Front and Rear Panel Controls

Front Panel
AM frequency readout
Back Panel
Connect indoor
antenna here,
uncoil and stretch
out fully along a
wall or window
sill.
Indoor AM Antenna
Model # IAM-Indoor Antenna
Push to Start Playback
of Recorded Message
Connect optional
outdoor antenna
Insert key to
here via RG-6
allow message
coaxial cable
record or
frequency
change
Select indoor or
outdoor antenna
Antenna Tuner / Range Extender
Model # IAM-ATU
Push to start and
Push to raise and
pause internal
lower operating
message recording
frequency
External hand-held
External audio
microphone jack.
input for
Use automatically
internal chip
overrides internal
recording or
microphone.
live input.
Select recording
of part 1 or part 2
internal message
Transmitter Hand-held Mic
Model # IAM-Mic
Select "MESSAGE CHIP"
to playback from internal
storage chip, or select
"LIVE RADIO" to transmit
via internal mic or
external line source.
Transmitter Power Supply
Model # IAM-Power Supply
