case. What do I do? •... -
Page 26: Uninstalling/Reinstalling The Alcatel Speed Touch Pc® Adapter
APPENDIX B Uninstall/reinstall the Alcatel Speed Touch PC® Adapter Uninstalling (and reinstalling) the Alcatel Speed Touch PC® adapter in Windows® 1. Select Start -> Settings -> Control Panel. Double-click the Network icon and choose the Adapters tab. 2. Highlight the Alcatel Speed Touch PC® Adapter and click the Remove button. 3. -
Page 27: Adding Tcp/Ip To Windows Nt
APPENDIX C Adding TCP\IP to Windows NT Right click on the network neighborhood icon and select properties. 2. Click on the ‘Protocols’ tab and click ‘Add’. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 26 ©2001 SBC Advanced Solutions, Inc. All rights reserved... - Page 28 3. Select the ‘TCP/IP Protocol’ and click ‘OK.’ 4. Specify the path of your NT installation files or insert the Windows NT CD-ROM and specify the I386 folder. 5. Select “No” when NT asks ‘Do you wish to use DHCP?’. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 27 ©2001 SBC Advanced Solutions, Inc.
- Page 29 6. After clicking “No”, TCP/IP should appear under the protocols tab. 7. Click “Close” to bind all the information. You must restart your computer for the settings to be stored. Installation Guide for Customer Self-Install: Alcatel Speed Touch PC®, Windows NT Page 28 ©2001 SBC Advanced Solutions, Inc.
-
Page 30: Troubleshooting Sbc Express
APPENDIX D Troubleshooting SBC Express Please refer to this list if you are having problems using SBC Express or if you receive an error message. Step Problem Solution Launch The following dialog appears: Reset your display to 256 colors or more. SBC Express will not run in 16 color mode. - Page 31 Unknown This scenario can occur if a NIC is physically present and Use the “Fix” button to launch the appropriate Network detected by Plug-n-Play, but no drivers were installed for the control panel and context sensitive help to Interface NIC. Windows will add this device to the “Other Devices” guide you through removing the “Unknown Adapter section in the Device Manager.
-
Page 32: Modem Diagnostic Lights
APPENDIX E Modem Diagnostic Lights To help identify a problem with the modem connection please look at the icon on located in the system tray as seen below. By comparing the lights to the table below you should be able to determine the problem. Diagnostic Icon Red, Red No ADSL connection or handshaking.
