FilterStream D4200 Instruction Manual page 17

Note: Make sure that all parts
are dry before putting them
back together.
5. After cleaning, insert the
HEPA Filter back into the
Lower Vacuum Chamber
Housing, and the Stainless
Steel Pre-Filter back into the
Upper Vacuum Housing. A light
"click" is heard when firmly
seated. (see figure 14)
6. The Vacuum Chamber is put
back together by connecting
the rectangular slot on the rear
of the Upper Vacuum
Chamber to the rear
protruding tab on the Lower
Vacuum Chamber Housing
Then lower the Upper Vacuum
Chamber Housing onto the
Lower Vacuum Chamber
Housing until an an audible
"click" is heard.
(see figure 15)
17
Fig. 14
15
Fig.
