Sharp PW-GT570 Quick Reference Manual

QUICK REFERENCE
Layout
Display
(Main display)
Selection key for
contents
Global search key
Power ON/OFF key
Earphone jack
(side)
Volume control keys
(volume up/down)
Function key
Audio key
Speaker
Character size
change keys
Page scroll keys
PRINTED IN CHINA
Using the PW-GT570 for the fi rst time
Insert the supplied batteries before using the PW-GT570.
Inserting the batteries
1
Set the battery replacement switch
on the bottom of the unit to the "
" position.
2
Remove the battery cover by sliding
it in the direction indicated by the
arrow.
3
Make sure the battery polarity is
Ribbon tab for removing Ribbon tab for removing
correct.
• Insert the batteries over the ribbon tab,
being sure not to cover the end of the tab.
4
Insert the battery cover horizontally
when putting it back in place.
5
Set the battery replacement switch to
the " " position.
6
Open the unit and press to turn on the power.
After displaying the message "Welcome to Papyrus World", the calibration
screen for the handwriting pad appears.
If the power cannot be switched on, perform the following procedure.
ELECTRONIC DICTIONARY
Utility keys for
dictionaries and
functions
Backlight key
Menu key
Stylus holder
(side)
Card slot
(side)
Cursor keys
Clear key
Back space key
Speaker
Escape key
Search/enter key
Handwriting pad
08ASP(TCADZ0254EHZZ) 0GS9701820////
• Make sure the battery replacement switch is in the "
again.
position and press
• If the power still cannot be switched on, try performing steps 1 through 6
in the above procedure once more.
7
Pull out the stylus and use it to accurately touch each center
of the four "+" characters displayed on the handwriting pad.
Back of
the unit
Stylus
• Touching each center of the four "+" characters displays the LCD contrast adjustment screen.
the batteries the batteries
8
Adjust the LCD contrast of the main display by pressing
or .
9
Adjust the LCD contrast of the handwriting pad by touching
or on the pad.
10
After these adjustments, press
The key sound (beep) on/off screen appears.
11
Press or to turn the key sound on/off.
The kana entry screen appears.
12
Press to select alphabet character input or press
select Japanese input.
The battery type selection screen appears.
13
Select the battery type ("
using or and then press
Entering characters using the handwriting pad
Parts and functions
PW-GT570
The handwriting pad is set to enter characters when the cursor is in any part of
the character entry area.
[ Single-frame pad ]
Candidate list display area
Automatic/manual
recognition indicator
Character entry type
indicator
Handwriting area (frame)
[ Dual-frame pad ]
Character entry display area
Candidate list
display area
Automatic/manual
recognition indicator
Character entry type
indicator
Handwriting areas (frames)
Entering characters using the single-frame pad
Example: Enter a Japanese word "
1
Press .
The &
The handwriting pad is set to the English character entry mode.
• If the dual-frame pad is displayed, touch
single-frame pad.
5
" Likewise, enter " " in the entry area.
6
Press .
The details screen appears.
Entering characters using the dual-frame pad
Example: Enter a Japanese word "
1
Press .
2
Touch to switch to the dual-frame pad.
.
3
Use the stylus to draw " " in either of the framed areas.
When automatic recognition is used, the entry is
recognized within one to two seconds after the stylus
is moved away from the handwriting pad, and the
to
candidate character appears in the entry display area.
When the recognition is used, you need to touch
to have the dictionary recognize the entry.
When you enter two or more characters, the entry is
(alkaline dry cell)")
recognized immediately after you start writing the next
. character in the other framed area.
2
Press
The handwriting pad is now switched to enter kanji and kana.
button
button
3
button
Use the stylus to draw " " in the handwriting area.
button
button
button
button
button
4
button
If the character in the entry area is not the one you desired,
button
use the stylus to touch and select the desired character in
button
the list.
The character in the entry area changes.
" from a Japanese-English dictionary
entry/selection screen appears.
• If you cannot fi nd the character in the list, touch
to switch to the
to erase it and redraw it on the pad.
4
If a character is recognized incorrectly, use the stylus to
touch the character. In the candidate list display area, fi nd
• When you start drawing, the previous entry
and touch the character that you want to replace it with.
is confi rmed and then erased.
5
Repeat steps 3 and 4 to enter " " and " ".
" ( ) from .
6
After entering the word,
touch
the dictionary's entry fi eld.
You can then proceed with the
dictionary search.
7
Use or
The details screen is displayed.
to move the cursor to the Japanese entry area.
The character shown in the candidate list display area is
also placed in the entry area so that the dictionary search
can proceed.
• When the manual recognition is used, press to
have the dictionary recognize the entry.
or press
• The character in the entry display area is
replaced with the character selected in the
candidate list display.
Up to six characters can be accommodated.
• For longer words, enter up to six characters and touch
to transfer the entries to the entry fi eld.
to transfer it to
to select a candidate and press .
