  • Page 1 BD5004...

  • Page 2: Important Safety Instructions

    Dealer Address this manual, meets FCC requirements. Modification not expressly PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN approved by Marantz may void your authority, granted by the FCC, to use Dealer Phone No. HAZARDOUS RADIATION EXPOSURE. the product.
  • Page 3 ESPAÑOL FRANÇAIS ENGLISH Note on use / Observations relatives a l’utilisation / Notas sobre el uso CLASS 1 LASER PRODUCT Copyrights / Droits d’auteur / Derechos de Autor • It is prohibited by law to reproduce, broadcast, rent or play discs •...

  • Page 4: Table Of Contents

    ENGLISH Contents Selecting the Format of Audio and Video ......24 Introduction Connections Selecting Audio Streams/Channels ..........24 Selecting Subtitle Language ............25 Important ..................2 Connecting to a TV ................12 Virtual Surround ................... 25 Power Supply ................2 Connecting to a Display Device with HDMI Cable ....12 Pure Direct Mode .................

  • Page 5: Important

    ENGLISH Introduction • Noise or disturbance tends to occur particularly when using Important Dew Warning indoor antennas or 300Ω/ohms feeder wires. We recommend using outdoor antennas and 75Ω/ohms coaxial cables. Use only discs marked with logos listed on page 4. Moisture condensation may occur inside the unit when it is moved from a cold place to a warm place, or after heating a cold room or under conditions of high humidity.

  • Page 6: Features

    ENGLISH Introduction Introduction ●BD-Live Features About Discs BD-Live (BD-ROM version 2 Profile 2.0) that allows interactive ●PIP (Picture in Picture) (BONUSVIEW) Setting functions to be used when this unit is connected to the Internet Disc Handling Some BD-Video have the PIP (picture-in-picture) function which in addition to the BONUSVIEW function.

  • Page 7: Playable Discs And Files

    ENGLISH Introduction Introduction Playable files Logos Media Playable Discs and Files Readable cards Playable files / data DVD-RW/-R SD Memory Card (8MB - 2GB) AVCHD, MP3, Windows Media™ This unit is compatible to play back the following discs. SD Memory Card Audio, JPEG, Picture-in-picture To play back a BD or DVD, make sure that it meets the SDHC Memory Card (4GB - 8GB)

  • Page 8: Unplayable Discs

    ENGLISH Introduction Introduction Unplayable Discs Region Codes Symbols Used in this User Guide The following discs will not play back on this unit. This unit has been designed to play back BD with To specify for which media type each function is, we put the BD-Video region A and DVD-Video with region 1.

  • Page 9: About The Remote Control

    Changing the Signal Code of a Remote Control proximity of the main unit, replace the batteries with new To avoid the other Marantz’s BD players responding the remote ones, even if less than a year has passed. signal of this unit, you can change the signal code of the remote •...

  • Page 10: Part Names And Functions

    ENGLISH Introduction Introduction Part Names and Functions Front Panel Rear Panel 10 11 12 DIGITAL OUT COMPONENT VIDEO OUT VIDEO OUT FLASHER AC IN COAXIAL 2ch AUDIO OUT NETWORK HDMI OUT The unit can also be turned on by pressing the buttons with circled numbers. 1.

  • Page 11: Remote Control

    6. ZOOM button • This button can be used to adjust the volume of devices • During playback, press to enlarge the picture on the screen. compatible with Marantz amplifiers that come with a remote 7. CLEAR button controller. • Press to clear the information once entered, to clear the 24.

  • Page 12: Front Panel Display

    ENGLISH Introduction Introduction 30. POP UP MENU / MENU button Front Panel Display • Press to display the pop-up menu/disc menu/file list. • Press to change “Original” and “Playlist” on the TV screen. 31. SEARCH MODE button • Press to display the search menu. 32.

  • Page 13: Examples Of Displays During Operation

    ENGLISH Introduction Introduction Examples of Displays during Operation Display Description Power on Standby mode Tray open Tray is closing Loading the disc No disc inserted This unit cannot read the disc or SD Memory Card inserted. Stop mode HDMI output mode (480i) is selected. HDMI output mode (480p) is selected.

  • Page 14: Connections

    Connections Connect the BD5004 as follows before using. Make connections according to the equipment you are connecting. Some BD5004 settings may be necessary depending on the connection method. Check each connection item for more information. Home theater playback Playing back with a direct connection to a TV...

  • Page 15: Connecting To A Tv

    ENGLISH Connections Connections Connecting to a TV Connecting to a Display Device with HDMI Cable Connecting this unit to device with an HDMI jack using an HDMI cable enables digital transfer of both Make one of the following connections, depending on the capabilities of your existing device. digital video signals and multi-channel audio signals.

  • Page 16: Hdmi Output Mode And Actual Output Signals

    ENGLISH Connections Connections HDMI Output Mode and Actual Output Signals Audio Setting Press [HDMI RESOLUTION] to select the HDMI output mode. HDMI video resolution changes as When using HDMI connections make the “HDMI Audio Out” settings in the “Audio” menu on the following.

  • Page 17: Digital Connection To An Av Amplifier With Built-In Decoder

    ENGLISH Connections Connections • If “BD Audio Mode” is set to “HD Audio Output” or the BD title does not have secondary or When HDMI is not connected or the “Audio Mute” is selected in “HDMI Audio Out” setting, the audio interactive audio, the audio will be output as shown in the table.

  • Page 18: Connection To A Device With 2-Channels Of Analog Audio Inputs

    ENGLISH Connections Connections Connection to a Device with 2-channels of Analog Audio Inputs Network Connection with LAN • You can use a disc which offers BD-Live function by connecting the unit to the Internet. (For BD-Live information, please refer to page 29.) RCA audio cable audio Stereo component...

  • Page 19: Connecting The Ac Cord

    ENGLISH Connections Connections Connecting the AC cord After you made all necessary connections, connect the AC cord to the AC IN. Then connect the AC cord to the AC outlet. AC outlet AC IN DIGITAL OUT COMPONENT VIDEO OUT AC 120V, 60 Hz AC cord COAXIAL NETWORK...

  • Page 20: Playback

    ENGLISH Playback [POWER OFF] Direct Playback Disc playback BD-V DVD-V DVD-VR AVCHD Direct Playback (BD/DVD-Video/AVCHD) : page 17 [POWER ON] Turn on the power of this unit. (Refer to “Turning Playing Back a VR mode DVD-RW/-R : page 18 the Power On” on this page.) Playing Back an Audio CD or a Disc with DivX®/MP3/Windows Media™...

  • Page 21: Operations Using Disc Menu, Title Menu, And Popup Menu

    ENGLISH Playback Playback Pause [POP UP MENU / Note MENU] 1) During playback, press F. • If the feature is not available, may appear on the TV [TOP MENU] Playback will be paused. screen. • Contents of menus and corresponding menu operations may [ENTER] vary among discs.

  • Page 22: Fast Forward / Fast Reverse Playback

    ENGLISH Playback Playback Fast Forward / Fast Reverse Playback Step by Step Playback Dialog Speed DVD-V DVD-VR DivX ® BD-V DVD-V DVD-VR AVCHD DivX ® BD-V AVCHD BD-V DVD-V DVD-VR AVCHD 1) During playback, press F. This function plays back approximately at 1.3 times of normal •...

  • Page 23: Repeat Playback

    ENGLISH Playback Playback 3) Press B to start program playback. Repeat Playback Note • Program playback will start. Available repeat function may vary depending on the discs. • The chapter/title/track/group repeat setting will be cleared Note when moving to other chapter, title, track/file or folder. 1) During playback, press [REPEAT] repeatedly until desired •...

  • Page 24: Random Playback

    ENGLISH Playback Playback 1) During playback, press [MODE] repeatedly until the PIP Zoom setting appears. Note • PIP information will appear. DivX ® JPEG • During the random playback, press C once to set the resume DVD-V DVD-VR 2) Use [ ] to select the secondary video you want.

  • Page 25: Camera Angle

    ENGLISH Playback Playback Using [SEARCH MODE] Marker search Note By using the [SEARCH MODE], you can select following search This feature allows you to assign a specific point on a title or track • For BD and AVCHD, zoom function is not available. options.

  • Page 26: On-Screen Display

    ENGLISH Playback Playback Bit rate information [POP UP MENU / [TOP MENU] MENU] OFF (File information (elapsed time)) File name information Tag information (title name) Tag information (artist name) OFF (File information (elapsed time)) [ENTER] B L1 [SUBTITLE] JPEG [AUDIO] [DISPLAY] File information File name information...

  • Page 27: Selecting The Format Of Audio And Video

    ENGLISH Playback Playback HDMI information AVCHD DivX ® DVD-V DVD-VR File name information 1) During playback, press [AUDIO]. 2) Use [ ] to select your desired audio stream/channel. Video Info YCbCr 1080i MP3 MUSIC Dolby D 3/2.1ch Audio Info Dolby Digital Max Channel •...

  • Page 28: Selecting Subtitle Language

    ENGLISH Playback Playback Video / audio outputs for each mode Selecting Subtitle Language “Normal” : Normal playback mode (pure direct mode is off). DivX ® BD-V DVD-V ΑVCHD ® [ENTER] “VideoOff” : Video signal will not be output. BD, DVD-Video, AVCHD and DivX may have subtitles in 1 or more languages.

  • Page 29: Adjusting The Picture

    ENGLISH Playback Playback Adjusting the Picture Adjustment range ® Playing Back an Audio CD or a Disc with DivX /MP3/ Item Description (* : Default setting) Windows Media™ Audio/JPEG File BD-V DVD-V DVD-VR AVCHD DivX ® Off* You can adjust the picture quality and store the setting you have DivX ®...
  • Page 30 ENGLISH Playback Playback ® ® <DivX > Hint for the purchased or rental official DivX Certified ® product ® To Play Back the DivX Subtitle Created by the Official DivX Certified product ® • When you purchased or rented a DivX file through the official •...

  • Page 31: Kodak Picture Cd

    ENGLISH Playback Playback ® Tips for JPEG/Kodak Picture Playback What is DivX • Every press on [ANGLE] will turn the image clockwise by 90 ® • DivX is a codec (compression/decompression) that can compress degrees when an image is displayed. images to a very small amount of data.

  • Page 32: Enjoying Bd-Live Discs With Internet

    ENGLISH Playback Playback Removing the SD Memory Card Follow the step 2 in “Playing Back an Audio CD or Enjoying BD-Live Discs with Internet a Disc with DivX®/MP3/Windows Media™ Audio/ In stop mode, push the SD Memory Card and then BD-V JPEG File”...

  • Page 33: Function Setup

    ENGLISH Function Setup Use [ ] to select setting items. Follow the procedure below depending on the [the Number buttons] setting items. For setting item A : [CLEAR] Press [ENTER] repeatedly to change options. Follow the procedure below depending on the For setting item B : [RED / GRN / BLU / setting items.
  • Page 34 ENGLISH Function Setup Function Setup Language Video Video Video Language TV Aspect 16:9 Wide Progressive Mode Auto Dialog Original HDMI Select YCbCr Still Mode Auto Subtitle HDMI RGB Setting Normal Wall Paper Picture Disc Menu English HDMI Auto Format OSD Language English HDMI Video Resolution Auto...
  • Page 35 ENGLISH Function Setup Function Setup Setting items Options Setting items Options HDMI RGB Setting Progressive Mode Auto*: Normal*: Sets the digital RGB image range Sets the optimum progressive The progressive mode will detect 24-frame film material Output as “16 (black)” to “235 (white)”. (data range) output from the HDMI mode for the image material (movies) and automatically select appropriate...
  • Page 36 ENGLISH Function Setup Function Setup Setting items Options Audio Wall Paper Picture* Sets the picture to be displayed on Blue the screen for stop mode or audio Black playback mode. Gray Audio • Settings with (*) are the default. • Quick menu consists of the setting menus frequently used, and they are accompanied with BD Audio Mode Mix Audio Output mark.
  • Page 37 ENGLISH Function Setup Function Setup Setting items Options Bitstream*: When playing back discs recorded in Dolby Digital, Dolby Digital Plus, Dolby TrueHD, DTS or Down Sampling DTS-HD, the corresponding core stream (Dolby Digital or DTS) are output. Sets the digital audio output when PCM signals are converted to 48 kHz for output.
  • Page 38 ENGLISH Function Setup Function Setup To make the most of its feature, set up your speakers appropriately by referring to the table below. • For “Speaker Configuration” setting, the settings of each speaker size may be adjusted automatically corresponding to each setting. (e.g. If “Front” is set to “Small”, you cannot set Speaker setting options are available in SETUP Quick HDMI Audio Out...
  • Page 39 ENGLISH Function Setup Function Setup Ratings Menu Setting items Options Descriptions Ratings control allows you to set a limit, which prevents your children from viewing inappropriate Delay Time Distance Feet* Set the desired measure materials. Playback will stop if the ratings exceed the levels you set, and it will require you to enter a system.
  • Page 40 ENGLISH Function Setup Function Setup RATING EXPLANATIONS Setting items Options Description • All : Parental control is inactive; all discs can play back. Angle Icon • 8 [Adult] : DVD software of any grades (adult/general/children) can be played Off* The angle icon appears on the back.
  • Page 41 ENGLISH Function Setup Function Setup Setting items Options Description Setting items Options Description DivX(R) VOD Registration Code This menu item provides you with HDMI CEC ® Your registration code is: the DivX VOD registration code. Sets whether to utilize ® the HDMI CEC function.

  • Page 42: Network Connection

    ENGLISH Function Setup Function Setup If you want to set the network settings back to the default settings as above (except “BD-Live Network Connection Setting”), follow the procedure below. 1) Follow steps 1) to 4) in “Connection Test” on this page. Connection Test 2) Use [ ] to select “Enable(Easy)”, then press [ENTER].
  • Page 43 ENGLISH Function Setup Function Setup Proxy Setting 1) Follow steps 1) to 2) in “IP Address Setting” on page 39. 2) Use [ ] to select “Proxy Setting”. IP Address Setting 3) Press [ENTER] repeatedly to select the desired setting. Is Setting OK? IP Address ∗∗∗...

  • Page 44: Disable

    ENGLISH Function Setup Function Setup Proxy Port “10BASE Full” : Set the connection speed to “10BASE Full”. “100BASE Half” : Set the connection speed to “100BASE Half”. Use [ ] to select “Proxy Port”, then press [ENTER]. “100BASE Full” : Set the connection speed to “100BASE Full”. •...

  • Page 45: Initialize

    ENGLISH Function Setup Function Setup Setting items Options Description Note Erase Saved BD-ROM Yes: • Please do not unplug the AC cord or LAN cable while executing the “Network Update”. Data (SD Card) Re-format BD-ROM Data (SD Card) • All settings will remain the same even if you update the firmware version. used for BD-Java.

  • Page 46: Trademark Information

    4:3 Pan-and-Scan When a wide (16 : 9) disc is played back by connecting a 4 : 3 TV and the BD5004, this function cuts left and right of the played Manufactured under license under U.S. Patent #’s: 5,451,942; back image to the 4 : 3 size according to the disc’s control 5,956,674;...
  • Page 47 This mechanism automatically perform network configuration Dynamic Range back the files on this unit. such as IP address for network devices including BD5004, PC, and The difference between the maximum undistorted sound level broadband router. and the minimum sound level that is discernible above the noise emitted by the device.
  • Page 48 Depending on the age of the viewer, this function restricts playing files on disc or SD Memory Card from a computer and play them back of BD-Video or DVD-Video. BD5004 can be set to restrict back on this unit. viewing in 1 to 254 level for BD-Video, and 1 to 8 level for DVD- Video.

  • Page 49: Index

    ENGLISH Others Others Index Playback (Kodak Picture CD) ..............28 page page Playback (SD Card) ................28 A-B Repeat ....................8 Fast forward ..................8 Popup menu ..................9 AC cord ....................... 3 Fast reverse ................... 8 Program playback ..................20 Angle ....................

  • Page 50: Troubleshooting

    ENGLISH Others Others Troubleshooting If the unit does not perform properly when operated as instructed in this user guide, check the unit, consulting the following checklist. Problem Solution Page Problem Solution Page No power - Check if the AC cord is properly connected. –...

  • Page 51: Language Code

    ENGLISH Others Others Language Code Language Code Language Code Language Code Language Code Language Code Esperanto 5161 Kinyarwanda 6469 Quechua 6367 Tigrinya 6655 Estonian 5166 Kirghiz 5771 Rhaeto-Romance 6459 Tonga 6661 Abkhazian 4748 Kirundi 6460 Romanian [RUM] 6461 Tsonga 6665 Afar 4747 Faroese...

  • Page 52: Specifications

    ENGLISH Others Others Specifications ANALOG AUDIO OUTPUT SIGNAL SYSTEM Output level: 2Vrms (10kΩ/kohms) NTSC color 2 channel (L, R) output connector: Pin jacks, 1 set APPLICABLE DISCS AUDIO OUTPUT PROPERTIES (1) BD/DVD-Video Discs (1) Frequency response 1-layer 12cm single-sided discs, 2-layer 12cm single-sided discs, 2-layer 12cm double-sided discs 1 BDs (linear PCM) : 20Hz to 22kHz (48kHz sampling) (1 layer per side) / 1-layer 8cm single-sided discs (DVD)
  • Page 54 E5KB1UD / 1VMN27773A ★★★★ Printed in China 07/2009 541110331126M mzh-d...
