La Crosse Technology 306-605 Quick Installation Manual

Digital Solar Window Thermometer
Model 306-605
FEATURES

Clear Functional Design

Maximum and Minimum Values with
Auto Reset

Clock

Easy Removal for Cleaning

Automatic Backlight for Easy reading in
the Dark

Weather Resistant
BUTTONS (see Fig. 2)
H. MODE Button
I. + 1 Button
J. +/- 1hr Button
K. ECO Slide
Fig. 2
HOLDER (see Fig. 4)
O. Holder
HOUSING (see Fig. 3)
L. Temperature Probe
M. Battery Compartment
N. Solar Panel
Fig. 4
DISPLAY (see Fig. 1)
A. Battery Indicator
B. AM/PM for 12 hour time
C. Time
D. DST (Daylight Savings Time) Indicator
E. Temperature
F. MIN Temperature
G. MAX Temperature
1
QUICK INSTALLATION GUIDE

Thoroughly clean the window where the thermometer holder will be attached.

Remove the thermometer holder from the thermometer by sliding it towards the bottom of
the thermometer.

Pull off the protection foil on the display

Attach the thermometer holder to the outside of the window with the enclosed adhesive
tape. (Be sure to mount with the frame "bar" down.)

Check that the bottom bar is in place to "catch" the thermometer, then hang the
thermometer on the holder by sliding it down into the holder.
Note: The thermometer is fragile. . When you mount or remove the thermometer, avoid action
that would bend or pull on it.
Fig. 3
SETUP INSTRUCTIONS

Remove the thermometer holder from the thermometer by sliding it towards the bottom of
the thermometer.

Pull off the protection foil on the display.

Open the battery compartment with a small Phillips screwdriver.

Insert the NiMh AAA battery (included) on the left. Make sure to observe the correct
polarity.

Insert the alkaline AAA battery (included) on the right. Make sure to observe the correct
polarity.
Ensure the NiMh Battery is Charged: The 1.2V NiMh rechargeable battery for the backlight is
not fully charged when shipped. For maximum efficiency it is recommended to either:
a) charge the battery fully (place thermometer outside on a sunny day) before first use
b) Recharge the NiMh battery in an appropriate NiMh-capable battery charger.
After the rechargeable battery is charged:

Re-insert the NiMh battery (if a charger was used).

Replace the battery compartment cover.
3
Fig. 1
2
4
