Hoshizaki KML-250MWH Instruction Manual

Hoshizaki KML-250MWH Instruction Manual

Low-profile modular crescent cuber
Hide thumbs Also See for KML-250MWH:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Hoshizaki
Hoshizaki America, Inc.
"A Superior Degree
of Reliability"
www.hoshizaki.com
Low-Profile Modular Crescent Cuber
Models
KML-250MAH
KML-250MWH
INSTRUCTION MANUAL
™
Issued: 9-18-2001
Revised: 2-4-2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KML-250MWH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki KML-250MWH

Summary of Contents for Hoshizaki KML-250MWH

  • Page 1 Hoshizaki Hoshizaki America, Inc. Low-Profile Modular Crescent Cuber Models KML-250MAH KML-250MWH INSTRUCTION MANUAL “A Superior Degree of Reliability” www.hoshizaki.com ™ Issued: 9-18-2001 Revised: 2-4-2011...
  • Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write, or send an e-mail message to the Hoshizaki Technical Support Department for assistance. HOSHIZAKI AMERICA, INC.

  • Page 3: Table Of Contents

    Important Safety Information ....................4 I. Specifications ........................5 A. Nameplate Rating ......................5 1. KML-250MAH (air-cooled) ..................5 2. KML-250MWH (water-cooled) .................. 6 B. Dimensions/Connections ....................7 1. KML-250MAH (air-cooled) ..................7 2. KML-250MWH (water-cooled) .................. 8 II. Installation and Operating Instructions ................9 A.

  • Page 4: Important Safety Information

    Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. WARNING Indicates a hazardous situation which could result in death or serious injury. CAUTION Indicates a situation which could result in damage to the unit.

  • Page 5: Specifications

    I. Specifications A. Nameplate Rating 1. KML-250MAH (air-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KML-250MAH SERIAL NUMBER AC SUPPLY VOLTAGE 115/60/1 COMPRESSOR 115V 7RLA 33.6LRA PUMP 120V 0.5FLA 115V 1.2FLA OTHER 115-120V 0.2A MAXIMUM FUSE SIZE 20 AMPS MAX. HACR BREAKER(USA ONLY) 20 AMPS MAX.

  • Page 6: Kml-250Mwh (Water-Cooled)

    2. KML-250MWH (water-cooled) HOSHIZAKI ICE MAKER MODEL NUMBER KML-250MWH SERIAL NUMBER AC SUPPLY VOLTAGE 115/60/1 COMPRESSOR 115V 6.7RLA 33.6LRA PUMP 120V 0.5FLA OTHER 115-120V 0.2A MAXIMUM FUSE SIZE 20 AMPS MAX. HACR BREAKER(USA ONLY) 20 AMPS MAX. CIRC. BREAKER (CANADA ONLY)

  • Page 7: Dimensions/Connections

    B. Dimensions/Connections 1. KML-250MAH (air-cooled)

  • Page 8: Kml-250Mwh (Water-Cooled)

    2. KML-250MWH (water-cooled)

  • Page 9: Installation And Operating Instructions

    • This icemaker can be installed on a dispenser unit or storage bin 30" wide or wider. The following are recommended: Hoshizaki Dispenser, Model DB-200 or DM series; Hoshizaki Ice Storage Bin, Model B-500 series. For further options, contact your local Hoshizaki distributor. B. How to Remove Panels See Fig.

  • Page 10: Location

    C. Location CAUTION 1. This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within 45°F to 100°F (7°C to 38°C); Normal operating water temperature should be within 45°F to 90°F (7°C to 32°C). Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect icemaker performance.

  • Page 11: Electrical Connection

    E. Electrical Connection WARNING 1. Electrical connection must be hard-wired and must meet national, state, and local electrical code requirements. Failure to meet these code requirements could result in death, electric shock, serious injury, fire, or severe damage to equipment. 2.

  • Page 12: Water Supply And Drain Connections

    10 PSIG. Do not run the icemaker until the proper water pressure is reached. • A plumbing permit and services of a licensed plumber may be required in some areas. • External filters, strainers, or softeners may be required depending on water quality. Contact your local Hoshizaki distributor for recommendations. • Water supply pressure should be a minimum of 10 PSIG and a maximum of 113 PSIG. If the pressure exceeds 113 PSIG, the use of a pressure reducing valve is required. • The icemaker drain line, dispenser unit/storage bin drain line, and water-cooled condenser drain line (if applicable) must be run separately.

  • Page 13: Icemaker

    1. Icemaker • Icemaker water supply inlet is 1/2" female pipe thread (FPT). A minimum of 1/4" nominal ID copper water tubing or equivalent is required for the icemaker water supply line. • An icemaker water supply line shut-off valve and drain valve should be installed. • Icemaker drain outlet is 3/4" FPT. A minimum of 3/4" nominal ID hard pipe or equivalent is required for the icemaker drain line. Icemaker Water Supply Line Icemaker Shut-Off Valve Water Supply Icemaker Inlet 1/2" FPT Icemaker Water Supply Line Drain Valve Bin Drain Outlet 3/4" FPT...

  • Page 14: Water-Cooled Condenser

    Separate piping to approved drain. Leave a 2-inch (5-cm) vertical air gap Icemaker between the end of each pipe and Drain Outlet the drain. 3/4" FPT 2-inch (5-cm) air gap Floor Drain KML-250MWH Fig. 5 Connection to an Open Drain System...

  • Page 15: B) Connection To A Closed Loop System

    Icemaker Bin Drain Outlet Drain Outlet 3/4" FPT 3/4" FPT 2-inch (5-cm) air gap Condenser Water Supply Line Drain Valve Condenser Return Line Drain Valve Floor Drain KML-250MWH Fig. 6 Connection to a Closed Loop System...

  • Page 16: Final Checklist

    G. Final Checklist WARNING CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the dispenser unit/storage bin. 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 90°F (7°C to 32°C) all year around? 3) Is there at least 6" (15 cm) clearance at sides, rear, and top of the icemaker for proper air circulation and ease of maintenance and service?

  • Page 17: Startup

    H. Startup WARNING 1. All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. 2. If the icemaker is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the compressor. 3.

  • Page 18: Cleaning And Maintenance

    A. Cleaning and Sanitizing Instructions Hoshizaki recommends cleaning and sanitizing this unit at least once a year. More frequent cleaning and sanitizing, however, may be required in some existing water conditions.
  • Page 19 8) In bad or severe water conditions, clean the float switch assembly as described below. Otherwise, continue to step 9. a. Remove the 3 screws securing the float switch assembly, then remove the assembly. b. Remove the retainer rod from the bottom of the float switch housing, then remove the float.

  • Page 20: Sanitizing Procedure - Following Cleaning Procedure

    2. Sanitizing Procedure - Following Cleaning Procedure 1) Dilute 1.0 fl. oz. (30 ml or 2.0 tbs) of a 5.25% sodium hypochlorite solution (chlorine bleach) with 2.0 gal. (7.6 l) of warm water. 2) Remove the front insulation panel. 3) Pour the sanitizing solution into the water tank. 4) Move the service switch to the "WASH" position. 5) Replace the front insulation panel and the front panel in their correct positions. 6) Turn on the power supply to start the sanitizing process.

  • Page 21: Maintenance

    B. Maintenance This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. WARNING 1. Only qualified service technicians should attempt to service or maintain this icemaker. 2. Disconnect power before performing service or maintenance. 1.

  • Page 22: Preparing The Icemaker For Long Storage

    C. Preparing the Icemaker for Long Storage CAUTION 1. When storing the icemaker for an extended time or in sub-freezing temperatures, follow the instructions below to prevent damage. 2. To prevent damage to the water pump, do not leave the control switch in the "SERVICE" position for extended periods of time when the water tank is empty.
  • Page 23 3) Open the condenser water supply line drain valve. If connected to a closed loop system, also open the condenser return line drain valve. 4) Attach a compressed air or carbon dioxide supply to the condenser water supply line drain valve. 5) Open the water regulating valve by using a screwdriver to pry up on the spring retainer underneath the spring.
  • Page 24 HOSHIZAKI AMERICA, INC. 618 Hwy. 74 S., Peachtree City, GA 30269 USA TEL (770) 487-2331 FAX (770) 487-3360 www.hoshizaki.com 91A1CE10D...
