Hayter Powertrim 407F Owner's Handbook Manual

Hayter Powertrim 407F Owner's Handbook Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

C
O
D
E
S
E
R
A I
L
N
407F
310000001
Issue 10/2009
POWERTRIM
OWNER'S HANDBOOK
O
.
Code 407F
P
ART NO: 111-3445 (Rev. A)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Powertrim 407F and is the answer not in the manual?

Questions and answers

Related Manuals for Hayter Powertrim 407F

Summary of Contents for Hayter Powertrim 407F

  • Page 1 POWERTRIM Code 407F OWNER’S HANDBOOK ART NO: 111-3445 (Rev. A) 407F 310000001 Issue 10/2009...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LIMITED WARRANTY OPERATOR SAFETY ASSEMBLY OPERATION MAINTENANCE TROUBLESHOOTING SPECIFICATIONS REPAIR PARTS 1739579...

  • Page 3: Limited Warranty

    LIMITED WARRANTY Hayter Limited warrants to the original user / purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of three years from the date of purchase. The manufacturers of the engine and battery pack system (where applicable) furnish their own warranty and services are provided through their authorised network (Refer to “Engine/Battery Pack Warranty Statement”).

  • Page 4: Operator Safety

    OPERATOR SAFETY OWNER’S INFORMATION Wear appropriate clothing such as a long−sleeved shirt or jacket. Also wear Know your product: If you understand the long trousers. Do not wear shorts. unit and how the unit operates, you will get Do not wear loose clothing or jewelry. the best performance.
  • Page 5 OPERATOR SAFETY 21. Stop the engine whenever you leave the Do not trim on wet grass. Reduced footing equipment, before cleaning repairing or could cause slipping. inspecting the unit, be sure the trimmer head and all moving parts have stopped. Let the engine cool, disconnect the III.
  • Page 6 OPERATOR SAFETY Never run the engine indoors or inside a To reduce fire hazard, keep machine closed area. The exhaust fumes are free of grass, leaves, or other debris dangerous, containing CARBON MON- build−up. Clean up oil or fuel spillage. OXIDE, an ODORLESS and DEADLY Allow machine to cool before storing.

  • Page 7: International Pictorials

    OPERATOR SAFETY INTERNATIONAL PICTORIALS IMPORTANT: The following pictorials are located on your unit or on literature supplied with the product. Before you operate the unit, learn and understand the purpose for each pictorial. Safety Warning Pictorials WARNING WARNING: Rotating Parts. Stop Engine. Disconnect Spark Plug Wire Before IMPORTANT: Read Owner’s Manual Making Adjustments.

  • Page 8: Assembly

    ASSEMBLY CONTENTS OF LITERATURE PACK 1 - Operator’s Manual 1 - Engine Manual 1 - Document of Conformity 1 - Warranty Card 1 - Safety Glasses 1 - Trimmer Line (2 Sets) 1 - Bag (4 Screws) REMOVE THE TRIMMER WARNING: Always wear safety glasses or eye shields while as- FROM CARTON...
  • Page 9 ASSEMBLY RAISE THE HANDLE 1. Hold the handle with one hand and loosen both handle adjustment knobs until the ratchet teeth are disengaged. Do not remove the handle adjustment knobs. See Figure 2. 2. Raise the handle to the operating position. 3.

  • Page 10: Engine Preparation

    ASSEMBLY ENGINE PREPARATION Fill Crankcase With Oil 1. Remove the oil fill cap/dipstick shown in Note: Engine does not contain OIL or Figure 4. Fill the crankcase to the FULL PETROL. line on oil fill cap/dipstick. DO NOT OVER- FILL. WARNING: Follow the engine 2.

  • Page 11: Operation

    OPERATION KNOW YOUR POWERTRIM READ THE OWNER’S HANDBOOK AND ALL SAFETY RULES BEFORE YOU OPERATE the machine. To familiarise yourself with the location of the controls, compare the illustrations with your machine. Save this handbook for future reference. Control Bail Trimmer Head Drive Lever Upper Handle Throttle Control Lever...
  • Page 12 OPERATION USE THE TRIMMER HEAD DRIVE LEVER Control Bail 1. To engage the trimmer head, hold the con- Handlebar trol bail against the handle. Move the trimmer head drive lever forward to en- gage the trimmer head. See Figure 6. The faster the engine runs, the faster the trim- mer head will rotate.
  • Page 13 OPERATION START THE ENGINE NOTE: If engine fails to start after three pulls, push the primer button two times and NOTE: DO NOT BE ALARMED, your engine again pull the recoil starter handle. will smoke the first time it is started. It is WARNING: Never run the engine burning off the protective coating that is on indoors or in a poorly ventilated...

  • Page 14: Maintenance

    MAINTENANCE SERVICE RECORDS Before Every Every Every Fill in dates as you SERVICE Each complete regular service. DATES Noted Hours Hours Hours √ Check Engine Oil Level √ Check Trimmer Lines Check Trimmer Head √ Engagement √ Engine/Machine Cleaning √ Check Nuts and Bolts √...
  • Page 15 MAINTENANCE LUBRICATION Grease Fitting Lubricate the Jackshaft Assembly A grease fitting is provided to lubricate the jackshaft assembly. Use a grease gun with au- tomotive type grease to lubricate the jackshaft assembly as shown in Figure 10. Figure 10 Change Engine Oil Change the engine oil when the engine is 7.

  • Page 16: Spark Plug

    MAINTENANCE SPARK PLUG Check the spark plug every 25 hours. Re- Tighten the spark plug to a torque of 15 place the spark plug if the electrodes are foot−pounds. pitted or burned or if the porcelain is cracked. Make sure the spark plug is clean. Clean Feeler Gauge 0.030”...

  • Page 17: Service And Adjustment

    MAINTENANCE SERVICE AND ADJUSTMENT WARNING: Before you inspect, clean or service the machine, stop the engine. Make sure that all moving parts have stopped. Disconnect the wire from the spark plug. PROPER CARE OF TRIMMER LINE IMPORTANT: To extend the life of the trim- For the best performance, use a heavy gauge 3.9mm (0.155”...
  • Page 18 MAINTENANCE REPLACE THE DRIVE BELT To replace the drive belt, see an author- ized service center. STORAGE WARNING: Do not remove petrol Engine while inside a building, near a To prevent engine damage when the ma- fire, or while you smoke. Petrol chine is in storage for 30 days or more, fol- fumes can cause an explosion or low the steps below:...

  • Page 19: Troubleshooting

    TROUBLESHOOTING CHART TROUBLE CAUSE CORRECTION Engine does not start. Spark plug wire Connect spark plug wire. disconnected. Engine not primed. Prime engine. Defective or incorrectly Inspect or replace spark gapped spark plug. plug. Fuel tank empty. Add fuel. Dirty carburetor or fuel line. Clean carburetor or fuel line.
  • Page 20 TROUBLESHOOTING CHART Engine overheats. Engine cooling system See authorized dealer. clogged. Carburetor out of adjustment. See authorized dealer. Oil level is low. Add oil. Engine will not stop Defective throttle control See authorized dealer. running. lever or wire. Poor trimming Trimmer line length is too Correct line length is 52 cm performance.

  • Page 21: Specifications

    SPECIFICATIONS Trimmer Line Diameter 3,9 mm (0,155”) Trimmer Line Length 520 mm (21,5”) Height of Cut (Fixed) 76 mm (3”) Dimensions 1400 x 555 x 1000 Engine Briggs 122T02-0188-B1 2,56 Displacement 190 cc (11,57 cu in.) Petrol Capacity 0,95 L (1,0 quarts) Oil Capacity 0,54 - 0,59 L (18-20 oz) Spark Plug...
  • Page 22 Order Replacement Parts Replacement parts, except for the engine, transmission, transaxle or differential, are available from your local Hayter authorised dealer, the store where the mower was purchased or a service shop recommended by the store. If you are unable to obtain parts or service in the manner outlined above, then contact: HAYTER LIMITED, Service Department,...

  • Page 23: Repair Parts

    Repair Parts PTS - 1...
  • Page 24 Handle And Wheels POWERTRIM Code 407F NOTE: Unless noted otherwise, use the standard hardware torque specification chart. PTS - 2...
  • Page 25 Handle And Wheels POWERTRIM Code 407F REF NO PART NO. QTY. DESCRIPTION MU740198E701MA LEVER, Stop MU323035MA BOLT MU740193MA CABLE, Control Latching MU071372MA TIE, Cable MU740196E701MA HANDLEBAR MU15X116MA MU1601039MA CONTROL, Throttle MU672510MA GUIDE, Rope MU740202MA KNOB, Handlebar MU783000MA WASHER MU711936MA WASHER, Spring MU711937MA BOLT MU740158MA...
  • Page 26 Cutting Head And Shield POWERTRIM Code 407F NOTE: Unless noted otherwise, use the standard hardware torque specification chart. PTS - 4...
  • Page 27 Cutting Head And Shield POWERTRIM Code 407F REF NO PART NO. QTY. DESCRIPTION MU015X84MA MU025X11MA SCREW MU740150E701MA FRAME, Trimmer MU26X256MA SCREW MU740232MA BRACKET, Idler Assembly MU009X48MA BOLT MU712403MA SPRING MU740292MA SPACER MU15X119MA M710083MA WASHER MU740171MA PULLEY, Cutting Head MU740173MA SPACER MU711933MA BELT MU740244MA...
  • Page 28 Hardware Identification & Torque Specifications Common Hardware Types Torque Specification Chart Hex Head Capscrew FOR STANDARD MACHINE HARDWARE (Tolerance ± 20%) Washer Hardware Lockwasher Marks Grade Carriage Bolt SAE Grade 2 SAE Grade 5 SAE Grade 8 Hex Nut Size Of in/lbs in/lbs in/lbs...
