12.1" liquid crystal display television
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading

Related Manuals for HANNspree F651-12A1

Summary of Contents for HANNspree F651-12A1

  • Page 2: Table Of Contents

    Table of Contents 1. Warranty and Service ............ 3 2. Preface ................. 4 3. Description of Warning Symbols ........5 4. Safety Notices ............... 6 5. Regulatory Information ..........14 6. Introducing the TV ............16 Features ..............16 7. Checking Package Contents ........17 8.
  • Page 3 Table of Contents 11. Adjusting On-Screen Display (OSD) Settings ....31 Brightness ............... 32 Contrast ..............33 Video Setting ............34 Hue ..............35 Saturation ............36 Sharpness ............37 Color Temperature ..........38 Audio Setting ............39 Treble ..............40 Bass ..............

  • Page 4: Warranty And Service

    TV). With this product, you will be able to enjoy superior audio and video while enriching your lifestyle with advanced technology. The Hannspree TV is warranted for one year limited service from the date the product is received (as shown on the Warranty and Service Manual);...

  • Page 5: Preface

    No part of this documentation may be reproduced in any form by any means without prior written authorization of Hannspree, Inc., and its licensors, if any.

  • Page 6: Description Of Warning Symbols

    Description of Warning Symbols Warning Caution This symbol is used to remind This symbol is used to remind users to pay attention to users to pay attention to the important descriptions regard- danger of electric shocks due ing usage and maintenance to dangerous internal non- (repair) or additional impor- insulated components.

  • Page 7: Safety Notices

    Safety Notices Power Supply Safety Notes 1. To avoid electric shocks, do not use an extended power cord or an outlet that does not match this product's plug or leaves the plug exposed. 2. This product has a 3-pin grounded plug. The third pin connects to ground;...
  • Page 8 Before You Proceed 1. Read the Safety Notices and the User’s Manual carefully before turning the product on. 2. Keep your User’s Manual in a safe place for future reference. Keep the box and packaging in case the product needs to be shipped in the future.
  • Page 9 Optimal Viewing Distance...
  • Page 10 Important Safety Instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 11 10. Protect the power cord from being walked on or pinched particularly at the plug, conve- nience receptacles, and the point where they exit from the apparatus. 11. Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
  • Page 12 Personal Safety To avoid overloading the power supply, do not plug too many electrical devices into an outlet or extension cable. Dangerous high-voltage electric power compo- nents are located inside the TV. To avoid electric shock, do not disassemble the casing. Do not place or drop metals, small objects, or flammable materials in the vent to avoid an elec- tric shock or a fire.
  • Page 13 Installation To avoid damage to power circuits, do not place the TV in locations where there is excessive steam or dust. Do not place the TV on a bed, sofa, carpet, or in a sealed cabinet to avoid blocking the product's vents.
  • Page 14 Operation This product is designed for power sources as labeled on the casing. Avoid using any other power accessories to avoid electric shock or other damage. The plug can be inserted into an outlet in only one direction. Notify a qualified service techni- cian if you cannot plug it in correctly.

  • Page 15: Regulatory Information

    Regulatory Information FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is sub- ject to the following two conditions: (1) This device may not cause harm- ful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 16 DOC Compliance Notice This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.This device complies with Canada ICES-003 Class B. CE Conformity Statement This device complies with the requirements set out in the Council Direc- tive on the approximation of the Laws of the Member States relating to...

  • Page 17: Introducing The Tv

    Introducing the TV Thank you for purchasing this Liquid Crystal Display TV. Your LCD TV is designed to be safe, versatile, and easy to use. The design of the product is based on sport watch, which makes it a fun addition to any room. You can watch broadcast or cable television channels, and easily connect a VCR, VCD, or DVD player...

  • Page 18: Checking Package Contents

    Checking Package Contents Make sure the following components are included in the box. Contact your vendor immediately if anything is missing or damaged. QUARTZ HYGROMTER Warranty and User’s Manual Quick Start Guide Service Manual Wire Material Package Power Cord Power Adapter 4-IN-1 Cable RCA Jack x 3...

  • Page 19: Getting To Know Your Tv

    Getting to Know Your TV Front View MENU CH - CH + VOL - VOL + SOURCE Signal sensor Description Function Turns the On-Screen Display (OSD) Menu menus on and off. Changes channels. Press CH + to Select channel increase the channel number. Press CH – to decrease the channel number.

  • Page 20: Input And Output Ports

    Input and Output Ports Open the cover before connect- QUARTZ HYGROMTER ing the cable. DC-IN HEADPHONE AV IN Description Function Connects to an antenna or CATV cable television line. Connects to the included power DC-IN adapter. Connects to headphones or other HEADPHONE audio device.

  • Page 21: Getting Started

    Getting Started Placing the Clock and Thermometer/Hygrometer Clock 1.Turn the clock so that the screw points to the 11 o'clock position as shown (A). 2.Turn the clock face clockwise as shown (B). The clock is locked into place. Thermometer/Hygrometer 1.Turn the Thermometer/Hygrometer so that the screw points to the 5 o'clock position as shown (A).

  • Page 22: Removing The Clock And Thermometer /Hygrometer

    Removing the Clock and Thermometer /Hygrometer Clock 1.Hold the clock and twist it counter- clockwise as shown to unlock it. QUARTZ QUARTZ 2.Remove the clock Thermometer/Hygrometer 1.Hold the Thermometer/Hygrome- ter and twist it counterclockwise as shown to unlock it. Note: place your fingers as shown to avoid damage to the LCD panel.

  • Page 23: Connecting To An Antenna Or Cable Tv

    Connecting to an Antenna or Cable TV Connect one end of the UHF or CATV cable to the ANT Jack (VHF/UHF IN Jack) on the back of the TV. Connect the other end of the VHF/UHF (Antenna) or CATV cable to the antenna socket or CATV cable.

  • Page 24: Connecting To Av Devices

    Connecting to AV Devices Connect external devices such as a VCR, VCD or DVD player, or video game to the TV using the 4-IN-1 cable. Connecting to a VCR/VCD/DVD Player The illustration presented here shows how to connect the TV to a VCR and VCD or DVD player.

  • Page 25: Connecting To A Video Camera

    Connecting to a Video Camera The instructions presented here are a general guide to connecting the TV to a camcorder or other type of digital camera. Actual connec- tions may vary according to the make and model of the device. Refer to the user’s manual included with the camcorder or camera for more detailed instructions.

  • Page 26: Connecting To A Game Device

    Connecting to a Game Device The instructions presented here are a general guide to connecting the TV to a game device using the RCA Jacks provided (some game devices may require a unique adapter that is not provided). Actual connections may vary according to the make and model of the game device.

  • Page 27: Connecting External Speakers Or Headphones

    Connecting External Speakers or Headphones External speakers or headphones may be used to listen to the TV rather than using the built-in speakers. Connect external speakers or headphones to the headphone line out port as illustrated. Headphones QUARTZ HYGROMTER DC-IN HEADPHONE AV IN Speakers...

  • Page 28: Connecting The Power Adapter

    Connecting the Power Adapter Connect the power cord to the power adapter as illustrated. Plug the power adapter connector into the DC-IN input jack on the rear panel of the TV. Insert the three-pronged plug at the other end of the power cord into a power outlet.

  • Page 29: Using The Tv

    Using the TV Using the Remote Control For best results, use the remote control within a distance of 5 meters from the front of the TV’s signal sensor. Do not exceed an angle of 30 degrees when pointing at the signal sensor. Refer to the following illustration.

  • Page 30: Turning The Tv On And Off

    Turning the TV On and Off Press the POWER button on the remote control (or control panel). The power LED on the TV:10 front of the TV changes from dark to green, indicating that the power has been turned on. Press the POWER button again;...

  • Page 31: Switching Source Sigals

    Switching Source Sigals Press SOURCE on the remote Current source setting control or control panel to select MENU CH - CH + VOL - VOL + SOURCE the incoming source signal. The current source setting S-VIDEO (TV/CATV, S-Video, or AV) appears on the top left corner of the screen.

  • Page 32: Adjusting On-Screen Display (Osd) Settings

    Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust your TV’s settings. This chapter describes how to change each of the available settings. The OSD can be used with either the remote control or the front con- trol panel.

  • Page 33: Brightness

    Brightness Press MENU to enter the OSD Main Menu menus. Press the CH UP button or CH Brightness DOWN button to select Brightness. Press MENU. The brightness slide ENTER bar appears. Press the CH UP button to increase the brightness. Press the CH DOWN button to decrease the brightness.

  • Page 34: Contrast

    Contrast Press MENU to enter the OSD Main Menu menus. Contrast Press the CH UP button or CH DOWN button to select Contrast. Press MENU. The contrast slide ENTER bar appears. Press the CH UP button to increase the contrast. Press the CH DOWN button to decrease the contrast.

  • Page 35: Video Setting

    Video Setting Main Menu MENU Video Setting CH - CH + ENTER Press the MENU button to enter Press the CH UP button or CH the OSD menus. DOWN button to select Video Setting. Press MENU to enter the Video Setting menu.

  • Page 36: Hue

    Press the CH UP button or CH Video Setting DOWN button to select Hue. Press MENU to enter the Hue menu. Press the CH UP button to increase ENTER the hue towards the red spectrum. The image becomes more red. Press the CH DOWN button to decrease the hue towards the green spectrum.

  • Page 37: Saturation

    Saturation Press the CH UP button or CH Video Setting DOWN button to select Saturation. Saturatuon Press MENU to enter the Saturation menu. Press the CH UP button to increase ENTER the saturation. The screen image becomes more vibrant. Press the CH DOWN button to decrease the saturation.

  • Page 38: Sharpness

    Sharpness Press the CH UP button or CH Video Setting DOWN button to select Sharpness. Sharpness Press MENU to enter the Sharpness menu. Press the CH UP button to increase ENTER the sharpness. Press the CH DOWN button to decrease the sharpness. Press MENU again to confirm the setting and return to the Video Set- ting menu.

  • Page 39: Color Temperature

    Color Temperature Press the CH UP button or CH Video Setting DOWN button to select Color. Color Press MENU to enter the Color menu. The following three color temperatures are available. ENTER Standard Color Press the CH UP button or CH DOWN button to select Standard, then press MENU.

  • Page 40: Audio Setting

    Audio Setting Main menu MENU A u d i o S e t t i n g CH - CH + ENTER Press the MENU button to enter Press the CH UP button or CH the OSD menus. DOWN button to select Audio Setting.

  • Page 41: Treble

    Treble Press the CH UP button or CH A u d i o S e t t i n g DOWN button to select Treble. Tr e b l e Press MENU to enter the Treble menu. Press the CH UP button to increase ENTER the treble.

  • Page 42: Bass

    Bass Press the CH UP button or CH A u d i o S e t t i n g DOWN button to select Bass. Bass Press MENU to enter the Bass menu. Press the CH UP button to increase ENTER the bass.

  • Page 43: Balance

    Balance Press the CH UP button or CH A u d i o S e t t i n g DOWN button to select Balance. Balance Press MENU to enter the Balance menu. Press the CH DOWN button to shift ENTER the balance to the left speaker.

  • Page 44: Tv Setting

    TV Setting Main Menu MENU TV Setting CH - CH + ENTER Press the MENU button to enter Press the CH UP button or CH the OSD menus. DOWN button to select TV Setting. Press MENU to enter the TV Setting menu.

  • Page 45: Tv/Catv

    TV/CATV Press the CH UP button or CH Setting DOWN button to select TV/CATV. AUTO MENU Channel TV/CATV Press MENU to enter the TV/CATV menu. The following choices are CATV available. ENTER Receiving Broadcast TV Setting AUTO MENU Channel Press theCH UP button or CH DOWN TV/CATV button to select TV, then press MENU.

  • Page 46: Mts

    Press the CH UP button or CH Setting DOWN button to select MTS. AUTO MENU Channel Press MENU to enter the MTS menu. MAIN DUAL ENTER MAIN Setting Press the CH UP button or CH AUTO MENU Channel DOWN button to select MAIN (default).

  • Page 47: Auto Program

    Auto Program Press the CH UP button or CH Setting DOWN button to select AUTO MENU Channel Auto Program. AUTO Program Press MENU to enter the Auto Pro- gram menu. ENTER Press the CH UP button or CH DOWN button to select Yes or No. Press MENU.

  • Page 48: Manual Program

    Manual Program This function allows you to locate channels for adding to or erasing from preset channels. Press the CH UP button or CH Setting DOWN button to select AUTO MENU Channel Manual Program. Manual Program Press MENU to enter the Manual DOWN Program menu.

  • Page 49: Channel Add/Erase

    Channel Add/Erase Channel to be added or erased must be selected from manual program. Press the CH UP button or CH Setting DOWN button to select AUTO MENU Channel CH. Add/Erase. CH.Add/Erase Press MENU to enter the CH. Add/Erase menu. Select one of the Erase following options.

  • Page 50: Miscellaneous Setting

    Miscellaneous Setting Main Menu MENU Miscellanous CH - CH + ENTER Press the MENU button to enter Press the CH UP button or CH the OSD menus. DOWN button to select Miscellaneous. Press MENU to enter the Mis- cellaneous menu.

  • Page 51: Osd Position

    OSD Position Press the CH UP button or CH OSD Position OSD Position DOWN button to select OSD Position. H - P o s i t i o n H - P o s i t i o n Press MENU to enter the OSD Position menu.

  • Page 52: Language

    Language Press the CH UP button or CH DOWN button to select Language. Press MENU to enter the Language menu. The screen displays the available OSD languages: English and T-Chinese (Traditional Chinese). Press the CH UP button or CH DOWN button to select a language. Press MENU to confirm your choice.

  • Page 53: Sleep Timer

    Sleep Timer The sleep timer turns the TV off automatically after a set period of time. Press the CH UP button or CH Miscellaneous DOWN button to select Sleep. Sleep Press MENU to enter the Sleep menu. 30 60 90 120 The screen displays the available ENTER sleep timer setting:...

  • Page 54: Osd Display

    OSD Display This setting allows you to set whether information such as the selected channel is shown on the TV screen when the DISPLAY button is pressed. Press the CH UP button or CH Miscellaneous DOWN button to select OSD Display. OSD Display Press MENU to enter the OSD Display menu.

  • Page 55: Reset

    Reset The Reset function returns all of your TV’s user settings to their fac- tory defaults. Warning: The reset function will erase all of your custom and favorite channel settings, and will reset all display settings (such as contrast, bright- ness, etc.) to the factory default values.

  • Page 56: Taking Care Of Your Tv

    Taking Care of Your TV Turn the power off before you begin cleaning the For best results, use a clean lens cloth to remove dust and fingerprints from the screen. Do not wipe the shell of the TV with alcohol, methanol, gasoline or oil products to avoid dam- aging the finish.
  • Page 57 Notices for using the clock • Don't try to open or remove the case. • If there's any condensation on the surface, con- QUARTZ tact the dealer or return the clock to the factory for service. • Don't use the clock in an environment of extreme temperatures.

  • Page 58: Troubleshooting

    Troubleshooting Situation Solution • Connect the power cord properly. • Press the POWER button on the control panel or remote control. • Press the SOURCE button to cycle through connected video sources. No picture and sound. • Press the CH UP or CH DOWN to switch to other TV stations.
  • Page 59 Situation Solution • Make sure the source device is functioning properly. • Set the volume to a higher level. No sound but have image. • Make sure the audio cable is connected securely. • Turn the mute off. • Make sure the video signal cable is con- Screen image turns over.

  • Page 60: Specifications

    Specifications F651-12A1 LCD Panel Size 12.1-inch TFT Aspect Ratio Best Resolution 800 (horizontal) x 600 (vertical) Maximum Display Area 246 mm (H) x 184.5mm (W) TV System NTSC S-Video Input and Composite Video Input (through the Video System 4-IN-1 cable)

  • Page 61: Glossary

    Glossary Aspect Ratio The ratio of width to height of a film, image or display screen. Broadcast TV Broadcasting video signals using high-frequency electromagnetic waves to distribute television channels to viewers (standard TV broadcast). CATV Community Antenna Television, the original name for cable TV. A television distribution system that uses coaxial cable instead of the traditional radio broad- casting (over-the-air) method to deliver television, FM radio, and other services to consumers.
  • Page 62 S-Video Super-video, a video cabling standard used to transmit video by keeping brightness (Y) and color information (C) on separate channels. Most often used with camcorders, VCRs, and quality receivers and amplifiers to provide sharper pic- tures. A compact disk format developed in 1993 by Sony and Philips to capture full- motion video.
