Sample configurations

506 Compact Disc Player
506
504 501
The 506 Compact Disc Player is an integrated CD transport and
converter, providing both digital and analogue outputs.
The 506 Compact Disc Player is ideally suited for use with the
Meridian 555 Stereo Power Amplifier and A2 Loudspeakers, with
control over the volume and source selection provided by the
501 Remote Control Preamplifier.
The 504 FM Tuner is an ideal addition to the system if radio
reception is required.
500 Compact Disc Transport
A2 A2
500
M60 555 M60
504
The 500 Compact Disc Transport provides a precision digital
output, and can drive DSP5000 Digital Loudspeakers directly.
A 562 Digital Controller can be added to cater for conventional
analogue sources, such as the 504 FM Tuner, and provide
source selection between up to 12 different analogue or digital
sources.
DSP5000
562
DSP5000
