- Page 1 9.6"/12.1" Liquid Crystal Display G G G K K K G G G L L L M M M T T T ED Unit 2/F No Hung To Road Television Kwun Tong Kowloon Hong Kong 3822 3790 T094/T124 User's Manual MAK-000014...
-
Page 2: Table Of Contents
Table of Contents 1. Regulatory Information ........... 3 2. Description of Warning Symbols ........5 3. Safety Notices ............... 6 4. Preface ............... 13 5. Introducing the TV ............15 Features ..............15 6. Checking Package Contents ......... 16 7. Getting Started ............17 Control Panel ............ - Page 3 Table of Contents Audio Setting ............36 Equalizer ............37 Balance .............. 38 Surround ............38 Preset ..............39 TV Setting ............... 40 System ............... 41 Channel Skip ............42 Auto Program ............43 Fine Tune ............44 Favorite Channel ..........45 Customize Setting ............
-
Page 4: Regulatory Information
Regulatory Information FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Additional Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 5 DOC Compliance Notice This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.This device complies with Canada ICES-003 Class B. CE Conformity Statement This device complies with the requirements set out in the Council Directive on the approximation of the Laws of the Member States...
-
Page 6: Description Of Warning Symbols
Description of Warning Symbols Before You Proceed 1. Read all Safety Notices in Section 3 of this manual and instructions in the User’s Manual carefully before either plugging in or turning the TV on. 2. Keep this User’s Manual in a safe place for future reference. Keep the box and packaging in case the TV needs to be shipped in the future. -
Page 7: Safety Notices
Safety Notices Electric Power Notice Electric power may cause personal injury and mechanical damage if misused. Although safety has been taken into consideration during the design and production of this TV, electric shock or fire can result if the TV is misused. To prevent potential danger, read and follow the instructions and warnings contained in this manual when setting up, operating or cleaning the TV. - Page 8 Installation Safety Notes Antenna We suggest that you use an outdoor antenna to get the best signal possible unless you have cable TV or a centralized indoor antenna system. You may, however, use an antenna indoors if it is placed in a location free from interference.
-
Page 9: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. - Page 10 11 Only use attachments/accessories specified by the manufacturer. 12 Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13 Unplug this apparatus during lightning storms or when unused for long periods of time.
- Page 11 Personal Safety To avoid overloading the power supply, never plug too many electrical devices into an outlet, power strip, or extension cable. Dangerous high-voltage electric power components are located inside the TV. To avoid electric shock, do not disassemble the TV in any way.
- Page 12 Installation Do not place the TV in locations where there is excessive steam or dust. Avoid blocking the TV's vents, do not place the TV on a bed, sofa, carpet, or in a sealed cabinet. Install the outdoor antenna (not included) away from power transmission lines to avoid possible danger.
- Page 13 Operation This TV is designed for home power sources as labeled on the casing. Avoid using any other power accessories to avoid electric shock or other damage. The plug can be inserted into an outlet in only one direction. Do not alter the plug. Contact an authorized service technician if you cannot plug it in correctly.
-
Page 14: Preface
Preface Thank you for purchasing a Hannspree Liquid Crystal Display Television (LCD TV). Your new TV will allow you to enjoy superior audio and video while enriching your lifestyle with advanced technology. Please carefully read this manual in its entirety before setting up, using or operating your TV. - Page 15 No part of this manual may be reproduced in any form by any means without the prior written authorization of Hannspree. The TV described in this manual may include copyrighted software of Hannspree (or other third parties). Hannspree (or other third parties) preserves the exclusive rights for copyrighted software, such as the right to distribute or reproduce the copyrighted software.
-
Page 16: Introducing The Tv
Introducing the TV Thank you for purchasing this LCD TV. Your LCD TV is designed to be safe, versatile, and easy to use. The design makes it a fun addition to any room. You can watch broadcast or cable television channels, and easily connect a VCR, VCD, DVD player or a game device to the standard RCA and S-Video input jacks that are included in the 4-IN-1 A/V cable. -
Page 17: Checking Package Contents
Checking Package Contents Make sure the following components are included in the box. Please contact Hannspree Customer Service immediately if anything is missing or damaged. • • User’s manual • Quick start guide • Warranty and service manual • Power cord •... -
Page 18: Getting Started
Getting Started Control Panel Description Icon Function Power /POWER Turns the TV on and off. Power LED Indicates power status. Selects the input source to be displayed: (TV, AV1, AV2 or AV2s) / SOURCE Source (TV, AV or AVs) Note: If S-Video is connected, the TV autodetects it and AV and AV2 display as AVs and AV2s. -
Page 19: Input And Output Jacks
Input and Output Jacks Description Connector Function Use the included 4-IN-1 A/V cable to connect external devices, such as a VCR, VCD, DVD player, CVBS RCA cables or a game device. 4-IN-1 (AV / AV2) Audio Input: AV connector audio (white and red) cables. Video Input: AV connector video (yellow) or S-Video cable. -
Page 20: Remote Control
Remote Control Description Icon Function Press this button to activate the OSD Menu MENU menu system and to adjust various MENU ENTER settings and personal preferences. Press to scroll through the on-screen display menus. Arrow < > Favorite channels can be selected using the buttons on the remote control. - Page 21 Description Icon Function Changes channels. Press channel up to increase the channel number. Select channel Press channel down to decrease the channel number. In AV mode, press either button to return to TV mode. Press this button to cycle the video Source input sources.
-
Page 22: Inserting The Remote Control Battery/Batteries
Inserting the Remote Control Battery/Batteries Open the battery compartment cover at the back of the remote control (A). For AAA batteries: Insert the batteries paying attention to the polarity markings inside the battery compartment (B). For lithium batteries: Insert the battery / batteries with the positive side (+) facing up (B). - Page 23 CAUTION • If the remote control is not used for a long period, remove the batteries and store them separately. • Handle damaged or leaking batteries carefully, and wash hands after such handling. • If your remote control has two batteries, do not mix new and old batteries because the life of the new batteries will be shortened.
-
Page 24: Making Connections
Making Connections Connecting to an Antenna or Cable TV Connect one end of the VHF/UHF (Antenna) or CATV cable to ANT Jack (VHF/UHF IN Jack) on the back of the TV. Connect the other end of the VHF/UHF (Antenna) or CATV cable to the antenna socket or CATV cable. -
Page 25: Connecting To Av Devices
Connecting to AV Devices Connect external devices such as a VCR, VCD, DVD player, or video game console to the TV using the supplied 4-IN-1 A/V cable. Connecting to a VCR/VCD/DVD Player The illustration presented here shows how to connect the TV to a VCR, VCD or DVD player. -
Page 26: Connecting To A Video Camera
Connecting to a Video Camera The instructions presented here are a general guide to connecting the TV to a camcorder or other type of digital camera. Actual connections may vary according to the make and model of the device. Refer to the user’s manual included with the camcorder or camera for more detailed instructions. -
Page 27: Connecting To A Video Game Console
Connecting to a Video Game Console The instructions presented here are a general guide to connecting the TV to a game console using the RCA Jacks (some game devices may require a unique adapter that is not provided). Actual connections may vary according to the make and model of the game device. -
Page 28: Connecting External Speakers Or Headphones
Connecting External Speakers or Headphones External speakers or headphones may be used to listen to the TV rather than using the built-in speakers. Connect external speakers with built-in amplifier to the speaker line out port or headphones to the headphone port as illustrated. -
Page 29: Connecting The Power Adapter
Connecting the Power Adapter Connect the power cord to the power adapter as illustrated. Plug the power adapter connector into the DC-IN input jack on the rear panel of the TV. Insert the three-pronged plug at the other end of the power cord into a power outlet. -
Page 30: Using The Tv
Using the TV Using the Remote Control For best results, use the remote control within a distance of 16 feet (5 meters) from the front of the TV. Do not exceed an angle of 30 degrees when pointing at the TV. Notes •... -
Page 31: Adjusting On-Screen Display (Osd) Settings
Adjusting On-Screen Display (OSD) Settings The On-Screen Display (OSD) menu system provides a quick and simple method to adjust your TV’s settings. This chapter describes how to change each of the available settings. TV & Remote Control Buttons You may adjust the setting from your remote control or the buttons located on the TV's front control panel. -
Page 32: Osd Function Menu
OSD Function Menu The following illustration helps you become acquainted with OSD menu items. Current Menu: displays Adjustable Items: displays the title of the currently the setting or value of selected menu. adjustable items. Picture Video Mode User Contrast Brightness Saturation Main Menu: displays the... -
Page 33: Picture Setting
Picture Setting Picture Press menu to enter the OSD Video Mode User menus. Contrast Brightness Press CH UP or CH DOWN to Saturation select Picture Setting. Sharpness Color Temp Neutral Press VOL UP to enter the Preset Picture Setting menu. Adjust : Select : Return :... -
Page 34: Video Mode
Video Mode Press VOL UP or VOL DOWN to Picture switch between Video Mode options: Video Mode User Contrast User: Enables you to set user Brightness Saturation defined values. Sharpness Color Temp Neutral Dynamic: Sets the display for Preset enhanced picture contrast and Adjust : Select : Return :... -
Page 35: Color Temperature
Color Temperature Press CH UP or CH DOWN to select Picture Color Temp. Video Mode User Contrast Brightness Press VOL UP or VOL DOWN to Saturation switch between Color Temp options: Sharpness Color Temp Neutral The following three color Preset temperatures are available. -
Page 36: Preset
Preset Preset erases all customized picture settings and returns all values to factory defaults. Press CH UP or CH DOWN to select Picture Preset. Video Mode User Contrast Brightness Press VOL UP to reset all picture Saturation settings to factory defaults. Sharpness Color Temp Neutral... -
Page 37: Audio Setting
Audio Setting Audio Press menu to enter the OSD Equalizer User menus. 100Hz 330Hz Press CH UP or CH DOWN to 1KHz 3.3KHz select Audio Setting. 6.6KHz Balance Press VOL UP to enter the Surround Preset Audio Setting menu. Adjust : Select : Return : MENU... -
Page 38: Equalizer
Equalizer Press VOL UP or VOL DOWN to Audio switch between Equalizer options: Equalizer User 100Hz User: Enables you to set user 330Hz 1KHz 3.3KHz defined values. 6.6KHz Balance Movie: Sets the audio to Surround Preset accommodate movies (default). Adjust : Select : Return : MENU... -
Page 39: Balance
Balance Press CH UP or CH DOWN to select Audio Balance. Equalizer User 100Hz 330Hz Press VOL UP or VOL DOWN to 1KHz 3.3KHz adjust the balance between left and 6.6KHz Balance Surround right audio channels. Preset Press menu to confirm the setting. Adjust : Select : Return :... -
Page 40: Preset
Preset Select this item to erase all customized audio settings and return all values to factory defaults. Press CH UP or CH DOWN to select Audio Preset. Equalizer User 100Hz 330Hz Press VOL UP to reset all audio 1KHz 3.3KHz settings to factory defaults. -
Page 41: Tv Setting
TV Setting Press menu to enter the OSD menus. System CH Skip Press CH UP or CH DOWN to Auto Program Fine Tune select TV Setting. Fav. CH Press VOL UP to enter the TV Setting menu. Enter : Select : Return : MENU... -
Page 42: System
System Use the System function to determine the PAL signal type System CH Skip The signal type will be detected Auto Program Fine Tune Fav. CH automatically: B/G, D/K, or I. Enter : Select : Return : MENU... -
Page 43: Channel Skip
Channel Skip Press CH UP or CH DOWN to select CH Skip. System CH Skip Auto Program Press VOL UP to enter the CH Skip Fine Tune Fav. CH submenu. Press CH UP or CH DOWN to select Channel. Enter : Select : Return : MENU... -
Page 44: Auto Program
Auto Program Press CH UP or CH DOWN to select Auto Program. System CH Skip Auto Program Press VOL UP to begin auto Fine Tune Fav. CH programming. The TV will search for all available channels and add them to the Enter : Select : Return :... -
Page 45: Fine Tune
Fine Tune Press CH UP or CH DOWN to select Fine Tune. System CH Skip Auto Program Press VOL UP to enter the Fine Fine Tune Fav. CH Tune submenu. Press CH UP or CH DOWN to select Channel. Enter : Select : Return : MENU... -
Page 46: Favorite Channel
Favorite Channel Press CH UP or CH DOWN to select Fav. CH. System CH Skip Auto Program Press VOL UP to enter the Fav. CH Fine Tune Fav. CH Setting submenu. Press CH UP or CH DOWN to select the Favorite channel you want to Enter : Select : Return :... -
Page 47: Customize Setting
Customize Setting Customize Press menu to enter the OSD Sleep Timer menus. OSD Timeout 10 sec Language English Press CH UP or CH DOWN to select Customize. Press VOL UP to enter the Customize Setting menu. Adjust : Select : Return : MENU... -
Page 48: Sleep Timer
Sleep Timer Press CH UP or CH DOWN to select Customize Sleep Timer. Sleep Timer OSD Timeout 10 sec Language English Press VOL UP or VOL DOWN to select a sleep timer value: 30/60/90/120 minutes Adjust : Select : Return : MENU The TV will turn off after the specified number of minutes. -
Page 49: Language
Language Press CH UP or CH DOWN to select Customize Language. Sleep Timer 30min OSD Timeout 10 sec Language English Press VOL UP or VOL DOWN to select an OSD language: English Adjust : Select : Return : MENU Press menu to confirm the setting. Note The new setting is confirmed automatically when the OSD times out. -
Page 50: Taking Care Of Your Tv & Remote Control
Taking Care of Your TV & Remote Control Turn the power off before you begin cleaning the For best results, use a clean lens cloth to remove dust and fingerprints from the screen. Do not wipe the shell of the TV with alcohol, methanol, gasoline or oil products to avoid damaging the finish. -
Page 51: Troubleshooting
Troubleshooting Situation Solution • Connect the power cord properly. • Check if the power LED is on or not. • Press power on the control panel or remote control. • Press source to cycle through connected No picture and sound. video sources. - Page 52 Situation Solution • Make sure the video signal cable is Screen image turns over. connected properly. • Adjust the location of the antenna, placing it far from roads or sources of interference. Snow appears on the screen. • Check the antenna and the video signal line connections.
-
Page 53: Warranty And Service
Warranty and Service For complete warranty service information, please refer to the “Warranty and Service Manual” enclosed with your TV. -
Page 54: Specifications
Specifications 9.6 / 12.1–inch LCD TV LCD Panel Size 9.6 / 12.1–inch TFT Aspect Ratio 9.6-inch: 800 (horizontal) x 600 (vertical) Display Resolution 12.1-inch: 640 (horizontal) x 480 (vertical) TV System S-Video Input and Composite Video Input Video System (through the 4-IN-1 A/V cable) / Composite Video Input (through the RCA jacks) 4-IN-1 A/V cable L/R RCA jacks Audio System... -
Page 55: Glossary
Glossary The ratio of width to height of a film, image or display Aspect Ratio: screen. Adjusting the color temperature enables you to Color Temperature: set the intensity of white light. Color temperature is measured in Kelvin (K). Higher color temperatures result in a blue tint. Lower temperatures result in a red tint. - Page 56 MEMO...
- Page 57 MEMO...
