Poulan Pro PRO PB20H42YT Repair Parts Manual
Lawn tractor
Hide thumbs
Also See for PRO PB20H42YT:
- Operator's manual (56 pages) ,
- Operator's manual (30 pages) ,
- Operator's manual (30 pages)
Table of Contents
Advertisement
Quick Links
IMPORTANT MANUAL
REPAIR PARTS MANUAL
MODEL:
PB20H42YT
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulan-pro.com
532 43 88-79
DO NOT THROW AWAY
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PRO PB20H42YT
Summary of Contents for Poulan Pro PRO PB20H42YT
- Page 1 Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so PB20H42YT can re sult in serious in ju ry. LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 532 43 88-79...
-
Page 2: Table Of Contents
HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them. -
Page 3: Schematic
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK BLACK SEAT SWITCH (NOT OCCUPIED) -
Page 4: Electrical
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 ELECTRICAL T02S With 12V Outlet Option With Service Minder Option... -
Page 5: Tractor - Model No. Pb20H42Yt (96048000500), Product No. 960 48
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 ELECTRICAL KEY PART NO. NO. DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Head 1/4-20 x 3/4 532 19 32-28 Box Battery 532 17 61-38 Switch Interlock Push-In 532 18 37-59 Harness Socket Light w/4152J 532 00 41-52... -
Page 6: Chassis
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 CHASSIS chassis-tex_elite-husq_11... - Page 7 TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 CHASSIS KEY PART NO. NO. DESCRIPTION 532 43 27-79 Dash Upper Tex Elite EL CK 428 532 43 91-57 Hood Pnt Elite Spl-Tp W-Skirts 532 18 99-82 Lens Elite-Husq Clear LH 532 43 27-78 Grille 532 18 99-81...
-
Page 8: Drive
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 DRIVE 80 125 drive-tex_K46_fender_18_r1... - Page 9 TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 DRIVE KEY PART NO. NO. DESCRIPTION - - - - - - - - - Transaxle, Tufftorq K46BA 532 12 35-83 Key Square 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga. 532 41 36-78 Spring, Brake 532 19 76-60...
-
Page 10: Engine
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 ENGINE SPARK ARRESTER KIT... -
Page 11: Engine
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 ENGINE KEY PART NO. NO. DESCRIPTION - - - - - - Engine B8S Model No. 406777-1518-B1 532 14 97-23 Muffler 532 19 43-20 Keeper Belt Engine 532 40 54-71 Pulley Engine 532 40 74-89 Tank Fuel... - Page 12 TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 STEERING ASSEMBLY 53 8 steering-tex_STDSRR_1_r2...
-
Page 13: Steering
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 STEERING ASSEMBLY KEY PART NO. NO. DESCRIPTION 532 42 45-51 Wheel, Steering 532 19 59-68 Axle Asm., Front 532 40 30-87 Spindle Asm., LH 532 40 30-88 Spindle Asm., RH 532 12 49-31 Bearing, Race Thrust Harden 532 12 17-48... -
Page 14: Mower Deck
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 MOWER DECK 42_D_man-tex_LT_33_r5... - Page 15 TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 MOWER DECK KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 19 64-95 Mower Housing 817 00 06-16 Screw Hexwsh Thd 3/8-16 x 1 872 14 05-06 Bolt Rdhd 5/16-18 x 3/4 532 14 10-43 Guard, Tuv Idler (94)
-
Page 16: Mower Lift
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 MOWER LIFT 101* lift-tex_17_r3 *Key 91 may be substituted for Key 101 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 42 20-27 Shaft Asm., Lift 817 00 06-12 Screw 3/8-16 x .75 Smgml Tap/R.Z 532 19 52-31 Lever Asm., Lift RH... -
Page 17: Seat
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 SEAT ASSEMBLY seat-tex_6.5SL_1_r1 KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 40 66-23 Seat 873 80 05-00 Nut, Lock 5/16-18 unc 532 19 76-61 Handle Slide Seat 532 18 01-66 Bracket Pivot Fender 532 19 82-00... -
Page 18: Decals
TRACTOR - MODEL NO. PB20H42YT (96048000500), PRODUCT NO. 960 48 00-05 DECALS KEY PART KEY PART NO. NO. DESCRIPTION NO. NO. DESCRIPTION 532 43 02-55 Decal, Fender SD RH/LH 532 43 01-13 Decal, Hood RH/LH 532 43 88-06 Decal, Replacement 532 43 52-86 Decal, Warn. - Page 19 SERVICE NOTES...
-
Page 20: Warranty
LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in mate- rials and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we find to be defective due to materials or workmanship.
