Specifi cations

Main unit
Amplifi er section
Rated output power
..............................20 W + 20 W (1 kHz, 10% T.H.D., at 8 Ω)
D.AUDIO/ AUX (Sensitivity/ Impedance) .... 500 mV/10 kΩ
SUBWOOFER PREOUT (Level/ Impedance) ......1.8 V/10 kΩ
Tuner section
FM tuner section
Tuning frequency range ......................87.5 MHz ~ 108.0 MHz
AM tuner section
Tuning frequency range ...........................531 kHz ~ 1,602 kHz
CD player section
Laser .....................................................................Semiconductor laser
Laser wave length ......................................................770 ~ 810 nm
Laser power class ........................................................Class 1M (IEC)
Over sampling ............................................................8 fs (352.8 kHz)
D/A conversion ..................................................................................1 Bit
USB interface
USB standard ....................................................................... USB 1.1/2.0
Maximum supply current ....................................................500 mA
File system ............................................................................... FAT 16/ 32
SD card interface
Format ........................................................................ SD memory card
Usable SD cards
............................ SD/SDHC, miniSD, microSD/SDHC card
File system ............................................................................... FAT 16/ 32
General
Provided AC adapter ..........DC 18 V (AC 230 - 240 V, 50 Hz)
Power consumption (Incl. AC adapter) ............................. 25 W
Power consumption in standby mode ............... 1 W or less
Dimensions .........................................................................W : 190 mm
(with iPod applied part) W : 286 mm
H : 240 mm
D : 142 mm
Weight (net) ..................................................................................... 1.4 kg
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the warranty card, and in the space provided
below. Refer to the model and serial numbers whenever you call upon your dealer for information or service on this product.
Model Serial Number
24
C-414
Speakers
Enclosure ..................................................................... Bass-refl ex type
Speaker confi guration
Full range ..................................................... 86 mm, cone type
Impedance .............................................................................................8 Ω
Maximum input ............................................................................... 20 W
Dimensions .........................................................................W : 130 mm
H : 238 mm
D : 133 mm
Weight (net) ................................................................ 0.9 kg (1 piece)
Notes:
• Kenwood follows a policy of continuous advancements in
development. For this reason specifications may be changed
without notice.
• Sufficient performance may not be exhibited at extremely
cold locations (where water freezes).
Memory back up function
Please note that the following items will be deleted from the
unit's memory if the power cord is disconnected from the
AC outlet.
• Input selector settings
• Volume level
• Sound control (preset equalizer, bass enhancement)
• Tuner setting
