Parts Manual
461ZX / 966681801
541ZX / 966681901
Please read the operator's manual carefully and make sure you
understand the instructions before using the machine.
Gasoline containing up to 10% ethanol (E10) is acceptable for
use in this machine. The use of any gasoline exceeding 10%
ethanol (E10) will void the product warranty.
Form Number 115 394427 Rev C
2011-09-15
Advertisement
Table of Contents
Related Manuals for Poulan Pro Pro 461ZX / 966681801
Summary of Contents for Poulan Pro Pro 461ZX / 966681801
-
Page 1: Parts Manual
Parts Manual 461ZX / 966681801 541ZX / 966681901 Please read the operator’s manual carefully and make sure you understand the instructions before using the machine. Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine. The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty. -
Page 2: Manufacturing Number
When you need spare parts or support in service questions, warranty issues, etc., please consult the following professional: This manual belongs to the machine with the Engine Transmission manufacturing number: Manufacturing Number The machine’s manufacturing number can be found on the printed plate affixed to the engine compartment. -
Page 3: Table Of Contents
CONTENTS FRAME ................ 4 HYDRAULIC PUMP- MOTOR ........16 ENGINE PLATE WHEELS AND TIRES ..........18 MODEL 966681901 ..........6 46" DECK ..............20 MODEL 966681801 ..........8 54" DECK ..............22 STEERING ..............10 SEAT ................. 24 IGNITION ..............12 DECALS .............. -
Page 4: Frame
FRAME... - Page 5 FRAME ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 510 261802 ..1 ..PLATE, OUTER BRAKE BLK 18.. 539 101341 ..8 ..HCS -16 x 3 2.. 510 206703 ..1 ..PLATE, BRAKE LATCH BLK 19.. 539 976938 ..6 ..HCS -18 x 2¼...
-
Page 6: Engine Plate
ENGINE PLATE MODEL 966681801... - Page 7 ENGINE PLATE ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 575 327002 ..1 ..PLATE, ENGINE 15.. 539 976935 ..3 ..HCS -18 x 1½ 2.. 539 112092 ..1 ..ARM, IDLER 16.. 539 976944 ..1 ..HCS -20 x 3½...
-
Page 8: Model 966681901
ENGINE PLATE MODEL 966681901... - Page 9 ENGINE PLATE ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 575 327002 ..1 ..PLATE, ENGINE BLK 16.. 539 103433 ..1 ..HCS ½-13 x 3¼ 2.. 532 400008 ..1 ..CLUTCH 17.. 539 109389 ..1 ..HCS -16 x 3½...
- Page 10 STEERING...
- Page 11 STEERING ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 579 036901 ..2 ..LEVER w/ GRIP 12.. 539 990209 ..2 ..HCS -18 x 1 2.. 525 392901 ..2 ..GRIP, FOAM 13.. 539 976935 ..2 ..HCS -18 x 1½...
-
Page 12: Model 966681801
IGNITION MODEL 966681801... -
Page 13: Ignition
IGNITION ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 578 179001 ..1 ..FENDER, RT BLK 27.. 576 371201 ..1 ..PANEL, RT 2.. 576 370501 ..1 ..FENDER, LT 28.. 576 371001 ..1 ..RING, RT BLK 3.. - Page 14 IGNITION MODEL 966681901...
- Page 15 IGNITION ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 578 179001 ..1 ..FENDER, RT BLK 28.. 576 371001 ..1 ..RING, RT BLK 2.. 576 370501 ..1 ..FENDER, LT 29.. 576 179401 ..1 ..HOUR METER 3..
-
Page 16: Brake / Lift
BRAKE / LIFT... - Page 17 BRAKE / LIFT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 574 216604 ..2 ..SHAFT LIFTING 12.. 532 195161 ..2 ..STUD w/ANTI- ROTATE 2.. 522 710804 ..1 ..SHAFT, BRAKE BLK 13.. 539 105069 ..3 ..E-RING 3..
-
Page 18: Hydraulic Pump- Motor
HYDRAULIC PUMP- MOTOR... - Page 19 HYDRAULIC PUMP- MOTOR ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 510 375601 ..1 ..EZT, LT 19.. 510 185102 ..2 ..MOUNT, EZT RR BLK 2.. 510 375602 ..1 ..EZT, RT 20.. 539 990637 ..4 ..HCS -16 x 2½...
-
Page 20: Wheels And Tires
WHEELS AND TIRES... - Page 21 WHEELS AND TIRES ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 11.. 539 102535 ..2 ..GREASE CAP 1.. 575 812201 ..2 ..CASTER TIRE ASSY 12.. 539 115749 ..2 ..PLUG, CASTER 2.. 575 812601 ..2 ..TIRE ASSY, REAR, 18 x 8.5-8 MODEL 966681801 13..
-
Page 22: 46" Deck
MOWER DECK / CUTTING DECK 46" DECK Torque to 55-70 ft/lbs... - Page 23 MOWER DECK / CUTTING DECK ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 522 745402 ..1 ..DECK w/ SAFETY DECALS 25.. 539 110462 ..1 ..ROD, HINGE 2.. 539 117245 ..1 ..BELT, DECK 26.. 539 991034 ..1 ..SCREW 10-24 x WSHR HD 3..
-
Page 24: Deck
MOWER DECK / CUTTING DECK... - Page 25 MOWER DECK / CUTTING DECK ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 522 745602 ..1 ..DECK w/ SAFETY DECALS 25.. 539 112062 ..1 ..BAFFLE, CNTR 2.. 539 114557 ..1 ..V-BELT 26.. 539 104870 ..1 ..HCS -14 x 2½...
-
Page 26: Seat
SEAT... - Page 27 SEAT ITEM PART NO. QTY. DESCRIPTION ITEM PART NO. QTY. DESCRIPTION 1.. 532 406625 ..1 ..SEAT 12.. 539 990316 ..4 ..RHSNB -18 x ¾ 2.. 532 196977 ..1 ..SEAT PAN 13.. 539 108503 ..1 ..HCS -16 x 3..
-
Page 28: Decals
DECALS... - Page 29 QTY. DESCRIPTION 1.. 539 105745 ..1 ..DECAL, BATTERY WARNING 13.. 575 934701 ..1 ..DECAL, POULAN, FRT 2.. 539 108385 ..1 ..DECAL, DO NOT TOW 14.. 575 934801 ..1 ..DECAL, POULAN, RT 3.. 539 109897 ..1 ..DECAL, SERVICE 15..
