Summary of Contents for Philips Azalis 288
-
Page 2: Alphanumeric Keypad
Philips tries to ensure that all information in this user manual is correct, but does not accept liability for any error, omission or discrepancy between this user manual and the product... -
Page 3: Quick Reference
Quick Reference Switch on/off: Long press r Enter PIN: 1. Enter PIN code on keypad 2. Press o to confirm Make a call: 1. Enter phone number on keypad 2. Press d to dial Answer a call: Press d End a call: Press r Use Names List: 1. - Page 4 4. Press < > to select a sub- menu 5. Press o to confirm Return to previous menu: Press C Return to idle screen: Press M Visit our site and register on line @ http://www.pcc.philips.com PHILIPS Favourites Service numbers Last page Launch...
-
Page 5: Table Of Contents
Table of contents Discover your Phone Messages Send SMS or Reply Introduction Read SMS Symbols used in this SMS Settings guide Signature Before your first call 3 Delivery report Auto save SMS The SIM card Broadcast SMS PIN and PUK codes Reception Insert the SIM card Topics... - Page 6 Register again Troubleshooting Preferred list Index Call settings Call forward Declaration of Any key answer conformity Call waiting Caller ID Philips Authentic Network Services Accessories Touchtones (DTMF) Make a second call Autoredial Answer a second call Conference call Operator services...
-
Page 7: Introduction
Introduction Thank you for purchasing your Philips Az@lis 288. This guide will help you to learn easily and quickly how to use your phone. Symbols used in this guide A function displayed on your phone screen. Ringer volume Represents a key on your phone keypad. -
Page 8: Insert The Sim Card
Insert the SIM card Remove the SIM card from your card. Remove the battery cover. Press on the battery cover latch at the back of the phone. Lift off the battery cover. Push the metal retaining clip to the left and lift the cardholder. Slide the SIM card into its slot until it stops. -
Page 9: The Battery
The battery Your phone is powered by a rechargeable battery. • To optimise the battery capacity, please allow the battery to fully discharge 3 times in a row. To then maintain optimal battery capacity, do not wait until the battery indicator reaches low. This level is reached when only one bar is displayed in the battery indicator, see page 7. -
Page 10: Remove The Battery
Remove the battery Press bottom of battery lightly against battery latch. Lift bottom of battery and slide it out of the phone. Unplug the connector from its slot. When disconnecting the battery, the settings for date and time will be lost. Charge the battery With the battery inside the phone: Plug the connector into the... -
Page 11: Screen
Screen The screen displays information regarding various functions of your phone. Network Name Network Name Network Name Network Name 12 jun 2000 12 jun 2000 12 jun 2000 12 jun 2000 Alarm clock Network Your alarm clock is activated. Network: your phone is Network Network Network... -
Page 12: Phone Functions
Phone Functions Switch on/off Long press r to switch on/off. Enter your PIN code if requested then press o to confirm. PIN CODE PIN CODE PIN CODE PIN CODE Idle Screen Network Name Network Name Network Name Network Name 12 jun 2000 12 jun 2000 12 jun 2000 12 jun 2000... -
Page 13: Make A Call
Make a call Enter the phone number using the keypad. Press d to dial. • Press to delete the previous digit. • Press to move through digits. < > • Long press to obtain "+" symbol on the screen for the International prefix. -
Page 14: End A Call
• by pressing : Find a phone number to access list, to select name and to confirm. < > Names Press to return to your call screen. End a call Press r to end a call. Emergency call Depending on the network operator, the emergency number can be dialled without the SIM card inserted. - Page 15 Characters space 1 @ _ # = < > ( ) & £ $ ¥ A B C 2 À Ä Å Æ Ç D E F 3 É E G H I 4 J K L 5 M N O 6 Ñ Ò Ö P Q R S 7 T U V 8 Ü...
- Page 16 Press * to enter T9™ mode unless T9™ symbol is already displayed. Press keys 2 to 9 (one press per letter indicated on the key) to spell the word you want to write. Press 0 to scroll the words T9™ proposes and select the one you want.
-
Page 17: The Carousel
Press M to return to the idle screen. Main Menus Press . Press to select a function from the carousel displayed on < > the screen then press to confirm. PHILIPS Favourites Service numbers Last page Launch Services Network Settings Help Oper. -
Page 18: Names
Settings Operator Names Messages Call list Organiser Extras services Names This is your directory of names and numbers you wish to store. They are stored in your SIM card. The capacity only depends on it. For further information, please contact your operator. Press M ->... -
Page 19: Send Sms
Settings Operator Names Messages Call list Organiser Extras services Send SMS Press < / > to select a name. Press o o. Press < / > to select Send SMS See "Send SMS or Reply" page 17. Voice Dial You can dial a number simply by long pressing and then pronouncing the voice tag you associated with that number. -
Page 20: Messages
(see page 27) or download from Internet (see page 28). The receiver must have a Philips mobile phone that supports this feature to see the icon and/or hear the melody sent. Otherwise, he will not... -
Page 21: Send Sms Or Reply
Settings Operator Names Messages Call list Organiser Extras Names services Send SMS or Reply Press M -> , -> Messages Send SMS Press < / > to select a name in the Names list, or select to enter a new number. Press o to enter a sub-menu : Standard . -
Page 22: Read Sms
Settings Operator Names Messages Call list Organiser Extras services Read SMS Consult the list of SMS you have saved and received. They have the following icons: Received unread Saved Received read Press M -> o -> Messages Read SMS Press < / > to select a message. Press o to read this message. -
Page 23: Reception Topics
Settings Operator Names Messages Call list Organiser Extras Names services Reception Press to activate/deactivate regular reception of the Broadcast < > SMS. Topics Go to to add a new topic you want to receive. Enter the name you <New> want to associate with the topic and the code provided by your network operator. -
Page 24: Call List
Settings Operator Names Messages Call list Organiser Extras services Call List This function provides a chronological list of all calls you have received, missed and dialled. Received call Dialled call Missed call Press < to see the list of your latest outgoing and incoming calls. -
Page 25: Organiser
Settings Operator Names Messages Call list Organiser Extras services Organiser You can manage up to 28 events. Press M -> o -> Select a function from the carousel Organiser displayed on the screen. Events Month view Day view Week view The events appear in the list in the chronological order, using start times and dates, with the most recent one on top. -
Page 26: Extras
Settings Operator Names Messages Call list Organiser Extras services Extras Your phone provides a number of practical extra functions for your convenience. Press M -> -> Select a function from the carousel displayed on Extras the screen. Call counters Voice memo ->... -
Page 27: Cost Limit
Settings Operator Names Messages Call list Organiser Extras services Cost limit* Enter the cost limit you don't want to exceed for your calls. Show balance* Check the remaining credit after entering the cost limit. Cancel cost limit* Cancel the cost limit you entered. Requires PIN or PIN2 code. Charge rate* Set and change the cost rate per unit of time. -
Page 28: Euro
Settings Operator Names Messages Call list Organiser Extras services <- Euro Convert an amount from Euro to your currency. Enter the amount, then press o. Long press to insert decimal point. NOTE: Only available in countries participating in the European Monetary Union. Brick game Break a complete set of bricks with a ball and racket. -
Page 29: Alarm Clock
Settings Operator Names Messages Call list Organiser Extras services Alarm Clock Set the alarm functions and activate/deactivate the alarm. The alarm rings even if the phone is switched off. Press < / > to set With alarm set the time using "00:00" format. Press o. -
Page 30: Settings
Settings Operator Names Messages Call list Organiser Extras services Settings You have various options to customise your phone. Press M -> -> Select a function from the carousel displayed on Settings the screen. Sounds Display Call settings Network Security Voice comm and Tim e and date Hotkeys Sounds... - Page 31 Settings Operator Names Messages Call list Organiser Extras services Ringer Select the ringer type among 22 melodies including your own composed melodies. Press < / > to select a melody. Press o to confirm your choice. Own Melody Compose your own ringer melody with up to 50 notes. Take a few notes from your favourite sheet music or compose your own.
-
Page 32: Ringer
Downloadable melody* You can personalise your phone by downloading new ringers of your choice on your Operator's web site (or connect to Philips web site : www.pcc.philips.com). From your personal computer, check on your Operator's Internet site the availability, terms and conditions of this service and follow its instructions to download your selected ringer tone via a SMS (see page 17). -
Page 33: Display
Settings Operator Names Messages Call list Organiser Extras services Display Set screen options for ease of reading. Zoom Activate the zoom function to enlarge the text size on your phone screen. Contrast You can choose between 5 levels of contrast. Security Keypad lock This menu allows you to activate/deactivate the keypad lock. -
Page 34: Time And Date
Settings Operator Names Messages Call list Organiser Extras services Change codes Change your PIN or PIN2 code to protect access to your phone. Press < / > to select Change PIN Change PIN2 Enter old PIN or PIN2, then press o. Enter new PIN or PIN2, then press o. -
Page 35: Hotkeys
Settings Operator Names Messages Call list Organiser Extras services Hotkeys* With a long press on certain keys you can instantly access their associated functions or dial a number (Flash Dial). There are eight keys, you can program for the functions or numbers you frequently use. Long press 1 or 0 to instantly access their respective functions: Voice Mailbox... - Page 36 Settings Operator Names Messages Call list Organiser Extras services Immediate access to the outdoors quick setting. The ringer Activ.Outdoors volume is high. Immediate access to the normal quick setting. Activ. Personal Immediate access to the autonomy quick setting. This extends Activ.
-
Page 37: Voice Command
Settings Operator Names Messages Call list Organiser Extras services Immediate access to the WAP Browser. Launch Forwards all calls to the voice mailbox. Call forward Direct access to Brick game Brick Game NOTE: *Depending on your subscription provider some Hotkeys, in addition to , can be predefined and locked, preventing reprogramming by the user. -
Page 38: Network
Settings Operator Names Messages Call list Organiser Extras services Network* When travelling abroad, your phone will register to one of the networks with the strongest reception. Register again If you want to select the network manually, select register again and your phone will present a list of available networks in your area. -
Page 39: Any Key Answer
Settings Operator Names Messages Call list Organiser Extras services Deactivate call forward options and receive calls on your phone as normal: Press M -> o -> o -> Settings Call settings o -> Call forward Unconditional Select , then press o. Cancel Status Select Status to verify the status of all call forwarding. -
Page 40: Network Services
Network Services Touchtones (DTMF) Your phone keys always transmit DTMF tones (Dual Tone Multiple Frequency) also known as "touchtones". These tones are used to operate services that you can reach with your phone, such as a pager or an answering machine. For example, to consult your home answering machine you may need to enter the following commands: Answering... -
Page 41: Autoredial
To end the call on hold: Select Switch calls Press r. Autoredial* When you dial a number and your correspondent is busy, your phone offers the function of automatically redialling. A beep will sound for each redial attempt and a special beep informs you when the connection has been made. - Page 42 To switch between calls: Press o. Select and select a call, then press o. Switch calls With two and up to 5 members on line: Press o. Press < / > to select , then press o. Conference End a conference call: Press r to end the conference call.
-
Page 43: Operator Services
Settings Operator Names Messages Call list Organiser Extras services Operator services Some services are specific to operator ; your phone readily supports them if they are included in your subscription. For further information on availability and rates, please contact your network operator. Depending on your subscription, your phone may allow you to access the following menus: Services... -
Page 44: Launch The Browser
Settings Operator Names Messages Call list Organiser Extras services Launch the Browser menu allows you to access the online services provided by your Launch operator. There are three ways to access these services: From the idle screen, press and hold key. - Page 45 Settings Operator Names Messages Call list Organiser Extras services The following commands enable you to navigate through the WAP pages: Press < or > to navigate the online pages. Press o to select a highlighted item. Press d or r to select the left or right option box displayed at the bottom of the screen.
-
Page 46: Favourites
Settings Operator Names Messages Call list Organiser Extras services Favourites* menu allows you to store direct links to your favourite WAP Favourites pages. • Select Favourites • Select <New> • Enter the name you want to associate to this page and confirm by pressing o. -
Page 47: Status Icons
Settings Operator Names Messages Call list Organiser Extras services Status icons allows you to activate or deactivate the header display and gain Status icons one extra line of text on your screen. Access settings* Depending on your subscription, you may configure the following connection parameters which should be provided by your network operator: Gateway* menu allows you to enter IP addresses for the gateways. -
Page 48: Phone Number
Settings Operator Names Messages Call list Organiser Extras services Phone Number* option allows you to enter the phone number for analogue or Phone num ber digital network depending on your operator. You need this number in order to establish a connection with your Internet Service Provider (ISP). Select Phone number Press <... -
Page 49: Glossary
Glossary GSM Network Global System for Mobile communications. The type of network used by your phone. DTMF Dual Tone Multi Frequency. Also known as "touchtone". The tones are transmitted by the phone to the network and are used to interrogate answering machines, transmit code... Home network The network to which you subscribe to. -
Page 50: Precautions
Precautions Your cellular mobile phone is under your responsibility. To avoid damage to yourself, to others or to the phone itself, read and follow all the safety instructions and make them known to anyone borrowing your phone. Furthermore to prevent unauthorised use of your phone: •... - Page 51 Always switch off your phone: Before boarding an aircraft and or when packing the phone in your luggage. In hospitals, clinics, other health care centres and anywhere else where you may be in the close vicinity of medical equipment. If you are a user of a pacemaker or hearing aid, or expect to use your cellular phone in the immediate vicinity of someone who does, then take the following precautionary steps:...
- Page 52 Check with the vehicle manufacturer that electronic equipment used in your vehicle will not be affected by radio energy. In order to improve the performance of your phone, reduce radio energy emission, reduce battery consumption and ensure safe operation adhere to the following guidelines: •...
- Page 53 • Avoid exposure to excessive heat (>60°C or 140°F), moisture or caustic environments. • You should only use Philips Authentic Accessories, as the use of any other accessories may damage your phone and make all guarantees for your Philips phone null and void.
-
Page 54: Environmental Care
Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate disposal of your eventual waste. -
Page 55: Troubleshooting
Troubleshooting PROBLEM SOLUTION The phone does not Check if the battery is correctly inserted and/or charge the phone until the battery icon has stopped flashing. switch on. The display shows Somebody tried to use your phone but didn’t know the PIN code nor the unblocking code (PUK). - Page 56 PROBLEM SOLUTION The display shows Check that the SIM card has been inserted in the right position (see page 4). Your SIM card may be damaged. SIM FAILURE Please contact your network operator. The display shows This problem is related to your subscription. Please contact your network operator.
-
Page 57: Index
Index deleting a message 18 deleting Names list entries 15 access settings 43 delivery report 18 accessories 58 display 29 alarm clock 7, 25 Downloadable melody 28 answering calls 1, 9, 37 DTMF 28, 45 antenna 1 any key answer 35 auto save option 18 earpiece volume 9 auto save SMS 18... - Page 58 organiser alerts 28 own number 14 language 31 launch 40 low battery alert 7, 51 pause characters 36 lower case 11 PIN code 3 PIN code modifying 29 PIN protection 30 mailboxes 19 preferred list 34 main menus 13 public names 29 making a call 9 PUK code 3 making a second call 36...
- Page 59 table of characters 11 text entry 10 time setting 30 troubleshooting 51 upper case 11 voice command 33 voice dialling 9 Voice memo 25 voice tag 33 volume control earpiece 1, 9 wap 39 zoom 29...
- Page 60 Declaration of conformity Philips Consumer Communications Route d’Angers of of of of 72081 Le Mans Cédex 9 FRANCE declare under our sole responsibility that the product TCD 288 Cellular Mobile Radio GSM 900/GSM 1800 TAC: 449686 to which this declaration relates, is in conformity with the following Standards: EN 60950 and ETS 300 / 342-1 CTR’s 19/20 and CTR’s 31/32...
- Page 61 Notes...
-
Page 62: Philips Authentic Accessories
Data cable and you can send faxes, SMS messages, access data communication facilities on mobile phone networks and connect to Internet. To maximise the performance of your phone and not void the warranty, always purchase Philips Authentic Accessories that are specially designed for use with your phone. Philips Consumer Communications cannot be held liable for any damage due to use with non authorised accessories.
