How to Use Your Binocular
If you want to...

Focus the Binocular

Diopter scale Focus knob
10
Page 10
Do this...
1. Set the Diopter Scale on underside
of CaptureView at its center point
between "+" and "-."
2. Choose an object (such as a
telephone pole) that is at least 50
feet (15m.) away.
3. Looking with only your left eye,
rotate the Focus Knob until the
object you are viewing is focused.
4. Looking with only your right eye,
rotate the Diopter Scale until the
object you are viewing is focused.
5. Now, looking with both eyes, rotate
the Focus Knob to focus on both far
and near objects.
