Alvin Mobile File Cart WTF35 Assembly Instructions

B
F F
A
A
1. Attach grid tray with small openings(A), to bottom of large
frame section(B).
2. Attach remaining two trays(C).
3. Secure smaller frame section(D) in the same manner.
4. Using enclosed screws, attach left and right side braces(F)
at opposite angles for support.
5. Twist casters(E) into place.
6. Optional white dust protector may by placed on the bottom
tray if desired. To hold dust protector in secure position use
transparent tape at each corner.
Alvin & Company, Inc.
Assembly Instructions for
Mobile File Cart No. WTF35
D
C
E
B
Bloomfield, CT
CONTENTS
Key Key Qty. Qty. Description Description
A 1 Grid Tray with small openings
B 1 Frame Section with rubber feet
C 2 Grid Tray with large openings
D 1 Frame Section
E 2 Covered Casters with lock nuts
F 2 Side Braces (left and right)
G 1 Dust Protector bottom cover
(Optional)
12 Nuts,
4 Screws
C
G
Grand Prairie, TX
D
F
E
Rancho Cordova, CA
TAIWAN
