HANNspree ST09-10C1 Quick Start Manual

ST09-10C1 9.6" Liquid Crystal Display TV
This guide is designed as a reference to help you start using your LCD TV quickly. Please refer to the User's Manual for more detailed installation and safety instructions.
Front View Front View
Speaker
Headphone jack Channel
select
Volume
adjust

Making Connections

Connecting to Antenna/Cable TV
Antenna
L VIDEO
ANT jack
(VHF/UHF
IN jack)
L
VIDEO
Antenna/CATV
coaxial cable
Connecting to a VCR, VCD, DVD Player, or Video Game Console
1. The illustration presented
here shows you how to
connect your TV to a
VCR, VCD, DVD player
or video game console.
4-IN-1 A/V jack
L
B
R
W
Y
4-IN-1 A/V cable

Connecting the Power Adapter

Power outlet
L VIDEO
L
VIDEO
Power adapter
DC-IN
All rights reserved.
Copyright 2005, Hannspree, Inc.

Quick Start Guide

Power /
Source
Power indicator LED
Remote IR sensor
Menu
1. Connect one end of the VHF/UHF
(Antenna) or CATV cable to ANT Jack
(VHF/UHF IN Jack) on the back of the
TV.
2. Connect the other end of the VHF/UHF
(Antenna) or CATV cable to the Antenna
or CATV socket.
2. The cables are
color-coded (black,
VCR
red, white, and yellow).
Connect each color-
VCD
coded cable to
L VIDEO
the appropriate
DVD
connector on your
device.
VIDEO
B R W Y
S-Video
connector
AV connectors
1. Connect the power cord to the power
adapter as illustrated.
2. Plug the power adapter connector into
the DC-IN input jack on the rear panel
of the TV.
3. Insert the three-pronged plug at the
other end of the power cord into a
power outlet.
Power cord
Note :
Images are for illustration only and may
vary by model or region.
Rear View Rear View
Speaker
DC-IN
A/V and Channel Setup
Selecting A/V Sources
1. Make sure your TV is turned on and a
device such as a DVD player is connected.
2. Press the SOURCE button on the
control panel to select different source signals.
TV channel number, AV or AVs appear on the screen.
Note : AVs only appears on the screen when
S-Video is connected.
Auto Channel Setup
Please follow the instructions by using the control panel.
1. Press the MENU button to enter the OSD menu.
2. Use the CH button to select "TV".
+
3. Press the VOL
4. Press the CH button until the "Auto Program" feature is selected.
+
5. Press the VOL
6. Your television will begin automatically memorizing the available channels.
L
VIDEO
L
VIDEO
AV1
button to enter the TV setting.
button to begin "Auto Program".
Auto Program
TV
Auto-Programming
093.84 MHz
1 6%
Return :
MENU
Antenna/
Cable TV
AV2
CH: 4
AV1
AV2
