- Page 1 INSTRUCTION MANUAL Automatic Digital Blood Pressure Monitor Model 7622 Sunbeam-Dster Household Products Before operating this unit please read these instructions completely. P.N.99943...
- Page 2 DO Read instructions carefully before using Monitor. DO Rest arm on a flat surface so that upper arm is at heart level when taking measurements. DO Remain calm, quiet and still when measurements are being taken, DO make sure that the cuff is in the proper position according to your instruction manual.
- Page 3 1. DO NOT move arms or hands when measurement is being taken. 2. DO NOT talk or chew when measurement is being taken. 3. DO NOT take a series of measurements without waiting at least 10 minutes between measurements. 4. DO NOT adjust medication based on readings from this Monitor, 5.
- Page 4 What is Blood Pressure? Blood pressure is a measurement of the force of blood flowing against the walls of the arteries. Arterial blood pressure is constantly changing during the course of the cardiac cycle The highest pressure in the cycle is called the SYSTOLIC BLOOD PRESSURE; the lowest is the DIASTOLIC BLOOD PRESSURE.
- Page 5 Systolic: The highest point of blood pressure; level of blood pressure produced as your heart beats. Diastolic: The lowest point of blood pressure; level of blood pressure produced as your heart rests between beats Millimeters of Mercury (mmHg): Blood pressure is measured in terms of the height of mercury in a column.
- Page 6 Standards for assessment of high or low blood pressure, without regard to age, have been established by the World Health Organization (WHO), as shown in this chart. (Fig. mmHg 1 6 0 1 4 0 Diseases Report the Ministry of Health Reference Material: Investigation into Adult and Social Security, 1971.
- Page 7 Individual blood pressures vary greatly both on a daily and a seasonal basis, These variations are even more pronounced in hypertense patients. Normally the blood pressure rises while at work and is at its lowest during the sleeping period. The graph below illustrates the variations in blood pressure over a whole day with measurement taken every five minutes.
- Page 8 DIAGRAM A Systolic blood pressure Diastolic blood pressure, display section pulse display section Memory switch Power switch Hose Main frame connector...
- Page 9 ir Release Valve...
- Page 10 Mark appears in the mea- Measurement in progress - surement condition and remain quiet. I--- Measurement in flashes when pulse is progress detected. Mark flashes when power is Automatic exhaust is per- applied and there is air formed. remaining in the cuff. Exhaust...
- Page 11 Measurement has begun Raise the cuff but the pressure was pressure 30-40 mmHg Insufficient insufficient, more and measure once pressure again. Appears when the battery Replace all four batteries Replace voltage is excessively low. with new ones. batteries Appears when the blood pressure could not be Measurement error obtained accurately.
-
Page 12: Battery Installation
1. Battery Installation Remove the batterv cover and insert batteries into the battery compartment as shown, taking extreme care that the polarities + and - are observed. (Fig. 3) (Fig. 3) 2. Inserting Hoses Insert the cuff hose and inflation bulb hose into the host jacket. (See Diagram A) -
Page 13: Measuring Posture
3. Attaching the Arm Cuff Wind the arm cuff around the left upper arm’tightly (for best results) so that the bottom edge of the cuff is positioned one inch above the elbow joint. (Fig. 4) Do not roll up a shirt or jacket. It may cause constriction of the upper arm and proper measurement results will not be obtained. - Page 14 When power is turned ON, all display marks appear for approximately 1 second. When the “0” is displayed the unit ready for measurement. It the ‘7” mark appears, release air in the arm cuff bv squeezing it or removtna the hose plug Approx.
- Page 15 *Remain still during measurement. 2) When a pulse is detected, the pressure value moves to the right side of the display. At this time the ” v” mark flashes at the same rate as pulse rate, and the buzzer sounds when the oulsation is sufficient. urrent Pressure Flashing alue...
- Page 16 Name and model number Digital Blood Pressure Meter 7622 Display system Digital display system/LCD 6 digits Measuring method Oscillometric method Power source Type AA batteries X 4 Measuring range 20-280 mmHg (Pressure) 40-200 Pulses/minute (Pulse) Accuracy - 3 m or 2% whichever greater (Pressure) - 5 % (P&e)
- Page 17 REPLACEMENT PARTS AND ACCESSORIES --‘---r------------------------------------------------ Please print your name and address below. Street Address City State Include check or money order made payable to Sunbeam-Oster Household Products and mail to: Sunbeam Service Department 117 Central Industrial Row Purvis, Mississippi 39475...
- Page 18 Above prices include shipping and handtmg. Please print your name and address below. N a m e Street Address State City Send to Sunbeam Service Department 117 Central Industrial Row Purvisl, Mississippi 39475 or call 1-800-394-2326 VISA Mastercard For Mastercard or VISA: Circle one Exp.
