HANNspree F009-15U1 Quick Start Manual

F009-15U1 15" Liquid Crystal Display TV
This Quick Start Guide is designed to help you set up and start using your LCD TV. Refer to the User's Manual for more detailed installation and safety instructions.

Front View

Front View
Speaker
Signal sensor
Mute
Channel down
Channel up
Volume down

Making Connections

Connecting to Antenna/Cable TV

Antenna
Antenna/CATV
coaxial cable

Connecting to a VCR, VCD, DVD Player, or Game Device

1.The illustration presented
here shows you how to
connect your TV to a
VCR, VCD, DVD player
or game device.
4-IN-1 A/V jack
Game device
4-IN-1 A/V cable

Connecting the Power Adapter

DC 12V
Power adapter
Copyright 2004, Hannspree California Inc. All rights reserved.

Quick Start Guide

Speaker
Power LED
/ Power
Auto
Menu
Source
Volume up
1. Connect one end of the VHF/UHF
(Antenna) or CATV cable to ANT Jack
(VHF/UHF IN Jack) on the back of the TV.
2. Connect the other end of the VHF/UHF
(Antenna) or CATV cable to the Antenna
or CATV socket.
ANT jack
(VHF/UHF IN Jack)
2. Refer to the user's
manual included
VCR
with your device
VCD
for more detailed
information.
DVD
3. The cables are
color- coded (black,
red, white, yellow).
Connect each color-
S-Video
coded cable to
connector
the appropriate
connector on your
device.
AV connectors
1. Connect the power cord to the power
Power outlet adapter as illustrated.
2. Plug the power adapter connector into
the DC-IN input jack on the rear panel
of the TV.
Power cord
3. Insert the three-pronged plug at the
other end of the power cord into a
power outlet.
Note : For information on connecting your
TV to a computer, refer to the user's
manual.

Rear View

Rear View
DC 12V LINE-IN
VGA

Getting Started

Watching Broadcast or Cable TV

1. Press the POWER button to turn on your TV.
2. Press the SOURCE button to select TV.
3. Press the MENU button on the
control panel to enter the OSD menu.
4. Press the CH button to select the TV setting.
5. Press the MENU button.
6. Press the CH button to select TV/CATV.

Selecting AV

1. Make sure your TV is turned on and a
device such as a DVD player is connected.
2. Press the SOURCE button on the
control panel to select different source signals.
TV/CATV channel number, AV or PC
appear on the screen.

Adjusting OSD Settings

Press the MENU/ENTER button to enter the OSD menus. Use the channel buttons on the
control panel to adjust settings.
Brightness
PC
Brightness&Contrast
Brightness 2 Brightness
5 5
Contrast Contrast
Return Return
Adjust Menu Next Adjust
Audio
PC
Audio Setting
Treble TV/CATV
Bass MTS
Balance Auto Program
L R
SRS On Off Manual Program
Mute On Off Favorite Channel
Return Return
Select Select
Menu OK
HEADPHONE
AV ANT
AV
PC
Contrast Video
PC
Brightness&Contrast Video Setting
2 G
Hue
5 5 Saturation
Sharpness
Color Temp
Return
Menu Next Adjust
TV Miscellaneous
PC
TV Setting Miscellaneous
CATV STD Language
Stereo Sleeper
Yes No OSD Display
Time Setting
More Option
Return
Select
Menu OK
MAD-001166
PC
R
Warm
Menu Next
PC
English
Off
On Off
Menu OK
