OPERATION, MAINTENANCE, and INSTALLATION INSTRUCTIONS
THE FOLLOWING ARE CAUTIONARY STATEMENTS THAT MUST BE READ AND
FOLLOWED DURING BOTH INSTALLATION AND OPERATION.
WARNING: Raritan Engineering Company, Inc. recommends that a qualified person or electrician install this
product. Equipment damage, injury to personnel or death could result from improper installa-
tion. Raritan Engineering Company, Inc. accepts no responsibility or liability for damage to
equipment, or injury or death to personnel that may result from improper installation or
operation of this product.
WARNING: RISK OF SHOCK OR FIRE - Always use recommended fuse/circuit breaker and wire size.
Motors in this product are "Ignition Protected". They are not however, explosion-proof as
defined in 46CFR 110.15-65(e), Subchapter J-Electrical Engineering.
WARNING: RISK OF FLOODING-Always shut off seacock(s) before leaving the boat unattended.
Whenever possible hose connections should be secured using two stainless steel hose clamps.
Integrity of clamps, hoses and fittings should be checked periodically.
Crown Head II Sea Water Model
The Crown Head II is an automatic electric
macerating toilet available in Freshwater or
Sea Water flushing.
www.raritaneng. com
crown head II
ELECTRIC MARINE TOILET
Manufactured after June 2002
1-800-352-5630
™
Crown Head II Pressurized Freshwater Model
Four different Flush Control options are
available:
1. Push Button activation - Standard
2. Timed Flush with Push Button - RTC
3. Timed Flush with wall mounted touch
pad - TC*+,*specify voltage and +color
4. Momentary Flush with ability to con-
trol intake and discharge seperately -
SWF100
Advertisement
Table of Contents
Related Manuals for Raritan Crown Head II
Summary of Contents for Raritan Crown Head II
- Page 1 THE FOLLOWING ARE CAUTIONARY STATEMENTS THAT MUST BE READ AND FOLLOWED DURING BOTH INSTALLATION AND OPERATION. WARNING: Raritan Engineering Company, Inc. recommends that a qualified person or electrician install this product. Equipment damage, injury to personnel or death could result from improper installa- tion.
- Page 2 • Push Button Switch (#164000) Press and hold switch until all waste is cleared from bowl. NOTE: Push Button Switch flushing is shown. Refer to manuals included with Toilet Control (TC12W), Raritime Solid State Timer with Solenoid (#RTC), or Flush Control (#SWF100) for operation Instructions.
-
Page 3: Maintenance
These will cause damage to the toilet. Using C.P. (#1PCP22), a bio-enzymatic toilet bowl cleaner (available from Raritan Engineering), will keep the bowl clean and fresh smelling. Recommend Visual Inspection ✔ For leaks at toilet and hose connections ✔... - Page 4 WINTERIZING IMPORTANT • Improper winter lay up is a major cause of marine toilet failure. • Use only nontoxic antifreeze. • Flush toilet several times to clear waste from system. • Dispose of all antifreeze in accordance with local and federal regulations. •...
-
Page 5: System Start-Up
Pressurized Fresh Water Model Parts Required • 1 1/2" (38mm) I.D. hose, approximately 3 feet (1m) long • Two buckets • Nontoxic antifreeze approximately 1 quart (1 liter) Steps 1. Close discharge seacock Nontoxic antifreeze 2. Shut off intake water at source. 3. -
Page 6: Installation
INSTALLATION • Fuse/circuit breaker Parts Included Tools Required All Toilets • 5/16" nut driver Toilet Bowl (Household or Marine) • Wrench or screw driver (depending on mounting Seat and Cover fastener) Discharge pump assembly • Bit for drilling mounting surface (depending on Heavy Duty Push Button Switch (#164000) fastener used) Mounting pads... -
Page 7: Specifications
) for 3% voltage drop. 3. Recommended conductor sizes are based on 105°C rated insulation. Refer to ABYC Standards for other insulation ratings. Recommended Wire and Breaker Sizes for Crown Head II with Diaphragm Intake Pump Distance (feet) and Wire (AWG) Main Circuit... - Page 8 3. Mount bracket. From 4. Install fittings provided (PLA14) on valve’s inlet Pressurized and outlet ports. Freshwater Source 5. Attach valve to bracket. Valve must be mounted according to flow markings on valve body. PLA14 To Crown Head II...
- Page 9 Mounting Atmospheric Vacuum Breaker 6" (Pressurized Freshwater Model only) (15.3cm) 1. Install fittings as shown. 2. Locate mounting area that is a minimum of 6" (15.3cm) above toilet. 3. Secure where top is in horizontal position. Mounting In-Line Strainer (Seawater Models Only) Make sure strainer bowl is tight.
-
Page 10: Discharge Lines
Remote Intake Pump Model PLUMBING Mounted Above Waterline WARNING: Hazard of Flooding Remote Crown head II Discharge Intake Vented Toilets mounted at or below the waterline must Pump Loop have a vented loop installed in the discharge Holding Tank line. The top of the vented loop must be a minimum of 4"... - Page 11 Intake Lines From Pressurized Pressurized Freshwater Models Freshwater Source (Shut Off Valve) Install a shut off valve in intake line before water solenoid valve. 1. Connect hose from pressurized freshwater source to a shut off valve. 2. Connect hose from shut off valve to inlet port of water solenoid valve.
- Page 12 WIRING WARNING: Hazard of Shock and Fire • Always use proper wire, wire connectors and fuse/circuit breaker. See Specification Chart on page 7. • Secure wire properly. • Do not connect other appliances to toilet circuit. Remote Intake Pump Wiring •...
-
Page 13: Troubleshooting
D. Close seacocks one at a time to determine which one is causing Boat is Underway: problem. If intake, install vented loop between pressure side of pump and bowl. If discharge, install vented loop in discharge line. If problem continues, contact Raritan Technical Support. Bowl Fills E1. Freshwater models: Water solenoid valve E1. - Page 14 Toilet Water Kit (Not shown) 31-102 Motor Shaft Seal w/316 Spring (Not shown) VL1½W Vented Loop 1½" (Not shown) C2M* Crown Head II Motor, 12, 24, 32 VDC C246 Lower Cover, Bone, Household-style C247 Lower Cover, White, Household-style * Specify Voltage...
-
Page 15: Exploded Parts View
CROWN HEAD II - EXPLODED PARTS VIEW 1237W, 1244AW, 1244W C250 1236AW 1226B 1236E CH26 CH18W 161107 CH120 CH38 Water Solenoid Valve F149VT CH121 CH119MW 1234 PLA14 CH15DD CWPS*A CH59 C246, 247 CH57 CH34 F149VT CH58 CH92 PLA14 CH27 C290... -
Page 16: Limited Warranty
1. TO OBTAIN WARRANTY SERVICE, Consumer must deliver the product prepaid, together with a detailed description of the problem, to Raritan at 530 Orange St., Millville, N.J. 08332, or 3101 SW 2nd Ave. Ft. Lauderdale, FL 33315. When requesting warranty service, purchaser must present a sales slip or other document which establishes proof of purchase.
Need help?
Do you have a question about the Crown Head II and is the answer not in the manual?
Questions and answers
my Crown head 2 has seized up, only clicking solenoid can be heard from the macerator pump. can I repair this? I'm in the Bahamas.
Yes, the Raritan Crown Head II can potentially be repaired if it has seized up and only the solenoid is clicking. This may indicate an object jammed in the macerator or damage to motor bearings. To repair:
1. Remove the front cover and check for a jammed object in the macerator.
2. If the motor bearings are damaged due to a macerator seal leak, return the motor to the factory for servicing or replacement.
This answer is automatically generated
@BRUCE R MAURA
where can I order these parts from?
Hi Mr. Anderson I have taken my '95 Raritan Crown Head 2 to pieces and the motor has seized and the inside of the macerator pump is full of thick corrosion. Is it possible to buy the same motor and macerator only? The motor serial #is 9501
