IMPORTANT MANUAL REPAIR PARTS MANUAL MODEL: PBGT26H54X GARDEN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulan-pro.com 418794 12.07.07 SBW Do Not Throw Away 03090 WARNING: Read this Man u al and follow all Warnings and Safety Instructions. Fail ure to do so can re sult in serious in ju ry.
Page 3
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 SCHEMATIC SCH12 PTO SWITCH (MATING SIDE) IGNITION SWITCH POSITION CIRCUIT “MAKE” M+G+A1 B+A1 RUN/OVERRIDE B+A1 L+A2 START B + S + A1 BATTERY FUSE AMMETER (OPTIONAL) WHITE PTO SWITCH (DISENGAGED) WHITE BLACK...
Page 4
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 ELECTRICAL T11S With 12V Outlet Option With Service Minder Option...
Page 5
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 ELECTRICAL PART DESCRIPTION 144927 Battery 74760412 Bolt Hex Head 1/4-20 x 3/4 186491 Box Battery 176138 Switch Interlock Push-In 175688 Harness Socket Light w/4152J 4152J Bulb Light 400253 Cable Battery 198893 Cable Start Red 17.5"...
Page 6
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 CHASSIS chassis-tex_Stealth II PL_1_r1...
Page 7
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 CHASSIS PART DESCRIPTION 195102X428 Dash 175260X428 Hood 175289X428 Grille 196125 Plate Engine 17060512 Screw 5/16-18 x 3/4 400009X428 Fender 194314 Bracket Fender 17490508 Screw Thdrol 5/16-18 x 1/2 192512 Screw WSHD Hex 10-32 x 5/8 416358...
Page 8
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 DRIVE Drive-tex_K66_pedal_2...
Page 9
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 DRIVE PART DESCRIPTION 199973 Transaxle, TuffTorq K66Y 7070E 7563R Hardened Washer 199837 Hub Asm. Wheel 140080 Bolt Hub Wheel 19131316 Washer 13/32 x 13/16 x 16 Ga. 401072 Spring, Brake 199679 Spring Return Cruise...
Page 10
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 ENGINE SPARK ARRESTER KIT engine-tex_bs-2cyl_2_r1...
Page 11
TRACTOR - - MODEL NUMBER PBGT26H54X (96042007100), PRODUCT NO. 960 42 00-71 ENGINE Engine Power Rating Information The gross power rating for individual gas engine models is labeled in accordance with SAE (Society of Automotive Engi- neers) code J11940 (Small Engine Power & Torque Rating Procedure), and rating performance has been obtained and corrected in accordance with SAE J1995 (Revision 2002-5).
Page 26
don- sont direction direction 00-71 PRODUIT 25,4 pouce É.-U. composant dimensions Toutes Support .118 .505 Rondelle Cat. 7/16-14 collet à frein Écrou Douille 7/16-14 Boulon retenue Collier 5/16-18 C.D. direction Barre C.G. direction Barre 5/8-11 collet à frein Écrou Rondelle épualement à...
Page 27
00-71 PRODUIT (96042007100), PBGT26H54X DIRECTION MODÈLE steering-tex_Prem2_4 ENSEMBLE TRACTEUR...
Page 28
25,4 pouce sont composant dimensions Parenthèse Bâti Couple Transmission Garde Ceinture outils à boîte Console 1-1/4 21/32 Rondell retenue Collier poulie pour Support contraire Pédale avant Pédale Boulon nylon Palier Culbuteur Tige denté Secteur Loquet Support Support 3/8-16 Guide coudé Levier d’embrayage Raccord...
Page 29
00-71 PRODUIT (96042007100), PBGT26H54X Drive-tex_K66_pedal_2 ENTRAÎNMENT MODÈLE TRACTEUR...
Page 36
AVERTISSEMENT: JETEZ www.poulan-pro.com l’utilisation. lors PBGT26H54X struc vous sures struc tous suivez Lisez RÉPARATION 03090 12.07.07 web: site notre sécurité lunettes toujours JARDIN TRACTEUR MODÈLE: PARTIES MANUEL IMPORTANT MANUEL 418794 Visitez Portez...
