MB-3 Electromagnetic Organ
The MB-3 is a Classic Tonewheel Organ with Leslie rotary speaker simulator.
Percussion On/Off: switches percussion section On/Off.
Short/Long: selects duration of percussion.
Loud/Soft: loud or soft percussion.
3rd/2nd: 3rd or 2nd harmonic for percussion.
Drawbars
Laid out as per a classic Tonewheel Organ:
16'
Fundamental
5 1/3'
3rd Harmonic
8'
2nd Harmonic
4'
4th Harmonic
2 2/3'
6th Harmonic
2'
8th Harmonic
1 3/5'
10th Harmonic
1 1/3'
12th Harmonic
1'
16th Harmonic
Click: sets the level of mechanical key on and off clicking.
Scanner Vibrato
Classic Tonewheel Organs had an additional chorus/vibrato section. The 'V' settings are vibrato settings while the 'C' settings are choruses.
V1 & C1: produces the lightest modulation.
V2 & C2: produces a deeper modulated sound.
V3 & C3: are the deepest and grittiest settings.
Drive: allows you to add tube overdrive before the rotary speaker.
Rotary On/Off: turns rotary speaker on/off.
Slow/ Fast: sets rotary speed.
NB: rotary speed can also controlled by the pitch wheel. Moving the pitch wheel up sets the rotary speed to fast while moving it down sets
it to slow.
1 Octave and a Fifth Higher
1 Octave Higher
2 Octaves Higher
2 Octaves and a Fifth Higher
3 Octaves Higher
3 Octaves and a major 3rd Higher
3 Octaves and a Fifth Higher
4 Octaves Higher
10
