Battery Charging Procedure - FilterStream D4200 Instruction Manual

B A T T E R Y C H A R G I N G P R O C E D U R E
Your DustTamer Deluxe
cordless, rechargeable vacuum
chamber to suction dust off your
DustTamer ® Duster. When fully
charged, your vacuum chamber
will have enough power to clean
your Duster approximately 50
times.
To charge your DustTamer
Deluxe ® , please follow these steps:
1. Open the Battery/AC Adapter
Compartment by depressing
the purple Compartment Latch
at the rear of the unit and
sliding the Battery/AC Adapter
Compartment out of the
Vacuum Chamber. (see figure 1)
2. Upon first use of the
DustTamer Deluxe
the white plastic tab marked
"Remove Before Use".
3. Remove the supplied AC
Adapter from the Battery/AC
Adapter Compartment and
connect it to the AC Adapter
Jack located at the rear bottom
of the Vacuum Chamber and
plug the AC Adapter into a wall
outlet. (See figure 2)
® uses a
, remove
®
8
1
Fig.
Fig. 2
