Sharp LC-40Z5T Service Manual

Sharp LC-40Z5T Service Manual

Lcd colour television
Hide thumbs

Advertisement

Quick Links

Download this manual
TopPage
LCD Module Edition
In the interests of user safety (required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
In this Service Manual, only parts in the LCD module are shown.
For the other points, refer to the LC-40/46/52/60Z5T (S51Q2LC60Z5T/) Service Manual.
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LCD COLOUR TELEVISION
MODELS
OUTLINE
LC-40/46/52/60Z5T
No. S51Q5LC60Z5T/
LC-40Z5T
LC-46Z5T
LC-52Z5T
LC-60Z5T
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LC-40Z5T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sharp LC-40Z5T

Summary of Contents for Sharp LC-40Z5T

  • Page 1: Service Manual

    TopPage LC-40/46/52/60Z5T SERVICE MANUAL No. S51Q5LC60Z5T/ LCD COLOUR TELEVISION LC-40Z5T LCD Module Edition LC-46Z5T LC-52Z5T LC-60Z5T MODELS In the interests of user safety (required by safety regulations in some countries) the set should be restored to its original condition and only parts identical to those specified should be used.
  • Page 2 LC-40/46/52/60Z5T LC40Z5T OUTLINE Service Manual OUTLINE In this Service Manual, only parts in the LCD module are shown. For the other points, refer to the LC-40/46/52/60Z5T (S51Q2LC60Z5T/) Service Manual. NOTE: When replacing the LCD control PWB, perform the VCOM adjustment.
  • Page 3 LC40Z5T Removing LCD Module Service Manual [1] LC-40Z5T 1. Remove the 4 lock screws [1], 13 lock screws [2], 12 lock screws [3] and detach the Bezel Unit (Top) [4], Bezel Unit (Bottom) [5] and Bezel Unit (Left/Right) [6]. 2. Detach the 40” LCD Panel Module Unit [7].
  • Page 4 LC-40/46/52/60Z5T [2] LC-46Z5T 1. Remove the 4 lock screws [1], 12 lock screws [2] and detach the 46” LCD Panel HIRAK Unit [3]. 2. Detach the DBEF Sheet [4], Lens Sheet [5], Micro Lens Sheet [6], Light Guide Plate [7], Reflection Sheet [8], 4 pieces Graphite Sheet [9]. 3.
  • Page 5 LC-40/46/52/60Z5T [3] LC-52Z5T 1. Remove the 5 lock screws [1], 19 lock screws [2] and detach the 52” LCD Panel HIRAKI Unit [3]. 2. Detach the DBEF Sheet [4], Lens Sheet [5], Micro Lens Sheet [6], Light Guide Plate [7], Reflection Sheet [8], 4 pieces Graphite Sheet [9]. 3.
  • Page 6 LC-40/46/52/60Z5T [4] LC-60Z5T 1. Remove the 7 lock screws [1], 19 lock screws [2] and detach the 60” LCD Panel HIRAKI Unit [3]. 2. Detach the DBEF Sheet [4], Lens Sheet [5], Micro Lens Sheet [6], Light Guide Plate [7], Reflection Sheet [8], 4 pieces Graphite Sheet [9] and 4 pieces Graphite Sheet [23].
  • Page 7 LC-40/46/52/60Z5T PartsGuide PARTS GUIDE No. S51Q5LC60Z5T/ LCD COLOUR TELEVISION LC-40Z5T LC-46Z5T LC-52Z5T LC-60Z5T MODELS CONTENTS LCD PANEL MODULE Assembly LCD PANEL MODULE Assembly (LC-40Z5T) (LC-52Z5T) LCD PANEL MODULE Assembly LCD PANEL MODULE Assembly (LC-46Z5T) (LC-60Z5T) Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
  • Page 8 LC-40/46/52/60Z5T [1] LCD PANEL MODULE Assembly (LC-40Z5T) 40" LCD Panel...
  • Page 9 LC-40/46/52/60Z5T PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [1] LCD PANEL MODULE Assembly (LC-40Z5T) 40" LCD Panel Module Unit R1LK400D3GW6AA Bezel Unit (Top) CANGK4919TP02 Bezel Unit (Bottom) CANGK4920TP02 Bezel Unit (Left/Right), x2 CANGK4921TP02 P Chassis Unit (Top) CHLDZ4763TP01 P Chassis Unit (Bottom)
  • Page 10 LC-40/46/52/60Z5T [2] LCD PANEL MODULE Assembly (LC-46Z5T)
  • Page 11 LC-40/46/52/60Z5T PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [2] LCD PANEL MODULE Assembly (LC-46Z5T) Backlight Ass'y 46" LCD Panel HIRAKI Unit R1LK460D3FW30A LED Angle, x2 CANGT0334TPN1 Back Light Chassis Unit CCHSM0329TPN1 Holder Unit (Left) CHLDZ4788TPN2 Holder Unit (Right) CHLDZ4788TPN3 LED Label TLABK0023TAZZ Screw, x6...
  • Page 12 LC-40/46/52/60Z5T [3] LCD PANEL MODULE Assembly (LC-52Z5T)
  • Page 13 LC-40/46/52/60Z5T PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [3] LCD PANEL MODULE Assembly (LC-52Z5T) Backlight Ass'y 52" LCD Panel HIRAKI Unit R1LK520D3FW30A LED Angle, x2 CANGT0342TP01 Holder Unit, x2 CHLDZ4800TP02 LED Label TLABK0023TAZZ Back Light Chassis Unit CCHSM0331TP01 Screw, x10 LX-BZ2568TPZZ Screw, x28 LX-HZ2414TPZZ...
  • Page 14 LC-40/46/52/60Z5T [4] LCD PANEL MODULE Assembly (LC-60Z5T)
  • Page 15 LC-40/46/52/60Z5T PRICE PARTS CODE PART DESCRIPTION RANK MARK DELIVERY [4] LCD PANEL MODULE Assembly (LC-60Z5T) Backlight Ass'y 60" LCD Panel HIRAKI Unit R1LK600D3FZE0A LED Angle, x2 CANGT0136TP01 Holder Unit, x2 CHLDZ4605TP01 LED Label TLABK0023TAZZ Back Light Chassis Unit CCHSM0132TP01 Screw, x8 LX-HZ2413TPZZ Screw, x24 LX-HZ2414TPZZ...
  • Page 16 LC-40/46/52/60Z5T © COPYRIGHT 2011 BY SHARP CORPORATION ALL RIGHTS RESERVED. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.
